USER'S MANUAL

Revision 1.0

X12SDV-4C/8C/10C-SP6F

X12SDV-8CE-SP4F

The information in this user’s manual has been carefully reviewed and is believed to be accurate. The manufacturer

assumes no responsibility for any inaccuracies that may be contained in this document, and makes no commitment

to update or to keep current the information in this manual, or to notify any person or organization of the updates.

Please Note: For the most up-to-date version of this manual, please see our website at www.supermicro.com.

Super Micro Computer, Inc. ("Supermicro") reserves the right to make changes to the product described in this manual

at any time and without notice. This product, including software and documentation, is the property of Supermicro and/

or its licensors, and is supplied only under a license. Any use or reproduction of this product is not allowed, except

as expressly permitted by the terms of said license.

IN NO EVENT WILL Super Micro Computer, Inc. BE LIABLE FOR DIRECT, INDIRECT, SPECIAL, INCIDENTAL,

SPECULATIVE OR CONSEQUENTIAL DAMAGES ARISING FROM THE USE OR INABILITY TO USE THIS PRODUCT

OR DOCUMENTATION, EVEN IF ADVISED OF THE POSSIBILITY OF SUCH DAMAGES. IN PARTICULAR, SUPER

MICRO COMPUTER, INC. SHALL NOT HAVE LIABILITY FOR ANY HARDWARE, SOFTWARE, OR DATA STORED

OR USED WITH THE PRODUCT, INCLUDING THE COSTS OF REPAIRING, REPLACING, INTEGRATING,

INSTALLING OR RECOVERING SUCH HARDWARE, SOFTWARE, OR DATA.

Any disputes arising between manufacturer and customer shall be governed by the laws of Santa Clara County in the

State of California, USA. The State of California, County of Santa Clara shall be the exclusive venue for the resolution

of any such disputes. Supermicro's total liability for all claims will not exceed the price paid for the hardware product.

FCC Statement: This equipment has been tested and found to comply with the limits for a Class A digital device

pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful

interference when the equipment is operated in a commercial environment. This equipment generates, uses, and can

radiate radio frequency energy and, if not installed and used in accordance with the manufacturer’s instruction manual,

may cause harmful interference with radio communications. Operation of this equipment in a residential area is likely

to cause harmful interference, in which case you will be required to correct the interference at your own expense.

California Best Management Practices Regulations for Perchlorate Materials: This Perchlorate warning applies only

to products containing CR (Manganese Dioxide) Lithium coin cells. “Perchlorate Material-special handling may apply.

See ”.www.dtsc.ca.gov/hazardouswaste/perchlorate

The products sold by Supermicro are not intended for and will not be used in life support systems, medical equipment,

nuclear facilities or systems, aircraft, aircraft devices, aircraft/emergency communication devices or other critical

systems whose failure to perform be reasonably expected to result in signicant injury or loss of life or catastrophic

property damage. Accordingly, Supermicro disclaims any and all liability, and should buyer use or sell such products

for use in such ultra-hazardous applications, it does so entirely at its own risk. Furthermore, buyer agrees to fully

indemnify, defend and hold Supermicro harmless for and against any and all claims, demands, actions, litigation, and

proceedings of any kind arising out of or related to such ultra-hazardous use or sale.

Manual Revision 1.0

Release Date: November 08, 2022

Unless you request and receive written permission from Super Micro Computer, Inc., you may not copy any part of this

document. Information in this document is subject to change without notice. Other products and companies referred

to herein are trademarks or registered trademarks of their respective companies or mark holders.

Printed in the United States of America

WARNING: This product can expose you to chemicals including

lead, known to the State of California to cause cancer and birth

defects or other reproductive harm. For more information, go

to www.P65Warnings.ca.gov.

Preface

About This Manual

This manual is written for system integrators, IT technicians and knowledgeable end users.

It provides information for the installation and use of the motherboard.

About This Motherboard

The Supermicro X12SDV-4C/8C/10C-SP6F and X12SDV-8CE-SP4F series motherboards are

built with Intel® Xeon® D-1700 series processor with up to 10 cores and a thermal design

power (TDP) of up to 80W. These motherboards feature high performance and low power

consumption in a small form factor motherboards. They support 256GB ECC and Non-ECC

RDIMM/UDIMM DDR4 memory with speeds of up to 2933 MT/s, two SATA 3.0 ports, one PCIe

4.0 x16 slot or two PCIe 4.0 x8 slots, and three M.2 slots (one M-Key, one B-Key, one E-Key).

The Supermicro X12SDV-4C/8C/SP6F series features six LAN ports including two 25GbE

and four GbE. The Supermicro X12SDV-8CE-SP4F motherboard is designed to support

extended working temperatures with two 25GbE and two GbE ports. These motherboards

also feature onboard Trusted Platform Module (TPM) 2.0 headers for hardware-based security

function support. Note that this motherboard is intended to be installed and serviced by

professional technicians only. For processor/memory updates, refer to our website at http://

www.supermicro.com/products/.

Conventions Used in the Manual

Special attention should be given to the following symbols for proper installation and to prevent

damage done to the components or injury to yourself:

Warning! Indicates high voltage may be encountered while performing a procedure.

Warning! Indicates important information given to prevent equipment/property damage

or personal injury.

Important: Important information given to ensure proper system installation or to

relay safety precautions.

Note: Additional Information given to di󰀨erentiate various models or to provide in-

formation for proper system setup.
