SUPERMICR R
ContaCt nformatIon I
Manuals: http://www.supermicro.com/support/manuals
Drivers & Utilities: https://www.supermicro.com/wdl/driver/
Safety: http://www.supermicro.com/about/policies/safety_information.cfm
© 2023 Supermicro Computer Inc. All rights reserved. Reproduction of this document whether in part or in whole is strictly prohibited without Supermicro's written
consent. All Trademarks are property of their respective entities. All information provided is deemed accurate at the time of printing; however, it is not guaranteed.
P CaCkage ontents
X13seeD-f/-sf
Q r g 1.00uICk eferenCe uIDe
One Supermicro Motherboard
One Quick Reference Guide
Website: www.supermicro.com
General Information: marketing@supermicro.com
Technical Support: support@supermicro.com
Phone: +1 (408) 503-8000, Fax: +1 (408) 503-8008
f or your system to work ProPerly Please DownloaD aPProPrIate,
DrIvers Images user s manual from the lInks below/ / ' :
MNL-2504-QRG-100
WARNING: This product can expose you to chemicals including
lead, known to the State of California to cause cancer and birth
defects or other reproductive harm. For more information, go
to www.P65Warnings.ca.gov.
!
PRESS FIT
JSPD1
JVRM1
JDBG1
JBR1
JB1
JPME2
JPWR1
MH2MH1
FAN4 FAN3
JMD1
MT1_1
MT1_2
MH7
JTPM1
JP2
JIPMB1
JP13
JPFR2
JPT1
JBM1
JP1
JPFR3
JPFR1
JCP1
JL1
MH10
MH11
JKVM1
LED3-1 LED3
JUIDB2
LED2
LED1
MH12
LED7 LED6
JLAN1
SW2
MH9
JSXB1A
MH8
JSXB1B
JSXB2
JSXB1C
MH6 MH5
BT1
JMD2
FAN1
FAN2
MH4MH3
CPU
DIMMA1
DIMMB1
DIMMC1
DIMMD1
DIMMH1
DIMMG1
DIMMF1
DIMME1
JPL1
2280
22110
MT2_1
MT2_2
2280
22110
BIOS
LICENSE
BAR CODE
LED4
X13SEED-F
REV:1.01
DESIGNED IN USA
PCH
BMC
JNCSI1
JBT1
JRK1
DIMM Memory Installation
CPU Installation
Jumpers, LED Indicators and ConnectorsMotherboard Layout and Features
Note: Graphics shown in this quick reference guide are for illustration only. Your components may or may not look exactly the same as drawings shown in this
guide.
Note: Refer to Chapter 1 of the User Manual for detailed information on jumpers, connectors,
and LED indicators.
Note: Refer to Chapter 2 of the User Manual for detailed information on memory support and CPU/
motherboard installation instructions.
Memory and CPU Support
The X13SEED-F/-SF motherboard supports up to 2TB of ECC DDR5
RDIMM/3DSRDIMM with speeds of up to 4800 MT/s.
Insert the desired number of DIMMs into memory slots based on the recom-
mended memory population sequence below. For the system to function properly,
use memory modules of the same type and speed.
The X13SEED-F/-SF motherboard supports a 4th Generation Intel® Xeon Scal-
ablProcessor with up 350W TDP in an LGA4677 socket.
Connector Description
BT1 Onboard Battery
FAN1–FAN4 CPU/System Fan Headers (FAN1: CPU Fan)
JIPMB1 4-Pin External I²C Header for an IPMI Card
JKVM1 KVM Connector (supports USB0/1, COM1, VGA)
JLAN1 RJ45 GbE (X13SEED-F)
1G SFP (X13SEED-SF)
JMD1 M.2 M-Key PCIe 5.0 Slot (2280/22110)
JMD2 M.2 M-Key PCIe 5.0 Slot (2280/22110)
JNCSI1 NC-SI Interface for IPMI Shared LAN Function
JRK1 Intel RAID Key Header
JSXB1A/B/C PCIe 5.0 p1-x32 Right Riser Slot with FH/HL PCIe card support
JSXB2 PCIe 5.0 p1-x16 Left Riser Slot with LP PCIe card support
JTPM1 Trusted Platform Module (TPM)/Port 80
JPWR1 Power Connector (for backplane power connector)
SW2 Power Button
Jumper Description Default
JBT1 CMOS Clear Open (Normal)
JBM1 IPMI Shared LAN Enable/Disable Pins 1-2 (Enabled)
JPL1 LAN1 Enable/Disable Pins 1-2 (Enabled)
JPT1 Onboard TPM 2.0 Enable/Disable Pins 1-2 (Enabled)
LED Description Status
LED1 Onboard Power LED Solid Green: Power On
LED2 Power/Fan Fail LED Solid Red: Power/Fan Failed
LED3 BMC Heartbeat LED Blinking Green: BMC Normal
LED4 Unit Identier LED Solid Blue: Unit Identied
LED6 RJ45 Port Activity
(X13SEED-F) Yellow: Port Activity
LED7 RJ45 Link
(X13SEED-F)
Solid Green: 100 Mb/s
Solid Amber: 1 Gb/s
LED8 SFP LED
(X13SEED-SF)
Yellow (Top): 1 Gb/s Link
Yellow (Bottom): Activity
Rear Panel I/O Connectors (X13SEED-F) Rear Panel I/O Connectors (X13SEED-SF)
LED Indicators
Jumpers
Connectors
# #Description Description
1. 4.UID Switch Power Button
2. KVM Port
3. LAN1 (RJ45)
# #Description Description
1. 4. LED8UID Switch
2. 5.KVM Port Power Button
3. LAN1 (SFP)
1
1
1
2
1
3
Assemble the processor carrier assembly by inserting the CPU into
the processor carrier.
To form the processor heatsink module (PHM), mount the
processor carrier assembly onto the heatsink and snap into place.
After assembling the PHM, mount it onto the CPU socket of the
motherboard. Use a T-30 Torx-bit screwdriver to gradually install
four screws into the mounting holes from #1-4.
A
B
T30 Torx Screwdriver
Use a torque
of 12 lbf-in
Printed Triangle
Pin 1
Press the rotating wires outwards to latch
the PHM and then tighten e four screws.th
Airflow direction
Mount the Processor Heatsink Module
onto the CPU socket (on the motherboard).
1 14 4 53 32 2
= mounting hole
Number of DIMMs Memory Population Sequence
1DIMMA1
DIMME1
2DIMMA1 / DIMMG1
DIMME1 / DIMMC1
4 DIMMA1 / DIMMC1 / DIMME1 / DIMMG1
6
DIMMA1 / DIMMC1 / DIMMD1 / DIMME1 / DIMMF1 / DIMMG1
DIMMA1 / DIMMB1 / DIMMC1 / DIMME1 / DIMMG1 / DIMMH1
DIMMB1 / DIMMC1 / DIMMD1 / DIMME1 / DIMMF1 / DIMMH1
DIMMA1 / DIMMB1 / DIMMD1 / DIMMF1 / DIMMG1 / DIMMH1
8 DIMMA1 / DIMMB1 / DIMMC1 / DIMMD1 / DIMME1 / DIMMF1 / DIMMG1 / DIMMH1
