P CaCkage ontents
X11sDV-4C/8C/12C/16C-tP8f
Q r g 1.0uICk eferenCe uIDe b
• One (1) Supermicro Motherboard
• Four (4) SATA Cables
• One (1) I/O Shield
• One (1) Quick Reference Guide
• Website: www.supermicro.com
• General Information: marketing@supermicro.com
• Technical Support: support@supermicro.com
• Phone: +1 (408) 503-8000, Fax: +1 (408) 503-8008
f or your system to work ProPerly Please DownloaD aPProPrIate,
DrIVers Images user s manual from the lInks below/ / ' :
MNL-2007-QRG-10b
• Two (2) Mini-SAS HD Cables
WARNING: This product can expose you to chemicals including
lead, known to the State of California to cause cancer and birth
defects or other reproductive harm. For more information, go
to www.P65Warnings.ca.gov.
!
BAR CODE
MADE IN USA
X11SDV-8C-TP8F
REV:1.02
2
1
JSIM1
G2
G3
G4 G1
S3
S5
S6
S1
S2
S4
S-SATA0
S-SATA1
S-SATA3
S-SATA2
LEDT1
C
A
LEDT3
A
C
LED3
A
C
LED1
A
C
LED2
A
C
JMD1_SRW1
JMD2_SRW1
PRESS FIT PRESS FIT
JPH1
JMD2
2
JPV1
BT1
SFP1
PRESS FIT
JSMB1
1
JI2C1
JPL1
JI2C2 JPME2
1
JWD1
JPUSB1
LEDM1
LEDT4
A
C
LEDT2
A
C
JMP1
JNVI2C1
CPU SLOT6 PCI-E 3.0 X16 JLANLED1
JL1
JPW1
JPI2C1
JBT1
JPG1
JNS1
JTGLED2
JTGLED1JIPMB1
COM1
JSD1
JF1
16
JD1
FANB
FANA
FAN4 FAN3
FAN1
FAN2
JMP1_SRW1 JMP1_SRW2
:LEDPWR
I-SATA4-7I-SATA0-3
M.2-H
PCI-E 3.0 X2/S-SATA4
CPU
UID
VGA
DIMMB1
DIMME1
USB 0/1
DIMMD1
DIMMA1
PCI-E 3.0 X1
CPU SLOT6 PCI-E 3.0 X16
CPU SLOT7 PCI-E 3.0 X8
2-3:DISA
1-2:E
JPB1:(deb only)
PCI-E 3.0 X4 / S-SATA5
JMD1:M.2-HC
1-3:PWR LED
4-7:SPEAKER
:SUPER DOM
PWR
ON
OH
FF
XRST NIC1NIC2
JF1: PWR
LEDLED
HDD
2-3:DISABLE
1-2:ENABLE
JPL1:
LAN1/2/3/4
JSTBY1
LAN 1/2
LAN 7/8
LAN 5/6
LAN 3/4 IPMI_LAN
USB 4/5 (3.0)
S-SGPIO1
JTPM1 JGP1
USB 2/3
Connectors
DIMM Memory Installation
Jumpers and Connectors
Memory Support
Motherboard Layout and Features
Jumpers
Note: Graphics shown in this quick reference guide are for illustration only. Your components may or may not look exactly the same as drawings shown in this
guide.
Note: Refer to Chapter 1 of the User Manual for detailed information on jumpers, connectors,
and LED indicators.
Note: Refer to Chapter 2 of the User Manual for detailed information on memory support and CPU/
motherboard installation instructions.
Front Control Panel (JF1)
CPU Support
LED Indicators
The X11SDV-4C/8C/12C/16C-TP8F motherboard supports up to 256GB of ECC
RDIMM and 512GB of ECC LRDIMM DDR4 memory.
When installing memory modules, the DIMM slots should be populated in the
following order: DIMMA1, DIMMB1, DIMMD1, DIMME1.
• Always use DDR4 DIMM modules of the same type, size, and speed.
• Mixed DIMM speeds can be installed. However, all DIMMs will run at the
speed of the slowest DIMM.
• The motherboard will support odd-numbered modules (one or three modules
installed). However, for best memory performance, install DIMM modules in
pairs to activate memory interleaving.
The X11DV-4C/8C/12C/16C-TP8F motherboard supports an Intel® Xeon®
D-2100 Series SoC.
Connector Description
BT1 Onboard Battery
COM1 COM Header
FAN1 - FAN4, FANA, FANB System Fan Connectors
IPMI_LAN Dedicated IPMI LAN Port
I-SATA0-3, I-SATA4-7 Eight Intel® PCH SATA 3.0 Ports or Two NVMe U.2 Ports
(See jumper JNS1 setting)
JD1 PWR LED/Speaker Header (Pins 1-3: PWR LED, Pins 4-7: Speaker)
JF1 Front Control Panel Header
JGP1 General Purpose I/O Header
JIPMB1 System Mangement Bus Header (for IPMI only)
JL1 Chassis Intrusion Header
JLANLED1 LAN1 - LAN4 Activity LED Header
JMD1 M.2 PCI-E 3.0 x4/S-SATA5 Connector (M-Key 2280)
JMD2 M.2 PCI-E 3.0 x2/S-SATA4 Connector (B-Key 3042)
JMD1_SRW1, JMD2_SRW1 M.2 Holding Screws
JMP1 Mini PCI-E p1-x1 Connector
JMP1_SRW1 Mini PCI-E p1-x1 Connector Holding Screw
JNVI2C1 NVMe I2C Header
JPI2C1 Power I2C System Management Bus (Power SMB) Header
JPH1 4-pin Power Connector for HDD use
JPW1 24-pin Main Power Connector
JPV1 12V 8-pin DC Power Connector (Required to provide extra power to
CPU, or as alternative power for special enclosure when the 24 pin ATX
power is not in use)
JSD1 SATA Disk On Module (DOM) Power Connector
JSIM1 Nano SIM Slot for M.2 B-Key WAN card support
JSMB1 System Management Bus Header
JSTBY1 +5V Standby Power Header
JTGLED1 LAN7/LAN8 Activity LED Header
JTGLED2 LAN5/LAN6 Activity LED Header
JTPM1 Trusted Platform Module (TPM)/Port 80 Header
LAN1 - LAN4 1GbE (RJ45) LAN Ports
LAN5 - LAN6 10GbE (RJ45) LAN Ports
LAN7 - LAN8 10G SFP+ LAN Ports
S-SATA0 - S-SATA3 SATA 3.0 Ports
Jumper Description Default
JBT1 CMOS Clear Open: Normal, Short: Clear CMOS
JI2C1, JI2C2 SMB to PCI-E Slots Enable/Disable Pins 2-3 (Disabled)
JNS1 Mini-SAS HDD NVMe/SATA Mode Select Pins 1-2: SATA (Default), Pins 2-3: NVMe
JPG1 Onboard VGA Enable Pins 1-2 (Enabled)
JPL1 LAN 1/2/3/4 Enable Pins 1-2 (Enabled)
JPME2 ME Manufacturing Mode Pins 1-2 (Normal)
JPUSB1 USB Wake Up Pins 1-2 (Enabled)
JWD1 Watch Dog Pins 1-2 (Reset)
Connectors and LED Indicators
LED Description Status
LED1 Power LED Solid Green: Power On
LED2 UID LED Solid Blue: Unit Identied
LED3 Overheat/PWR Fail/Fan Fail Solid Red: Overheat
Blinking Red: PWR Fail or Fan Fail
LEDM1 BMC Heartbeat Blinking Green: BMC Normal
Back Panel I/O Connectors
1
9
8
7
6
5
4
3
2
10
Connectors
Connector Description
S-SGPIO1 Serial General Purpose I/O Header for S-SATA0-3
SLOT6 CPU PCI-E 3.0 p1-x16 Slot
SLOT7 CPU PCI-E 3.0 p1-x8 Slot
UID Unit Identier Button
USB0/1, USB2/3 Front Accessible USB 2.0 Ports
USB4/5 Back Panel USB 3.0 Ports
VGA VGA Port
1211
# # #Description Description Description
1 5 9IPMI_LAN LAN1 LAN5
2 6USB5 LAN4 10 SFP LAN8
3 7USB4 LAN3 11 SFP LAN7
4 8LAN2 LAN6 12 VGA
Power Button
OH/Fan Fail LED
NIC1 Activity LED
Reset Button
HDD LED
PWR LED
Reset
PWR
3.3V Stby
3.3V Stby
Ground
15
3.3V Stby
16
1 2
Ground
NIC2 Activity LED
PWR Fail LED
UID
3.3V
3.3V
= mounting hole
