DVD Stereo System

Operating Instructions

Model No. SC-DV290

Note

“EB” on the outer packaging indicates the

United Kingdom.

Before connecting, operating or adjusting

this product, please read these instructions

completely. Please keep this manual for fu-

ture reference.

RQT6894-B

The illustration shows the model for the United Kingdom, Continental Europe and Russia.

For the United Kingdom and

Continental Europe

pThe region number of this player is “2”.

pThe player will play DVD-Video marked with

labels containing “2” or “ALL”.

Example:

For Australia and N.Z.

pThe region number of this player is “4”.

pThe player will play DVD-Video marked with

labels containing “4” or “ALL”.

Example:

For Russia

pThe region number of this player is “5”.

pThe player will play DVD-Video marked with

labels containing “5” or “ALL”.

Example:

2ALL

Region number supported by

this player

Region numbers are allocated to DVD players and

software according to where they are sold.

4ALL

ALL

RQT6894

Before use

System

Sound processor

Stereo tuner/amplifier

DVD/Video CD/CD changer

Stereo cassette deck

Supplied accessories

Please check and identify the supplied acces-

sories. Use numbers indicated in parentheses

when asking for replacement parts.

uAC mains lead . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1

For the United Kingdom For Australia and N.Z.

(RJA0053-3X) (RJA0035-2X)

For Continental Europe and Russia

(RJA0019-2X)

Note

The included AC mains lead is for use with this unit only. Do not use

it with other equipment.

uRemote control . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1

For the United Kingdom, For Australia and N.Z.

Continental Europe and Russia (EUR7702300)

(EUR7702290)

uRemote control batteries . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2

uFM indoor antenna . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1

For the United Kingdom, For Australia and N.Z.

Continental Europe and Russia (RSA0006-J)

(RSA0007)

uAM loop antenna set: (RSA0022-L) . . . . . . . . . . . . . . . . . . . . . 1

uSpeaker leads

(REE1234-1) . . . . . . . . . . 2 (REE1233-1) . . . . . . . . . . 2

(Red/Black) (Gray/Blue)

uAntenna plug adaptor: (SJP9009) . . . . . . . . . . . . . . . . . . . . . . 1

(Only for the United Kingdom)

uVideo cord

For the United Kingdom and Continental Europe

(VJA0815-A) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1

For Russia (RJL1P019B15) . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1

For Australia and N.Z. (RJL1P019B15) . . . . . . . . . . . . . . . . . . . . 2

uRCAJ adaptor: (VFA0151-2) . . . . . . . . . . . . . . . . . . . . . . . . . . . 1

(Only for the United Kingdom, Continental Europe and Russia)

Dear customer

Thank you for purchasing this product.

For optimum performance and safety, please read these instructions care-

fully.

Front

Center

Surround

Speakers

SC-DV290

SH-DV290

SA-DV290

SL-DV290

RS-DV290

SB-DV290

SB-PC95

SB-PS95

www.panasonic.co.uk (for UK customers only)

Order accessory and consumable items for your

product with ease and conﬁdence by telephoning our

Customer Care Centre Mon–Friday 9:00am–5:30pm.

(Excluding public holidays.)

Or go on line through our Internet Accessory ordering

application.

Most major credit and debit cards accepted.

All enquiries transactions and distribution facilities are

provided directly by Panasonic UK Ltd.

It couldn’t be simpler!

Customer Care Centre

For UK customers: 08705 357357

For Republic of Ireland customers: 01 289 8333

Technical Support

For UK customers: 0870 1 505610

This Technical Support Hot Line number is for

Panasonic PC software related products only.

For Republic of Ireland, please use the Customer Care

Centre number listed above for all enquiries.

For all other product related enquiries, please use the

Customer Care Centre numbers listed above.

For United Kingdom and Republic of Ireland

Unless otherwise indicated, illustrations in these operating in-

structions are of the system for the United Kingdom, Continen-

tal Europe and Russia.

RQT6894

Before use

Table of contents

Before use

Safety precautions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . c3

Maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . c3

Cassette tape selection and care . . . . . . . . . . . . . . . . . . . . c3

Caution for AC Mains Lead . . . . . . . . . . . . . . . . . . . . . . . . . c4

Disc information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . c5

Simple setup . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6

Control guide and preparatory steps

Front panel controls . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10

Turning DEMO off . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11

The remote control . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12

Setting the time . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12

QUICK SETUP . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13

Basic operations

Discs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14

Skip function/Search function/Slow-motion play . . . . . . . . . . . . . . . . 15

Frame-by-frame viewing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15

Position Memory function/Selecting groups to play . . . . . . . . . . . . . . 16

Soundtracks/Subtitles/Cinema . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17

Marking places to play again/Variable Zoom function . . . . . . . . . . . . 18

Repeat play/A-B repeat play/All group play . . . . . . . . . . . . . . . . . . . . 19

Program play . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20

Random play/ALL DISC play. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21

Starting play from a selected item . . . . . . . . . . . . . . . . . . . . . . . . . . . 21

Playing the programs or play lists on DVD-RAM . . . . . . . 22

Navigation menus . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22

Using GUI screens . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24

The radio: manual tuning . . . . . . . . . . . . . . . . . . . . . . . . . . 27

The radio: preset tuning . . . . . . . . . . . . . . . . . . . . . . . . . . . 28

Cassette tapes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29

Changing sound field and quality

Boosting the super woofer . . . . . . . . . . . . . . . . . . . . . . . . . 30

Using the super sound equalizer . . . . . . . . . . . . . . . . . . . . 30

Double re-master—Enjoying more natural sound . . . . . . 30

Changing sound field and quality . . . . . . . . . . . . . . . . . . . 30

Using the acoustic image equalizer (AI EQ) . . . . . . . . . . . . . . . . . . . 31

Using the manual equalizer (M.EQ) . . . . . . . . . . . . . . . . . . . . . . . . . 31

Enjoying surround sound . . . . . . . . . . . . . . . . . . . . . . . . . . 32

Surround effects . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34

Recording operations

Before recording (Deck 2 only) . . . . . . . . . . . . . . . . . . . . . . 35

Recording discs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36

Recording the radio . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37

Tape-to-tape recording . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37

Timer operations and convenient functions

Using the timers . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38

Changing the sound range display . . . . . . . . . . . . . . . . . . 41

Muting the volume . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 41

Using headphones (not included) . . . . . . . . . . . . . . . . . . . 41

Enjoying karaoke (For Australia and N.Z.) . . . . . . . . . . . . 42

External unit connections . . . . . . . . . . . . . . . . . . . . . . . . . . 44

Optional antenna connections . . . . . . . . . . . . . . . . . . . . . . 45

Using other equipment . . . . . . . . . . . . . . . . . . . . . . . . . . . . 45

Changing settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 46

Reference

Glossary . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 48

Technical specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . 49

Troubleshooting guide . . . . . . . . . . . . . . . . . . . . . . . . . . . . 50

Safety precautions

Placement

Set the unit up on an even surface away from direct sunlight, high tem-

peratures, high humidity, and excessive vibration. These conditions can

damage the cabinet and other components, thereby shortening the unit’s

service life.

Do not place heavy items on the unit.

Voltage

Do not use high voltage power sources. This can overload the unit and

cause a fire.

Do not use a DC power source. Check the source carefully when setting

the unit up on a ship or other place where DC is used.

AC mains lead protection

Ensure the AC mains lead is connected correctly and not damaged. Poor

connection and lead damage can cause fire or electric shock. Do not pull,

bend, or place heavy items on the lead.

Grasp the plug firmly when unplugging the lead. Pulling the AC mains

lead can cause electric shock.

Do not handle the plug with wet hands. This can cause electric shock.

Foreign matter

Do not let metal objects fall inside the unit. This can cause electric shock

or malfunction.

Do not let liquids get into the unit. This can cause electric shock or mal-

function. If this occurs, immediately disconnect the unit from the power sup-

ply and contact your dealer.

Do not spray insecticides onto or into the unit. They contain flammable

gases which can ignite if sprayed into the unit.

Service

Do not attempt to repair this unit by yourself. If sound is interrupted, indi-

cators fail to light, smoke appears, or any other problem that is not covered

in these instructions occurs, disconnect the AC mains lead and contact your

dealer or an authorized service center. Electric shock or damage to the unit

can occur if the unit is repaired, disassembled or reconstructed by unquali-

fied persons.

Extend operating life by disconnecting the unit from the power source if it

is not to be used for a long time.

Maintenance

If the surfaces are dirty

To clean this unit, wipe with a soft, dry cloth.

pNever use alcohol, paint thinner or benzine to clean this unit.

pBefore using chemically treated cloth, read the instructions that came with

the cloth carefully.

For a cleaner crisper sound

Clean the heads regularly to assure good quality playback and recording.

Use a cleaning tape (not included).

Cassette tape selection and care

The unit can correctly play or record on the following types. It identifies the

type automatically.

pTapes exceeding 100 minutes are thin and can break or get caught in the

mechanism.

pTape slack can get caught up in the mechanism and should be taken up

before the tape is played.

pEndless tapes can get caught up in the deck’s moving parts if used incor-

rectly. Use tapes appropriate to this unit’s auto-reverse mechanism.

✔

Normal position/TYPE I

High position/TYPE II

Metal position/TYPE IV

Produktspecifikationer

Varumärke:	Technics
Kategori:	hi-fi system
Modell:	SC-DV290
Färg på produkten:	Zwart, zilver
Vikt:	50 g
Bredd:	68 mm
Djup:	98 mm
Höjd:	9.8 mm
Förpackningens vikt:	100 g
Förpackningens bredd:	130 mm
Djuppackning:	160 mm
Förpackningshöjd:	30 mm
Husmaterial:	Plastic, Steel
Kompatibla minneskort:	CFast, CFast 2.0
Snabbstartsguide:	Ja
Certifiering:	CE, FCC, RoHS
Material:	Plastic, Steel
Hållbarhetscertifikat:	RoHS
Förvaringstemperatur:	-40 - 85 °C
Internera:	Nee
Snabbinstallationsguide:	Ja
Medeltid mellan fel (MTBF):	50000 uur
Värdgränssnitt:	SATA
Typ av anslutning:	SATA
Inklusive skruvar:	Ja
Överföringshastighet:	6000 Mbit/s
Drifttemperatur (TT):	0 - 75 °C
Relativ luftfuktighet i drift (VV):	5 - 95 procent
Harmoniserad systemkod (HS):	84733020
Dataöverföringshastighet (max):	6 Gbit/s
Utgångsgränssnitt:	CFast
Stöd för lagringsenhetshöjder:	3.3, 5 mm
Stöd för enhetsfack:	2.5 "
SATA-kontaktens ingångscykler:	10000
Höjddrivanordning:	3.3 mm
