USER’S MANUAL
Revision 1.1
X10DRT-P
X10DRT-PT
X10DRT-PIBQ
X10DRT-PIBF
Manual Revision 1.1
Release Date: December 19, 2017
Unless you request and receive written permission from Super Micro Computer, Inc., you may not
copy any part of this document.
Information in this document is subject to change without notice. Other products and companies
referred to herein are trademarks or registered trademarks of their respective companies or mark
holders.
Copyright © 2017 by Super Micro Computer, Inc.
All rights reserved.
Printed in the United States of America
The information in this user’s manual has been carefully reviewed and is believed to be accurate.
The vendor assumes no responsibility for any inaccuracies that may be contained in this document,
and makes no commitment to update or to keep current the information in this manual, or to notify
any person or organization of the updates. Please Note: For the most up-to-date version of this
manual, please see our website at www.supermicro.com.
Super Micro Computer, Inc. ("Supermicro") reserves the right to make changes to the product
described in this manual at any time and without notice. This product, including software and docu-
mentation, is the property of Supermicro and/or its licensors, and is supplied only under a license.
Any use or reproduction of this product is not allowed, except as expressly permitted by the terms
of said license.
IN NO EVENT WILL SUPER MICRO COMPUTER, INC. BE LIABLE FOR DIRECT, INDIRECT,
SPECIAL, INCIDENTAL, SPECULATIVE OR CONSEQUENTIAL DAMAGES ARISING FROM THE
USE OR INABILITY TO USE THIS PRODUCT OR DOCUMENTATION, EVEN IF ADVISED OF
THE POSSIBILITY OF SUCH DAMAGES. IN PARTICULAR, SUPER MICRO COMPUTER, INC.
SHALL NOT HAVE LIABILITY FOR ANY HARDWARE, SOFTWARE, OR DATA STORED OR USED
WITH THE PRODUCT, INCLUDING THE COSTS OF REPAIRING, REPLACING, INTEGRATING,
INSTALLING OR RECOVERING SUCH HARDWARE, SOFTWARE, OR DATA.
Any disputes arising between the manufacturer and the customer shall be governed by the laws of
Santa Clara County in the State of California, USA. The State of California, County of Santa Clara
shall be the exclusive venue for the resolution of any such disputes. Supermicro's total liability for
all claims will not exceed the price paid for the hardware product.
FCC Statement: This equipment has been tested and found to comply with the limits for a Class
A digital device pursuant to Part 15 of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference when the equipment is operated in a commercial
environment. This equipment generates, uses, and can radiate radio frequency energy and, if not
installed and used in accordance with the manufacturer’s instruction manual, may cause harmful
interference with radio communications. Operation of this equipment in a residential area is likely
to cause harmful interference, in which case you will be required to correct the interference at your
own expense.
California Best Management Practices Regulations for Perchlorate Materials: This Perchlorate
warning applies only to products containing CR (Manganese Dioxide) Lithium coin cells. “Perchlorate
Material-special handling may apply. See www.dtsc.ca.gov/hazardouswaste/perchlorate”.
WARNING: Handling of lead solder materials used in this
product may expose you to lead, a chemical known to
the State of California to cause birth defects and other
reproductive harm.
Preface
This manual is written for system integrators, IT professionals, and
knowledgeable end-users. It provides information for the installation and use of the
X10DRT-P/PT/PIBQ/PIBF motherboard.
About This Motherboard
The Super X10DRT-P/PT/PIBQ/PIBF motherboard supports dual Intel
® E5-2600v3/
v4 Series processors (Socket R3) that offer Intel® QPI (Intel QuickPath Interface)
Technology, providing point-to-point connections with a transfer speed of up to
9.6 GT/s. With the PCH C612 built in, the X10DRT-P/PT/PIBQ/PIBF motherboard
supports Intel® Manageability Engine, Intel Rapid Storage Technology enterprise,
Digital Media Interface (DMI), PCI-E Gen. 3.0, and 2400 MHz (max.) DDR4 memory.
This motherboard is ideal for Twin Pro server platforms. Please refer to our website
(http://www.supermicro.com) for processor and memory support updates.
Manual Organization
Chapter 1 describes the features, specications and performance of the moth-
erboard. It also provides detailed information about the Intel PCH C612 chipset.
Chapter 2 provides hardware installation instructions. Read this chapter when in-
stalling the processor, memory modules, and other hardware components into the
system. If you encounter any problems, see , which describes troubleChapter 3 -
shooting procedures for video, memory, and system setup stored in CMOS.
Chapter 4 includes an introduction to BIOS, and provides detailed information on
running the BIOS Setup utility.
Appendix A provides BIOS Error Beep Codes.
Appendix B lists software installation instructions.
Appendix C contains UEFI BIOS Recovery instructions.
Preface
iii
iv
Conventions Used in the Manual
Pay special attention to the following symbols for proper system installation and to
prevent damage to the system or injury to yourself:
Warning: Important information given to ensure proper system installation or to prevent
damage to the components
Note: Additional information given to differentiate between various models
or provides information for proper system setup.
X10DRT-P/PT/PIBQ/PIBF Motherboard User’s Manual
Preface
v
Contacting Supermicro
Headquarters
Address: Super Micro Computer, Inc.
980 Rock Ave.
San Jose, CA 95131 U.S.A.
Tel: +1 (408) 503-8000
Fax: +1 (408) 503-8008
Email: marketing@supermicro.com (General Information)
support@supermicro.com (Technical Support)
Website: www.supermicro.com
Europe
Address: Super Micro Computer B.V.
Het Sterrenbeeld 28, 5215 ML
's-Hertogenbosch, The Netherlands
Tel: +31 (0) 73-6400390
Fax: +31 (0) 73-6416525
Email: sales@supermicro.nl (General Information)
support@supermicro.nl (Technical Support)
rma@supermicro.nl (Customer Support)
Website: www.supermicro.nl
Asia-Pacic
Address: Super Micro Computer, Inc.
3F, No. 150, Jian 1st Rd.
Zhonghe Dist., New Taipei City 235
Taiwan (R.O.C)
Tel: +886-(2) 8226-3990
Fax: +886-(2) 8226-3992
Email: support@supermicro.com.tw
Website: www.supermicro.com.tw
vi
Table of Contents
Preface
Chapter 1 Overview
1-1 Overview ......................................................................................................... 1-1
1-2 Processor and Chipset Overview .................................................................1-11
1-3 Special Features ........................................................................................... 1-12
1-4 System Health Monitoring ............................................................................. 1-12
1-5 ACPI Features ............................................................................................... 1-13
1-6 Power Supply ................................................................................................ 1-13
1-7 Serial Port ..................................................................................................... 1-13
1-8 Advanced Power Management ..................................................................... 1-14
Intel® Intelligent Power Node Manager (NM) (Available when the Supermicro
Power Manager [SPM] is installed)............................................................... 1-14
Management Engine (ME) ............................................................................ 1-14
Chapter 2 Installation
2-1 Standardized Warning Statements ................................................................. 2-1
2-2 Static-Sensitive Devices .................................................................................. 2-4
2-3 Processor and Heatsink Installation................................................................ 2-5
Installing the LGA2011 Processor ................................................................. 2-5
Installing a Passive CPU Heatsink ................................................................. 2-9
Removing the Passive Heatsink ................................................................... 2-10
2-4 Installing and Removing the Memory Modules ..............................................2-11
Installing & Removing DIMMs ........................................................................2-11
Removing Memory Modules ..........................................................................2-11
2-5 Motherboard Installation ................................................................................ 2-14
Tools Needed ................................................................................................ 2-14
Location of Mounting Holes .......................................................................... 2-14
2-6 Control Panel Connectors and I/O Ports ...................................................... 2-15
Back Panel Connectors and I/O Ports .......................................................... 2-15
Back Panel I/O Port Locations and Denitions ........................................... 2-15
Universal Serial Bus (USB) ...................................................................... 2-16
Ethernet Ports .......................................................................................... 2-17
QSFP Connector (Connect-X3 QDR 40 GT/s or FDR 56 GT/s) (For
X10DRT-PIBQ/PIBF) 2-18 ................................................................................
Video Connector ....................................................................................... 2-18
Unit Identier Switch ................................................................................ 2-19
Front Panel Accessible Add-on Card Connector (JF1) ................................. 2-20
X10DRT-P/PT/PIBQ/PIBF Motherboard User’s Manual
vii
Table of Contents
2-7 Connecting Cables ........................................................................................ 2-21
COM Port Header .................................................................................... 2-21
IPMB I2C SMB .......................................................................................... 2-21
DOM Power Connector ............................................................................ 2-22
Fan Headers ............................................................................................. 2-23
TPM Header/Port 80 ................................................................................ 2-24
2-8 Jumper Settings ............................................................................................ 2-25
Explanation of Jumpers ................................................................................ 2-25
LAN Ports 1/2 Enable .............................................................................. 2-25
CMOS Clear ............................................................................................. 2-26
Watch Dog Enable/Disable ...................................................................... 2-26
VGA Enable .............................................................................................. 2-27
BMC Enable) ............................................................................................ 2-27
2-9 Onboard LED Indicators ............................................................................... 2-28
LAN LEDs ................................................................................................. 2-28
IPMI Dedicated LAN LEDs ....................................................................... 2-28
BMC Heartbeat LED (For X10DRT-PIBF) ................................................ 2-29
InniBand Link/Activity LED Indicators (For the X10DRT-PIBQ/PIBF Only) ..
.................................................................................................................. 2-30
Rear UID LED ......................................................................................... 2-31
2-10 SATA and SATA/PCI-E 3.0 Slots ................................................................... 2-32
S-SATA 0-2/CPU2_PCI-Express 3.0 x16 Slot (SXB1) ............................. 2-32
I-SATA 0-5/CPU1_PCI-Express 3.0 x8 Slot (SXB2) ................................ 2-32
SATA DOM/Power .................................................................................... 2-33
Chapter 3 Troubleshooting
3-1 Troubleshooting Procedures ........................................................................... 3-1
3-2 Technical Support Procedures ........................................................................ 3-5
3-3 Battery Removal and Installation .................................................................... 3-6
3-4 Frequently Asked Questions ........................................................................... 3-7
3-5 Returning Merchandise for Service................................................................. 3-8
Chapter 4 BIOS
4-1 Introduction ...................................................................................................... 4-1
4-2 Main Setup ...................................................................................................... 4-2
4-3 Advanced Setup Congurations...................................................................... 4-4
4-4 Event Logs ....................................................................................................4-34
4-5 IPMI ............................................................................................................... 4-36
4-6 Security Settings ........................................................................................... 4-38
4-7 Boot Settings ................................................................................................. 4-42
4-8 Save & Exit ................................................................................................... 4-44
viii
Appendix A BIOS Error Beep Codes
A-1 BIOS Error Beep Codes .................................................................................A-1
Appendix B Software Installation Instructions
B-1 Installing Software Programs ..........................................................................B-1
B-2 Conguring SuperDoctor 5 .............................................................................B-2
Appendix C UEFI BIOS Recovery Instructions
C-1 An Overview to the UEFI BIOS ......................................................................C-1
C-2 How to Recover the UEFI BIOS Image (-the Main BIOS Block)....................C-1
C-3 To Recover the Main BIOS Block Using a USB-Attached Device..................C-1
X10DRT-P/PT/PIBQ/PIBF Motherboard User’s Manual
Chapter 1: Overview
1-1
Chapter 1
Overview
1-1 Overview
Checklist
Congratulations on purchasing your computer motherboard from an acknowledged
leader in the industry. Supermicro boards are designed with the utmost attention to
detail to provide you with the highest standards in quality and performance.
This motherboard was designed to be used with an SMCI-proprietary chassis as
an integrated server platform. There will be no shipping package included in the
shipment.
Note: For your system to work properly, please follow the links below to
download all necessary drivers/utilities and the user's manual for your
motherboard.
Supermicro product manuals: http://www.supermicro.com/support/manuals/
Product Drivers and utilities: ftp://ftp.supermicro.com/
If you have any questions, please contact our support team at support@supermicro.
com.
1-2
X10DRT-P/PT/PIBQ/PIBF Motherboard User’s Manual
Motherboard Image
Model Variations for X10DRT-P/PT/-PIBQ/-PIBF
X10DRT-P X10DRT-PT X10DRT-PIBQ X10DRT-PIBF
LAN Ports Gigabit LAN1/2 10_Gigabit LAN1/2 Gigabit LAN1/2 Gigabit LAN1/2
IPMI/IPMI_LAN Yes Yes Yes Yes
FDR IB No No No Yes
QDR IB No No NoYes
Note: All graphics shown in this manual were based upon the latest PCB
Revision available at the time of publishing of the manual. The motherboard
you've received may or may not look exactly the same as the graphics
shown in this manual.
Chapter 1: Overview
1-3
Notes:
1. For the latest CPU/Memory updates, please refer to our website at http://
www.supermicro.com/products/motherboard/ for details.
2. Use only the correct type of onboard CMOS battery as specied by
the manufacturer. Do not install the onboard battery upside down to avoid
possible explosion.
Motherboard Layout
JBT1
P1-DIMMB2
S-SATA3
IB CODE
BAR CODE
BIOS
LICENSE
COM1
JIPMB1
FAN3
FAN4
JSD1
JTPM1
JF1
UID_LED1
BMC_HB_LED1
JPG1
JPB1
JVRM2
JVRM1
JWD1
JPL1
/CPU2 PCI-E 3.0 X16)
(CPU2 SLOT1 PCI-E 3.0 X16)
PCI-E 3.0 X8)(CPU2 SLOT2
UID SW
BATTERY
BIOS
BMC
VGA
QSFP
LAN1/LAN2
IB
10G/1G
(3.0)USB0/1
IPMI_LAN
SATA DOM+POWER
TPM/PORT80
CPU2_VRM_HS1
CPLD
P2-DIMMG1
P2-DIMMH2
P2-DIMMH1
P2-DIMMG2
P2-DIMMF2
P2-DIMME1
P2-DIMME2
P2-DIMMF1
P1-DIMMD2
P1-DIMMD1
P1-DIMMC2
P1-DIMMC1
P1-DIMMB1
P1-DIMMA2
P1-DIMMA1
/CPU1PCI-E 3.0 X8)(I-SATA0~5
CPU2
CPU1
LAN CTRL
PCH
IB_LINK_LED1
IB_ACT_LED1
(S-SATA0~2
SXB1 SXB2
Slot1 Slot2
SXB1
SXB2
X10DRT-P Series
Rev. 1.10
1-4
X10DRT-P/PT/PIBQ/PIBF Motherboard User’s Manual
Notes:
• See Chapter 2 for detailed information jumpers, I/O ports, connectors and ex-
pansion slots. " " indicates the location of "Pin 1".
• Components/Jumpers/LED Indicators that are not documented in this manual
are reserved for internal testing only.
X10DRT-P/PT/PIBQ/PIBF Motherboard Quick Reference
JBT1
P1-DIMMB2
S-SATA3
IB CODE
BAR CODE
BIOS
LICENSE
COM1
JIPMB1
FAN3
FAN4
JSD1
JTPM1
JF1
UID_LED1
BMC_HB_LED1
JPG1
JPB1
JVRM2
JVRM1
JWD1
JPL1
/CPU2 PCI-E 3.0 X16)
(CPU2 SLOT1 PCI-E 3.0 X16)
PCI-E 3.0 X8)(CPU2 SLOT2
UID SW
BATTERY
BIOS
BMC
VGA
QSFP
LAN1/LAN2
IB
10G/1G
(3.0)USB0/1
IPMI_LAN
SATA DOM+POWER
TPM/PORT80
CPU2_VRM_HS1
CPLD
P2-DIMMG1
P2-DIMMH2
P2-DIMMH1
P2-DIMMG2
P2-DIMMF2
P2-DIMME1
P2-DIMME2
P2-DIMMF1
P1-DIMMD2
P1-DIMMD1
P1-DIMMC2
P1-DIMMC1
P1-DIMMB1
P1-DIMMA2
P1-DIMMA1
/CPU1PCI-E 3.0 X8)(I-SATA0~5
CPU2
CPU1
LAN CTRL
PCH
IB_LINK_LED1
IB_ACT_LED1
(S-SATA0~2
SXB1 SXB2
Slot1 Slot2
SXB1
SXB2
X10DRT-P Series
Rev. 1.10
Chapter 1: Overview
1-5
X10DRT-P/PT/PIBQ/PIBF Motherboard Jumpers
Jumper Description Default Setting
JBT1 Clear CMOS/Reset BIOS
Conguration
See Chapter 2
JPB1 BMC Enabled Pins 1-2 (Enabled)
JPG1 VGA Enabled Pins 1-2 (Enabled)
JPL1 (For X10DRT-P/
PIBQ/PIBF)
GLAN1/GLAN2 Enable Pins 1-2 (Enabled)
JPL1 (For X10DRT-PT) 10G-LAN1/10G-LAN2 Enable Pins 1-2 (Enabled)
JWD1 Watch Dog Pins 1-2 (RST)
X10DRT-P/PT/PIBQ/PIBF Motherboard Connectors
Connectors Description
Battery Onboard CMOS Battery (See the Note on P. 1-3.)
COM1 COM Port Header
FAN3/FAN4 System Cooling Fan Headers 3/4
JF1 SMC Proprietary Slot for SMC Add-On Card for Power,
Front Control Panel
JIPMB1 4-pin External BMC I2C Header (for an IPMI Card)
JSD1 SATA DOM (Device_On_Module) Power Connector
JTPM1 TPM (Trusted Platform Module)/Port 80
LAN1/2 G-bit Ethernet Ports 1/2 (for X10DRT-P/PIBQ/PIBF),
10G-bit Ethernet Ports 1/2 (for X10DRT-PT)
(IPMI) LAN IPMI_Dedicated LAN
QSFP -Quad (4-channel) Small Form-factor Pluggable (QSFP) Con
nector used as Connect-X3 FDR 56GT/s or QDR 40GT/s In-
niBand Port (for X10DRT-PIBQ/PIBF)
S-SATA3 SATA DOM (Disk-On-Module) with Power-pin Connector
(CPU2) Slot1 PCI-E 3.0 x16 Slot supported by CPU2
(CPU2) Slot2 PCI-E 3.0 p13-x8 Slot supported by CPU2
SXB2 I-SATA 0-5/PCI-E 3.0 p13-x8 Slot supported by CPU1
SXB1 S-SATA 0-2/PCI-E 3.0 x16 Slot supported by CPU2
UID SW UID (Unit Identier) Switch (JUIDB1)
USB0/1 (3.0) Back Panel USB 3.0 Ports 0/1
VGA Backpanel VGA Port
X10DRT-P/PT/PIBQ/PIBF Motherboard LED Indicators
LED State
BMC_HB_LED1 (BMC Heartbeat LED) Green (Blinking): BMC Normal
1-6
X10DRT-P/PT/PIBQ/PIBF Motherboard User’s Manual
IB_ACT_LED1 (InniBand Activity LED)
(X10DRT-PIBQ/PIBF) Yellow (Blinking): InniBand Active
IB_LINK_LED1 (InniBand Link LED)
(X10DRT-PIBQ/PIBF) Green (On): InniBand On
UID LED1 (Unit_Identier LED) Blue: (On/Blinking) Unit Identied
Chapter 1: Overview
1-7
CPU • Dual Intel® E5-2600v3/v4 Series processors (Socket
R3 LGA 2011); each processor supports two full-width
Intel QuickPath Interconnect (QPI) links (with Data
Transfer Rate of up to 9.6 GT/s per QPI)
Note: E5-2600v4 requires Revision 2.0 BIOS
(or higher).
Memory • Integrated memory controller supports up to 2048
GB of Load Reduced (LRDIMM), and up to 512
GB of Registered (RDIMM) DDR4 (288-pin) ECC
2400/2133/1866/1600 MHz memory in 16 slots
Note: Memory speed support is pending on
the processors installed in the system. For
the latest CPU/memory updates, please refer
to our website at http://www.supermicro.com/
products/motherboard.
DIMM Sizes
Up to 128GB @ 1.20V
Chipset • Intel® PCH C612
Expansion • One (1) PCI Express 3.0 p15-x8 slot supported by CPU1
(SXB2)
• One (1) PCI Express 3.0 x16 slot supported by CPU2
(SXB1)
• One (1) PCI Express 3.0 x16 slot (CPU2 Slot 1)
• One (1) PCI Express 3.0 p15-x8 slot (CPU2 Slot 2)
Slots
Graphics • ASpeed 2400 BMC Controller with integrated VGA/2D
Graphics Controller 1920x1200@60Hz 32bpp
Network • One Intel i350 Gigabit (10/100/1000 Mb/s) Ethernet
Dual-Channel controller for GLAN 1/GLAN 2 ports
(X10DRT-P/PIBQ/PIBF)
• One Intel X540 10_Gigabit Ethernet Dual-Channel
controller for 10G-LAN1/10G-LAN2 ports (X10DRT-
PT)
I/O Devices Connect-X3 Port (X10DRT-PIBQ/PIBF)
• Used as InniBand QDR 40 GT/s or FDR 56 GT/s
(4-channel) Small Form-factor Pluggable (QSFP)
Port
SATA Connections
• SATA 3.0 Ten (10) SATA 3.0 Connections
• RAID RAID 0, 1, 5, 10 (from Intel PCH)
Motherboard Features
1-8
X10DRT-P/PT/PIBQ/PIBF Motherboard User’s Manual
IPMI 2.0
• IPMI 2.0 supported by the ASpeed 2400 BMC
Serial (COM) Port
• One (1) Fast UART 16550 connection header
VGA
• Rear VGA Port
Peripheral
Devices
USB Devices
• Two (2) USB ports on the rear I/O panel (USB 3.0)
Ports USB 0/1
BIOS • 16 MB AMI SPI BIOS Flash ROM
• DMI 2.3, PCI 2.3, ACPI 2.0/3.0/4.0, USB Keyboard,
Plug & Play (PnP), UEFI 2.3.1, and SMBIOS 2.7
or later,
Power • ACPI Power Management
• Power-on mode for AC power recovery
• Intel® Intelligent Power Node Manager (available
when the NMView utility is installed)
• Management Engine
• Riser Card auto-detection
System
Health
System Health Monitoring
Monitoring • Onboard system health monitors for 12V, +3.3V, +5V,
Vcpu, Vdimm (DDR4 DIMM voltage), chipset voltage,
and battery voltage.
• CPU 5-Phase switching voltage regulator
• CPU/System overheat LED and control
• CPU Thermal Trip support
• Thermal Monitor 2 (TM2) support
Fan Control
• Fan status monitoring with rmware 4-pin fan speed
control
• Low noise fan speed control
LED Indicators
• BMC (BaseBoard Management) LED
• InniBand LED
• UID/Remote UID LED
Chapter 1: Overview
1-9
System
Management
• PECI (Platform Environment Conguration Interface)
2.0 support
• System resource alert via SuperDoctor® 5
• Thermal Monitor 2 (TM2) support
• SuperDoctor® 5, Watch Dog, NMI
Dimensions • 18.86" (L) x 6.80" (W) (479.04 mm x 172.72 mm)
1-10
X10DRT-P/PT/PIBQ/PIBF Motherboard User’s Manual
System Block Diagram
Notes: 1. This is a general block diagram and may not exactly represent
the features on your motherboard. See the Motherboard Features pages
for the actual specications of each motherboard. 2. This block diagram
was provided for your reference only.
SPI
L 3 AN
RGRMII
Debug Card
FRONT PANEL
SYSTEM POWER
CTRL
FAN SPEED
PCI-E X1 G2
USB 2.0
PCH C612
6.0 Gb/S
LPC
1
0
SATA
5
4
R E-VB-CGTL8211
3
2
R 5J4
Temp Sensor
EMC1402-1 *2 at diff SMBUS
TPM HE ERAD
USB 3.0
USB
AST 0240
BMC
RMII/NCSI
VGA CONN
BMC Boot Fl has
DDR3
5 PHASE
145W
DDR4
P1
P1
P0
VR12.5
P0
#2-1
DDR4
#1-4
#1-3
#1-2
#1-1
QPI
9.6G
CX3 IB
CPU1
DMI2
PCI-E X8 G3
#1-5
#1-6
PCI-E X8 G3
DMI2
CPU2
DDR- DDR-4 4
QPI
9.6G
5 PHASE
145W
VR12.5
#1
i /350
X 054
LAN
PCI-E X8
SLOT1
SLOT2
PCI-E X8 G3
PCI-E X16 G3
PCI-E X16 G3
#1-7
#1-8
#2-2
#2-3
#2-4
#2-5
#2-6
#2-7
#2-8
6789
SXB2
COM1
Conn torec
#1
#2 #2
DMI2
#3 #3
SXB1
SPI
BIOS
SPI
Chapter 1: Overview
1-11
1-2 Processor and Chipset Overview
Built upon the functionality and capability of the Intel E5-2600v3/v4 Series pro-
cessors (Socket R3) and the Intel C612 PCH, the X10DRT-P Series motherboard
provides the best balanced solution of performance, power efciency, and features
to address the diverse needs of next-generation data centers.
With support of new Intel Microarchitecture 22nm (E5-2600v3)/14nm (E5-2600v4)
Process Technology, the X10DRT-P Series dramatically increases motherboard
system performance for a multitude of server applications.
The PCH C612 chip in conjunction with the E5-2600v3/v4 processors support
the following features:
• Enterprise SMbus and MCTP support
• DDR4 288-pin memory support on Socket R3
• Support for MCTP Protocol and ME
• Support of SMBus speeds of up to 1 MHz for BMC connectivity
• Improved I/O capabilities to high-storage-capacity congurations
• SPI Enhancements
• Intel® Node Manager 3.0 for advanced power monitoring, capping and man-
agement for BMC enhancement (Note below)
• BMC supports remote management, virtualization, and the security package
for enterprise platforms
Note:
1. E5-2600v4 requires Revision 2.0 BIOS (or higher).
2. Intel Node Manager 3.0 support is dependent on the power supply
used in the system.
1-12
X10DRT-P/PT/PIBQ/PIBF Motherboard User’s Manual
1-3 Special Features
Recovery from AC Power Loss
The Basic I/O System (BIOS) provides a setting that determines how the system will
respond when AC power is lost and then restored to the system. You can choose for
the system to remain powered off (in which case you must press the power switch
to turn it back on), or for it to automatically return to the power-on state. See the
Advanced BIOS Setup section for this setting. The default setting is Last State.
1-4 System Health Monitoring
This section describes the features of system health monitoring of the motherboard.
This motherboard has an onboard Baseboard Management Controller (BMC) chip
that supports system health monitoring. Once a voltage becomes unstable, a warn-
ing is given, or an error message is sent to the screen. The user can adjust the
voltage thresholds to dene the sensitivity of the voltage monitor.
Fan Status Monitor with Firmware Control
The system health monitor embedded in the BMC chip can check the RPM status
of a cooling fan. The CPU and chassis fans are controlled via lPMI 2.0.
Environmental Temperature Control
System Health sensors in the BMC monitor temperatures and voltage settings of
onboard processors and the system in real time via the IPMI interface. Whenever
the temperature of the CPU or the system exceeds a user-dened threshold,
system/CPU cooling fans will be turned on to prevent the CPU or the system from
overheating.
Note: To avoid possible system overheating, please be sure to provide
adequate airow to your system.
System Resource Alert
This feature is available when used with SuperDoctor 5. SuperDoctor 5 is used
to notify the user of certain system events. For example, you can congure
SuperDoctor 5 to provide you with warnings when the system temperature, CPU
temperatures, voltages and fan speeds go beyond a predened range.
Chapter 1: Overview
1-13
1-5 ACPI Features
ACPI stands for Advanced Conguration and Power Interface. The ACPI specica-
tion denes a exible and abstract hardware interface that provides a standard way
to integrate power management features throughout a computer system, including
its hardware, operating system and application software. This enables the system
to automatically turn on and off peripherals such as network cards, hard disk drives
and printers.
In addition to enabling operating_system-directed power management, ACPI also
provides a generic system event mechanism for Plug and Play, and an operating
system-independent interface for conguration control. ACPI leverages the Plug and
Play BIOS data structures, while providing a processor architecture-independent
implementation that is compatible with Windows 8/R2, and Windows 2012/R2
operating systems.
1-6 Power Supply
As with all computer products, a stable power source is necessary for proper and
reliable operation. It is even more important for processors that have high CPU
clock rates. In areas where noisy power transmission is present, you may choose
to install a line lter to shield the computer from noise. It is recommended that you
also install a power surge protector to help avoid problems caused by power surges.
1-7 Serial Port
The X10DRT-P/PT/PIBQ/PIBF motherboard supports one serial communication
connection. COM 1 can be used for input/output. The UART provide legacy speed
with baud rate of up to 115.2 Kbps as well as an advanced speed with baud rates
of 250 K, 500 K, or 1 Mb/s, which support higher speed modems.
1-14
X10DRT-P/PT/PIBQ/PIBF Motherboard User’s Manual
1-8 Advanced Power Management
The following new advanced power management features are supported by the
motherboard.
Intel® Intelligent Power Node Manager (NM) (Available
when the Supermicro Power Manager [SPM] is installed)
The Intel®
Intelligent Power Node Manager (IPNM) provides your system with
real-time thermal control and power management for maximum energy efciency.
Although IPNM Specication Version 2.0/3.0 is supported by the BMC (Baseboard
Management Controller), your system must also have IPNM-compatible Manage-
ment Engine (ME) rmware installed to use this feature.
Note: Support for IPNM 2.0/3.0 support is dependent on the power supply
used in the system.
Management Engine (ME)
The Management Engine, which is an ARC controller embedded in the IOH (I/O
Hub), provides Server Platform Services (SPS) to your system. The services
provided by SPS are different from those provided by the ME on client platforms.
Chapter 2: Installation
2-1
Chapter 2
Installation
2-1 Standardized Warning Statements
The following statements are industry-standard warnings, provided to warn the user
of situations which have the potential for bodily injury. Should you have questions or
experience difculty, contact Supermicro's Technical Support department for assis-
tance. Only certied technicians should attempt to install or congure components.
Read this section in its entirety before installing or conguring components in the
Supermicro chassis.
Battery Handling
Warning!
There is a danger of explosion if the battery is replaced incorrectly. Replace the
battery only with the same or equivalent type recommended by the manufacturer.
Dispose of used batteries according to the manufacturer's instructions
電池の取り扱い
電池交換が正しく行われなかった場合、破裂の危険性があります。 交換する電池はメー
カーが推奨する型、または同等のものを使用下さい。 使用済電池は製造元の指示に従
って処分して下さい。
警告
电池更换不换会有爆炸危险。换只使用同类电池或制造商推荐的功能相换的电池更
换原有电池。换按制造商的换明处理换换电池。
警告
電池更換不當會有爆炸危險。請使用製造商建議之相同或功能相當的電池更換原有
電池。請按照製造商的說明指示處理廢棄舊電池。
Warnung
Bei Einsetzen einer falschen Batterie besteht Explosionsgefahr. Ersetzen Sie die
Batterie nur durch den gleichen oder vom Hersteller empfohlenen Batterietyp.
Entsorgen Sie die benutzten Batterien nach den Anweisungen des Herstellers.
2-2
X10DRT-P/PT/PIBQ/PIBF Motherboard User’s Manual
Attention
Danger d'explosion si la pile n'est pas remplacée correctement. Ne la remplacer
que par une pile de type semblable ou équivalent, recommandée par le fabricant.
Jeter les piles usagées conformément aux instructions du fabricant.
¡Advertencia!
Existe peligro de explosión si la batería se reemplaza de manera incorrecta. Re-
emplazar la batería exclusivamente con el mismo tipo o el equivalente recomen-
dado por el fabricante. Desechar las baterías gastadas según las instrucciones
del fabricante.
!הרהזא
תנכס תמייקץוציפ .הניקת אל ךרדב הפלחוהו הדימב הללוסה לש ףילחהל שי
גוסב הללוסה תא מ םאותה תרבחלמומ ןרציתצ.
תוללוסה קוליס תושמושמה עצבל שי .ןרציה תוארוה יפל
!
.
.
.
Waarschuwing
Er is ontplofngsgevaar indien de batterij verkeerd vervangen wordt. Vervang de
batterij slechts met hetzelfde of een equivalent type die door de fabrikant aan-
bevolen wordt. Gebruikte batterijen dienen overeenkomstig fabrieksvoorschriften
afgevoerd te worden.
Chapter 2: Installation
2-3
Product Disposal
Warning!
Ultimate disposal of this product should be handled according to all national laws
and regulations.
製品の廃棄
この製品を廃棄処分する場合、国の関係する全ての法律・条例に従い処理する必要が
あります。
警告
本换品的换换处理换根据所有国家的法律和换章换行。
警告
本產品的廢棄處理應根據所有國家的法律和規章進行。
Warnung
Die Entsorgung dieses Produkts sollte gemäß allen Bestimmungen und Gesetzen
des Landes erfolgen.
¡Advertencia!
Al deshacerse por completo de este producto debe seguir todas las leyes y regla-
mentos nacionales.
Attention
La mise au rebut ou le recyclage de ce produit sont généralement soumis à des
lois et/ou directives de respect de l'environnement. Renseignez-vous auprès de
l'organisme compétent.
