F330•E340 OWNER'S MANUAL P. 2- 6

BETRIEBSANLEITUNG S. 7-12

MODE D'EMPLOI P. 13 -18

MANUALE D'USO P. 19 -24

MANUAL DEL USUARIO P. 25 -30

HANDLEIDING P. 31- 36

BRUKSANVISNING S. 37- 42

KÄYTTÖOHJE S. 43 - 48

www.tunturi.com

• SERIAL NUMBER • SERIENNUMMER

• NUMERO DE SERIE • NÚMERO DE SERIE

• NUMERO DI SERIE • SERIENUMMER

• SERIENNUMMER • SARJANUMERO

O W N E R ' S M A N U A L • F 3 3 0 • E 3 4 0

O W N E R ’ S M A N U A L

F 3 3 0 / E 3 4 0

I N F O R M A T I O N A N D

WA R N I N G S

Please read this owner’s manual through carefully

before assembling, using and servicing the

workout cycle! Follow the instructions described

in this manual carefully. The equipment has

been designed for home use. Please notice that

the warranty does not cover any damages due to

negligence of assembly, adjustment or maintenance

instructions described in this manual!

NOT E ABOU T YO U R HEALT H

• Before you start any training, consult a

physician to check your state of health.

• If you experience nausea, dizziness or other

abnormal symptoms while exercising, stop your

workout at once and consult a physician.

• To avoid muscular pain and strain, begin each

workout by warming up and end it by cooling

down (slow pedalling at low resistance). Don’t

forget to stretch at the end of the workout.

NOT E ABOU T T HE EXERC ISING

ENVIRONMENT

• The device is not to be used outdoors.

• Place the cycle on a ﬁ rm, level surface. Place the

machine on a protective base.

• Make sure that the exercising environment has

adequate ventilation. To avoid catching cold, do

not exercise in a draughty place.

NOT E ABOU T US ING T HE E Q UIPMENT

• If children are allowed to use the cycle, they

should be supervised and taught to use the cycle

properly, keeping in mind the child’s physical and

mental development and their personality.

• Before you start using the cycle, make sure that

it functions correctly in every way. Do not use a

faulty device.

• Only one person may use the cycle at a time.

• Hold the handlebar for support when getting on

or off the cycle.

• ar appropriate clothing and shoes when We

exercising.

• Press the key with the tip of your ﬁ nger; your

nails may damage the key membrane.

• Protect the meter from sunlight and always dry

the surface of the meter if there are any drops of

sweat on it.

• Do not attempt any servicing or adjustment

other than those described in this manual.

• The device must not be used by persons

weighing over 110 kg.

• F 330 / E 340 is designed for household use

only. The warranty of 24 months applies only for

faults in household use.

W E L C O M E T O T H E W O R L D

O F T U N T U R I E X E R C I S I N G !

Your choice shows that you really want to invest in

your well-being and condition; it also shows you

really value high quality and style. With Tunturi

Fitness Equipment, you’ve chosen a high quality,

safe and motivating product as your training

partner. Whatever your goal in training, we are

certain this is the training equipment to get you

there. You’ll ﬁ nd information about using your

exercise equipment and what makes for efﬁ cient

training at Tunturi’s website at www.tunturi.com.

A S S E M B LY

Check that the following parts are in the package:

1. Frame

2 . Rear support

3. Handlebar support tube

4. Meter

5. Pedals (2)

6. Seat

7. Assembly kit (contents marked with in the spare

part list): keep the assembly tools, as you may need

them e.g. for adjusting the equipment

8. F330 Workout kit (ﬁ tness mat, dumbbells,

exercise band, water bottle, exercise guide poster)

If necessary, contact the dealer and give the model,

serial number and the needed spare part number

from the spare part list in the back of the manual.

The package includes a silicate bag for absorbing

moisture during storage and transportation. Left,

right, front and back are as seen from the exercising

position. It is recommended that that installation is

carried out by two people.

REAR SU P PO RT

Lift the equipment frame e.g. on to the top of the

package and attach the rear support to the frame

with the four black washers and four black Allen

screws. Tighten the screws carefully crosswise.

Check after one hour of use that the screws are

tight.

G B

O W N E R ' S M A N U A L • F 3 3 0 • E 3 4 0

U P RIG H T P O S T

Connect the upper and lower meter wires together

and push the tension cable into the upright post

prior to ﬁ tting the upright post to the main frame.

Secure the upright post to the main frame with

four chromed washers and Allen screws. Ensure

that the concave side of the washer faces the

handlebar support tube. First turn all the screws

loosely into place and then tighten them.

RES IS TANC E KNOB

Make sure the display window shows 8 on the

knob. Remove the attachment screw and pull out

the resistance knob from upright post. Pull the

end of the resistance wire out from the handlebar

support tube and connect the resistance wire to

the lower end of the brake wire. Make sure the

resistance wire is tightly inserted. Push the wire

inside the handlebar support tube, place the

resistance knob over the hole in the tube and

attach it with the screw.

ME T ER

Pop open the battery cover at the back of the meter

to assemble batteries. Close the cover. Remove the

cable ties from the wires of the handlebar support.

Connect the wires to the respective connectors

on the meter and then thread the wires into the

handlebar. Be careful not to damage the wires

when attaching the interface. Slide the meter on

the top of the handlebar support tube and attach

it with three locking screws through the plastic

sleeve.

S E AT

Attach the seat to the seat support: tighten the

locking nuts in opposite directions. Please note

that you can adjust both seat inclination and the

distance of the seat from the handlebar. Once the

distance and inclination are set how you want,

tighten the locking nuts carefully.

chrome

E340

E340E340

black
