P cackage ontents
X12stn-H/-e/-L/-c
X12stn-H/-e/-L/-c-WoHs
Q R g 1.00uick efeRence uide
• One Supermicro Motherboard
with Passive Heatsink
• One SATA Data Cable
• One SATA Power Cable
• One USB 2.0 Cable
• Website: www.supermicro.com
• General Information: marketing@supermicro.com
• Technical Support: support@supermicro.com
• Phone: +1 (408) 503-8000, Fax: +1 (408) 503-8008
F or your system to work properly please download appropriate,
drivers images user s manual From the links below/ / ' :
MNL-2395-QRG-100
• One Audio Cable
• One COM Port Cable
• One Quick Reference Guide
• One DC IN Power Cable
WARNING: This product can expose you to chemicals including
lead, known to the State of California to cause cancer and birth
defects or other reproductive harm. For more information, go
to www.P65Warnings.ca.gov.
!
JPME2
JMD1
JMD2
JMD3
JSIM1
SRW3
JSMBUS1
X12STN-C
REV: 1.10
JPT1
DIMMB1
DIMMA1
DESIGNED IN USA
SRW5
SRW1
SRW2
SRW4
LED Indicators
SO-DIMM Memory Installation
CPU and Memory Support
Note: Graphics shown in this quick reference guide are for illustration only. Your components may or may not look exactly the same as drawings shown in this
guide.
Note: Refer to Chapter 1 of the User Manual for detailed information on jumpers, connectors,
and LED indicators.
Note: Refer to Chapter 2 of the User Manual for detailed information on memory support and CPU/
motherboard installation instructions.
Front Control Panel (JF1)
1
5
1
4
1
3
1
7
1
21
6
X12STN-H/-H-WOHS supports 11th Generation Intel® Core™ i7-1185GRE
X12STN-E/-E-WOHS supports 11th Generation Intel Core™ i5-1145GRE
X12STN-L/-L-WOHS supports 11th Generation Intel Core™ i3-1115GRE
X12STN-C/-C-WOHS supports 11th Generation Intel CELERON 6305E
The X12STN-H/-E/-L/-C-WOHS motherboard supports up to 64GB of DDR4
3200MHz SO-DIMM in two memory slots.
87
3.3V Stby
3.3V HDD LED
Power LED
21
Reset Button
Power Button
Ground
Ground
Connector Description
AUDIO FP Front Panel Audio Header (Mic-In/Line-Out)
BT1 Battery Connector (To Clear CMOS, remove the battery, short pins 1-2 for 10
seconds and install the battery.)
FAN1 System Fan Header
I-SATA0 SATA 3.0 Port
JCOM1: COM1/COM2 COM Header (two RS232/RS422/RS485)
JCOM2: COM3/COM4 COM Header (two RS232 ports)
JF1 Front Control Panel Header (Power/HDD LED, Reset, Power button)
JGP1 8-bit General Purpose I/O Header
JHDMI1 Back Panel HDMI 2.0b Port
JHDMI2 Back Panel HDMI 1.4b Port
JMD1 M.2 Slot B-KEY 2280/2242/3042 (SATA 3.0 or PCIe/USB 3.1/USB 2.0)
JMD2 M.2 Slot E-KEY 2230 (PCIe/USB 2.0/CVNi)
JMD3 M.2 Slot M-KEY 2280/2242 (PCIe Gen4 x4)
JPH1 4-pin HDD Power Connector
JPW1 8-pin 12-24V Power Connector
JSIM1 JSIM1 Nano SIM Card Slot (bottom side)
JSMBUS1 System Management Bus Header
JSPKR1 Audio-Out Speaker with 3W Amplier
LAN1, LAN2 2.5 Gigabit Ethernet Ports
LVDS1 Dual Channel 48-bit LVDS Connector
SRW1 ~ SRW5 M.2 Mounting holes
USB0/1 Front Accessible USB 2.0 Headers
USB2/3 Front Accessible USB 2.0 Headers
USB5 Back Panel USB 3.1 Type C Port (supports DP1.4a with Alt. Mode)
USB4/6/7 Back Panel USB 3.1 Type A Ports
# #Denition Description
1 5LAN1 USB5 (3.1 Type C)
2 6LAN2 USB6/7 (3.1)
3 7HDMI 2.0 HDMI 1.4
4 USB4 (3.1)
= mounting hole
CPU
JHDMI1
BT1
MH4
USB0/1
USB2/3
MH2
JSPKR1
AUDIO FP
I-SATA0
JPH1
JCOM2JCOM1
LVDS1
MH3
JLCDPWR1
JPW1
FAN1
MH1
JHDMI2 JGP1
JF1
LAN1LAN2
LED1
USB4/5 (3.1)
USB6/7 (3.1)
JSIM1_OPT
Align
1. Position the SO-DIMM module's bottom key so it aligns with the receptive
point on the slot.
2. Insert the SO-DIMM module vertically at about a 45-degree angle. Press
down until the module locks into place. The side clips will automatically
secure the SO-DIMM module, locking it into place.
Insert this end rst
Locking Clip
SO-DIMM Removal
1. Push the side clips at the end of slot to release the SO-DIMM module.
Pull the SO-DIMM module up to remove it from the slot.
Back Panel I/O Connectors
Bottom Layout and Mechanical Drawing
Top Layout and Mechanical Drawing
1
1
Connectors
Indicator Description Indicator Setting
LED1 Onboard Power LED
Green: System On
Red: S5 or main power fail
Off: System Off (Power cable not connected)
Jumper Description Default Setting
JLCDPWR1 LVDS Panel Power Source
Selection
Pin 1-3* (3.3V)
Pin 3-5 (5V)
Pin 3-4 (12V)
JPME2 CMOS Pin 1-3* (Normal)
Pin 3-5 (Clear CMOS)
JPME2 Manufacturing Mode Pin 2-4 (Manufacturing Mode)
Pin 4-6* (Normal)
JPT1 TPM Pin 1-3* (Enable)
Pin 3-5 (Disable)
JPT1 Force Power On Pin 2-4* (Force power on)
Pin 4-6 (Power button power on)
JSIM1_OPT SIM Detect Option Pin 2-4* (Normal)
Pin 4-6 (Low Activity)
Jumpers
Jumpers, Connectors & LED IndicatorsMotherboard Layouts and Mechanical Drawings
