UH5000

Mini Compact

UHF CB Transceiver

For more exciting new products please visit our website:

Australia: www.uniden.com.au

Introduction 3

Controls & Connectors 4

Indicators 6

Included with your UH5000 Transceiver 7

Connecting the Microphone 8

Mounting the MIC Hanger 9

Operation 10

Turning on the Power 10

Setting the Squelch Level 10

Monitor 12

Selecting a Channel 12

Programming the Instant Priority Channel 12

Recalling the Instant Channel 13

Transmitting 13

Call Function 13

Using Repeater Channels 13

Operating the UHF CB Radio in Duplex Mode 15

Scanning 15

Open Scan (OS) Mode 16

Group Scan (GS) Mode & Priority Watch 16

Add/Remove Channels from SCAN Memory 17

CTCSS & DCS 17

Busy Channel Lockout 18

Selecting the Call tone 18

Roger Beep 19

Beep On/Off 19

Backlight Colours 19

Backlight Brightness 20

LCD Flip 20

CTCSS Codes Table 21

DCS Codes Table 22

UHF CB Channel Guidelines 23

UHF CB Channels & Frequencies 24

Warranty 26

Contents

UNIDEN UH5000 UHF CB Transceiver

The Uniden UH5000 is designed to provide you with years of trouble

free service. Its rugged components and materials are capable of

withstanding harsh environments. Please read this Operating Manual

carefully to ensure you gain the optimum performance of the unit.

NOTE

The citizen band radio service is licenced in Australia by

ACMA Radio-communications (Citizen Band Radio Stations)

Class Licence and in New Zealand by MED General User

Licence for Citizen Band Radio and operation is subject to

conditions contained in those licenses.

Features

• NarrowBand(NB)80Channel

Radio*

• 12VDCPowerInput

• Built-inAVSCircuitry†

• Transmissionpower5W

• LCDdisplay

• SignalstrengthandRFpower

(S/RF) meter

• Instantchannelprogramming

• OnetouchInstantchannel

recalling

• Selectablescanningtypefrom

group scan (GS) and open scan

(OS).

• ScanchannelmemoryOn/Off

function separately divided into

OS and GS

• MonitorOn/Offfunction

• Duplexcapability*

• KeyBeepOn/Offfunction

• RotaryChannelselectknob

• BusyChannellock-outfunction

• RogerbeepfunctionOn/Off

• 5differentCALLTones

• 38builtinCTCSS(Continuous

Tone Coded Squelch System)

 codesand104DCS(Digital

Coded Squelch) are selectable

• Autosquelchdetection

 thresholdcontrol(“oF”,“1”~“9”)

• Volumecontrol(“oF”,“1”~“40”)

• PowerOn/OffcontrolSW

• OptionalExternalSpeaker

• FlipLCDfunction

• 7LCD/KeyBacklightColour

Options

• 4LCD/KeyBacklightBrightness

Levels

• Underandovervoltagealert

function

* Refertop.23-p.25for

channel information

† AVS-AutomaticVolumeStabilizer

detects and manages incoming

audio to comparable levels.

Introduction

UNIDEN UH5000 UHF CB Transceiver
