At Uniden, we'll take care of you!
Thank you for purchasing a Uniden product.
If you have any questions or problems,
please do not return this product to the place of purchase.
Having Trouble?
Our customer care specialists are here to help you! Visit our website at
www.uniden.com or call our Customer Hotline at 1-800-297-1023
during regular business hours.*
Need a Part?
To order headsets, additional handsets, replacement batteries or other
accessories, visit our website at www.uniden.com 1-800-554-3988 or call
during regular business hours.*
Help for our Special
Needs Customers
Uniden provides a customer service hotline for accessibility questions. If
you have disability and need customer service assistance or if you have any
questions about how Uniden's products can accommodate persons with
disabilities, please call the accessibility voice/TTY line:
1-800-874-9314 (voice or TTY).
Accessibility information can be found on our website, www.uniden.com,
under the "Accessibility" link. If your call is received outside of our business
hours, leave us a message and we will call you back.
* Central Standard Time. Detailed customer service hours are available at www.uniden.com.
©2007 Uniden America Corporation, Fort Worth, Texas.
Printed in China UCZZ01065BZ(0)
UNIDEN
CORDLESS
TELEPHONES
DXI8560 Series
1) Installing the Phone
1-1. Choosing the Best Location
To get the best performance out of your new phone, put it in the best location:
Near an AC outlet
and a telephone
wall jack.
• Microwave ovens
• Refrigerators
• Fluorescent
lighting
• Dust
• Excessive
moisture
• Other cordless
telephones
In a
centrally-located
open area.
PLACE YOUR BASE
• TVs
• Other electronics
• Direct sunlight
• Extreme temperatures
• Personal computers
• Wireless LAN
equipment
• Dust
• Excessive
moisture
• Areas with
a lot of
background
noise
• Shock
• Vibration
• Shock
• Vibration
TRY TO AVOID
Notes: For maximum range
Keep both the base and handset antennas free of obstruction.
When the handset is not in use, place the handset in an upright position.
Metal and reinforced concrete may aect cordless telephone performance.
•
•
•
1-2. Plug in the Battery
Use only the Uniden BT-905 rechargeable battery pack supplied with your phone.
1Locate the battery packs, battery
covers and the handsets. 2Line up the red and black wires
on the battery pack connector
with the sticker in the handset's
battery compartment.
3Place the cover over the
battery compartment and
slide it up into place.
Push the battery connector in firmly.
(You should hear it click into place.)
Red
Black
1Locate the battery packs, battery
covers and the handsets. 2Line up the red and black wires
on the battery pack connector
with the sticker in the handset's
battery compartment.
3Place the cover over the
battery compartment and
slide it up into place.
Push the battery connector in firmly.
(You should hear it click into place.)
Red
Black
1-3. Plug in the Base and Charging Cradle
You can put the charging cradles for additional handsets anywhere they can get power. They do not have to
connect to a phone line.
Don’t put any power cord where people might trip over it or step on it. If a power cord becomes
chafed or worn out, it can create a re or electrical hazard.
4Connect the base's AC adapter to the jack.DC IN 9V
Route the cord through the molded wiring channel.
6
5
Connect the base's
AC adapter to a standard
120V AC wall outlet.
DO NOT use an AC outlet
controlled by a wall switch.
7Connect the charging cradle's AC adapter to a standard 120V AC wall outlet.
Route the cord
To AC outlet
AC adapter
(supplied)
To AC outlet
AC adapter
(supplied)
To DC IN 9V
4Connect the base's AC adapter to the jack.DC IN 9V
Route the cord through the molded wiring channel.
6
5
Connect the base's
AC adapter to a standard
120V AC wall outlet.
DO NOT use an AC outlet
controlled by a wall switch.
7Connect the charging cradle's AC adapter to a standard 120V AC wall outlet.
Route the cord
To AC outlet
AC adapter
(supplied)
To AC outlet
AC adapter
(supplied)
To DC IN 9V
Note: For optimum battery life, charge all of your handsets completely before you connect the
telephone cord. The rst time you charge a new battery, allow 15 to 20 hours.
1-4. Connect the Telephone Cord
If you receive high-speed internet service through
your telephone line (referred to as DSL), you
should install a DSL lter between the telephone
base and the wall jack. Standard telephones
often can’t operate correctly without a DSL lter.
Test the connection
12 Make a quick test call, and then press to hang up.[END]
What if the call doesn't go through?
Check to see if your telephone provider uses pulse dialing.
(See section 3-1 on System Options.)
What if there is a lot of static?
Check the sources of interference described in section
1-1 on Choosing the best location: is the base near
any of those?
1-5. Register the Accessory Handsets
1-6. Things to Remember
When you charge the handsets, the Caller ID summary screen and the
name of the handset appear in the display.
Lots of people put HANDSET #1 in the base, but it doesn’t matter which
handset you put in the base and which one you put in the charging cradle.
Now your phone is ready to use!
1-7. Attach the Belt Clip
To attach the belt clip
Insert the tabs on the side of the belt clip into the holes on either side of the handset.
Press the belt clip down until it clicks into place. (Tug on the clip to make sure it’s secure.)
To remove the belt clip
Gently pull the tabs out of the holes, then slide the belt clip o of the handset.
•
•
8Place one handset in the base and the other in the charging cradle.
What if the charge LED doesn't
light up?
• Check AC adapter connection.
• Make sure you are not using
an outlet that's controlled by
a wall switch.
Make sure that the
/in use and LEDs
illuminate.
8Place one handset in the base and the other in the charging cradle.
What if the charge LED doesn't
light up?
• Check AC adapter connection.
• Make sure you are not using
an outlet that's controlled by
a wall switch.
Make sure that the
/in use and LEDs
illuminate.
9Connect the telephone cord to the
TEL LINE jack on the rear of the base.
10 Connect the telephone cord
to a telephone wall jack.
To telephone
wall jack
Telephone cord (supplied)
Note: If the telephone cord does not fit into your telephone wall jack, contact your
local phone provider for assistance.
To TEL LINE
9Connect the telephone cord to the
TEL LINE jack on the rear of the base.
10 Connect the telephone cord
to a telephone wall jack.
To telephone
wall jack
Telephone cord (supplied)
Note: If the telephone cord does not fit into your telephone wall jack, contact your
local phone provider for assistance.
To TEL LINE
Telephone
wall jack
Telephone cord
DSL filter
Telephone
wall jack
Telephone cord
DSL filter
11 Pick up the handset from the base and press .[TALK/flash]
You should hear a dial tone, and the display should show TALK.
What if I can't hear a dial tone?
Check the telephone cord connection on the base.
What if the display doesn't show TALK?
Put the handset back in the base for at least five seconds.
Make sure the LED flashes. /in use
Talk 0:01
11 Pick up the handset from the base and press .[TALK/flash]
You should hear a dial tone, and the display should show TALK.
What if I can't hear a dial tone?
Check the telephone cord connection on the base.
What if the display doesn't show TALK?
Put the handset back in the base for at least five seconds.
Make sure the LED flashes. /in use
Talk 0:01
13
14
One by one, put each additional handset in the base.
The LED should flash as the base recognizes the handset. /in use
Wait at least five seconds, then pick up the handset and press
[TALK/flash]. Make sure you can get a dial tone on each handset.
What if the LED/in use
doesn't flash?
Pick the handset up and put it back
in the base.
13
14
One by one, put each additional handset in the base.
The LED should flash as the base recognizes the handset. /in use
Wait at least five seconds, then pick up the handset and press
[TALK/flash]. Make sure you can get a dial tone on each handset.
What if the LED/in use
doesn't flash?
Pick the handset up and put it back
in the base.
HS1
New :01
Total:17
HS1
New :01
Total:17
