Sida 1/72

Safe Operation Practices • Assembly • Operation • Service And Maintenance

OperatOr’s anual M

Form No. 769-22911

(October 30, 2019)

Self Propelled Mower

NOTE: This Operator’s Manual covers several models. Features may vary by model. Not all features in this manual are

applicable to all models and the model depicted may differ from yours.

WARNING

Read and follow all safety rules and instructions in this manual before attempting to operate this

machine.

Failure to comply with these instructions may result in personal injury - SAVE THESE INSTRUCTIONS.

WARNING

CALIFORNIA PROPOSITION 65

Engine Exhaust, some of its constituents, and certain vehicle components contain or emit chemicals

known to State of California to cause cancer and birth defects or other reproductive harm.

Record Product Information

Before setting up and operating your new

mower, please locate the model plate on the

equipment and record the information in the

provided area to the right. You can locate the

model plate by standing at the operator’s

position and looking down at the rear of the

deck. This information will be necessary, should

you seek technical support via our web site,

Customer Support Department, or with a local

authorized service dealer.

Model Number

Serial Number

English ......................................................................................................................................Page 2

Spanish (Español) ....................................................................................................................Page 24

French (Français) ......................................................................................................................Page 48

SAFE OPERATION PRACTICES

GENERAL INFORMATION

1. Read, understand, and follow all instructions on the mower

and in the manual(s) before attempting to assemble and

operate. Keep this manual in a safe place for future and

regular reference and for ordering replacement parts.

2. Be familiar with all controls and their proper operation.

3. Never allow children under 14 years of age to operate this

mower. Children 14 and over should read and understand

the instructions and safe operation practices in this manual

and on the mower and should be trained and supervised by

an adult.

4. Never allow adults to operate this mower without proper

instruction.

5. Store mower in a dry, clean area. Do not store next to

corrosive materials, such as fertilizer.

6. If situations occur which are not covered in this manual, use

care and good judgment. Contact your customer service

representative for assistance.

7. According to the U.S. Consumer Products Safety Commission

(CPSC) and the U.S. Environmental Protection Agency (EPA),

this product has an estimated useful life of seven (7) years,

under ordinary use conditions. At the end of its useful life,

have the product inspected annually to ensure all mechanical

and safety systems are operating properly, safely, and are

not worn excessively. Failure to do so may result in accident,

injury, or death.

PREPARATION BEFORE OPERATING

1. Thoroughly inspect the area where the mower is to be used.

Remove all stones, sticks, wire, bones, toys, and other foreign

objects which could be tripped over or picked up and thrown

by the blade(s). Thrown objects can cause serious personal

injury.

2. To help avoid blade contact or a thrown object injury, stay in

the operator zone behind the mower handles. Keep helpers

at least 75 feet (23 meters) from the mower while it is in

operation. Keep bystanders, children and pets inside while

the mower is in operation. Stop mower if anyone enters the

area.

3. Be aware of the mower and attachment discharge direction

and do not point the mower discharge at anyone.

4. Always wear safety glasses or safety goggles during

operation and while performing an adjustment or repair to

protect your eyes. Thrown objects which ricochet can cause

serious injury to the eyes.

5. Wear sturdy, rough-soled work shoes and close-fitting slacks

and shirts. Loose fitting clothes, jewelry and long hair can be

caught in moving parts. Shirts and pants that cover the arms

and legs and steel-toed shoes are recommended.

6. Never operate mower in bare feet, sandals, slippery or light-

weight (e.g. canvas) shoes.

7. Never over fill fuel tank. Fill tank to no more than 1” (2.5 cm)

below bottom of filler neck to allow space for fuel expansion.

8. Replace gasoline cap and tighten securely.

9. Use only accessories and attachments approved for this

mower by the mower manufacturer. Read, understand and

follow all instructions provided with the approved accessory

or attachment.

OPERATING

1. Data indicates that operators, age 65 years and above, are

involved in a large percentage of mower-related injuries.

These operators should evaluate their ability to operate the

mower safely enough to protect themselves and others from

serious injury.

2. Many injuries occur as a result of the mower being pulled

over the foot during a fall caused by slipping or tripping. Do

not hold on to the mower if you are losing your balance or

footing; immediately release the handle.

3. Never pull the mower back toward you while you are walking.

If you must back the mower away from a wall or obstruction

first look down and behind to avoid tripping and then follow

these steps:

a. Step back from mower to fully extend your arms.

b. Be sure you are well balanced with sure footing.

c. Pull the mower back slowly, no more than half way

toward you.

d. Repeat these steps as needed.

WARNING

This symbol points out important safety instructions which, if not followed, could endanger the personal

safety and/or property of yourself and others. Read and follow all instructions in this manual before

attempting to operate this machine. Failure to comply with these instructions may result in personal injury.

When you see this symbol, HEED ITS WARNING!

DANGER

This machine was built to be operated according to the safe operation practices in this manual. As with any type of

power equipment, carelessness or error on the part of the operator can result in serious injury. This machine is capable of

amputating fingers, hands, toes and feet and throwing debris. Failure to observe the following safety instructions could

result in serious injury or death.

SAFE OPERATION PRACTICES

4. Do not engage the drive control (if equipped) while starting

engine.

5. The blade control is a safety device. Never attempt to bypass

its operation. Doing so makes the safety device inoperative

and may result in personal injury through contact with the

rotating blade. The blade control must operate freely in

both directions and automatically return to the disengaged

(off) position when released. The cutting blade continues

to rotate for up to three seconds after the blade control is

released. Never place any part of the body in the blade area

until you are certain the blade has stopped rotating.

6. If the mower should start to vibrate abnormally, stop the

engine and check immediately for the cause. Vibration is

generally a warning of trouble.

7. Never operate mower without the proper trail shield,

discharge cover, grass catcher, blade control or other safety

protective devices in place and working. Never operate

mower with damaged safety devices. Failure to do so can

result in personal injury.

8. When starting engine, pull cord slowly until resistance is felt,

then pull rapidly. Rapid retraction of starter cord (kickback)

will pull hand and arm toward engine faster than you can let

go. Broken bones, fractures, bruises or sprains could result.

9. Do not put hands or feet near rotating parts or under the

cutting deck. Contact with the blade(s) can amputate hands

and feet.

10. Watch for holes, ruts, bumps, rocks, or other hidden objects.

Uneven terrain or hidden objects could cause a slip and/or

trip accident. Tall grass can hide obstacles.

11. Your mower is designed to cut normal residential grass of a

height no more than 7” (17.5 cm). Do not attempt to mow

through unusually tall, dry grass (e.g., pasture) or piles of

dry leaves.

12. Plan your mowing pattern to avoid discharge of material

toward roads, sidewalks, helpers and the like. Avoid

discharging material against a wall or obstruction which

may cause discharged material to ricochet back toward the

operator.

13. Shut the engine off and wait until the blade comes to

a complete stop before removing the grass catcher or

unclogging the chute. The cutting blade continues to rotate

for up to three seconds after the blade control is released.

Never place any part of the body in the blade area until

you are certain the engine is off and the blade has stopped

rotating.

14. A missing or damaged discharge door, chute or mulch plug

can cause blade contact or thrown object injuries.

15. Do not operate the mower without the discharge door, chute,

mulch plug or the entire grass catcher in its proper place.

16. Stop the mower blade when crossing gravel drives, walks, or

roads and while not cutting grass.

17. Mow only in daylight or good artificial light.

18. Do not operate the mower while under the influence of

alcohol or drugs.

19. The muffler and engine become very hot and can cause

serious burn injuries. Do not touch. Allow the mower to cool

for at least five minutes before storing or attempting any

service.

20. Never run an engine indoors or in a poorly ventilated area.

Engine exhaust contains carbon monoxide, an odorless and

deadly gas.

CHILDREN

1. Tragic accidents can occur if the operator is not alert to the

presence of children. Children are often attracted to the

mower and the mowing activity. They do not understand the

dangers. Never assume that children will remain where you

last saw them.

2. Keep bystanders, children and pets inside while the mower is

in operation under watchful care of a responsible adult other

than the operator. Stop mower if anyone enters the area.

3. Be alert and turn mower off if a child or bystander enters

the area.

4. Never allow children under 14 years of age to operate this

mower. Children 14 and over should read and understand

the instructions and safe operation practices in this manual

and on the mower and should be trained and supervised by

an adult.

5. This mower is a precision piece of power equipment, not a

plaything. Therefore, exercise extreme caution at all times.

This mower has been designed to perform one job: to mow

grass. Do not use it for any other purpose.

6. Use extreme care when approaching blind corners, doorways,

shrubs, trees or other objects that may block your vision of a

child who may run into the path of the mower.

7. Keep children away from hot or running engines. They can

suffer burns from a hot engine or muffler.

8. If your mower is equipped with an Electric Start Push Key,

remove the key when the mower is unattended to prevent

unauthorized operation. Make certain the key is inaccessible

to small children.

SLOPE OPERATION FOR WALK-BEHIND MOWERS

1. Slopes are a major factor related to slip and fall accidents

which can result in severe injury or death. All slopes require

extra caution. If you feel uneasy on the slope, do not mow it.

2. For your safety, measure any slope before using the mower

on the sloped area. Use a slope measuring device in addition

to the slope gauge included as part of this manual to measure

slopes before operating this mower on a sloped or hilly area.

Smart phone applications can be also utilized to measure

slopes. If the slope is greater than 15 degrees (25%) as shown

on the slope gauge or a slope measuring device, do not

operate this mower on that area or serious injury could result.

3. Do not mow on slopes greater than 15 degrees (25%).

Produktspecifikationer

Varumärke:	Troy-Bilt
Kategori:	Gräsklippare
Modell:	TB210

Behöver du hjälp?

Om du behöver hjälp med Troy-Bilt TB210 ställ en fråga nedan och andra användare kommer att svara dig

Ditt namn*

Din e-post*

Skriv din fråga här

Gräsklippare Troy-Bilt Manualer

Troy-Bilt TB490 XP Bruksanvisning

18 Oktober 2024

Troy-Bilt TB410 XP Bruksanvisning

15 Oktober 2024

Troy-Bilt Mustang Z54 XP Bruksanvisning

18 September 2024

Troy-Bilt TB300 XP Bruksanvisning

18 September 2024

Troy-Bilt TBWC23B XP Bruksanvisning

18 September 2024

Troy-Bilt TB18R Bruksanvisning

18 September 2024

Troy-Bilt TB16R Bruksanvisning

18 September 2024

Troy-Bilt TB280 ES Bruksanvisning

18 September 2024

Troy-Bilt Mustang Pivot S 54 Bruksanvisning

18 September 2024

Troy-Bilt TBWC28T Bruksanvisning

18 September 2024

Gräsklippare Manualer

Nyaste Gräsklippare Manualer

Masport President 1000ST Combo Bruksanvisning

27 Oktober 2024

Saturn ST-HC7381 Bruksanvisning

27 Oktober 2024

Viking MI 632 P Bruksanvisning

27 Oktober 2024

Baumr-AG 480ZRX Bruksanvisning

26 Oktober 2024

Honda HRH 536 HX Bruksanvisning

26 Oktober 2024

Alpina AL4 51 S Li Bruksanvisning

23 Oktober 2024

Al-ko Highline 42.5 P-A Bruksanvisning

22 Oktober 2024

Al-ko 5235 SP-A Bruksanvisning

22 Oktober 2024

Stiga Combi 55 SVQ H Bruksanvisning

21 Oktober 2024

Flymo SimpliGlide 360 Bruksanvisning

21 Oktober 2024
