Sida 1/16
vax.co.uk VRS17W
Vax Careline: (UK) 0844 412 8455
(ROI) 1-800 928 308
User Guide
Get cleaning...
What’s your Vax model number? (Located on the flap of the packaging)
What’s your serial number? (Located on the base of the machine)
Note these down in case you need them in future. Please keep instructions for further use.
– – – – –
e.g. VR S1 7 W
Carpet washer
Powermax
-------- ---
23
24
1 Handle
2 Handle screw
3 On/off switch
4 Clean water tank release
5 Clean water tank
6 Dirty water tank handle
7 Dirty water tank
8 Dirty water tank release
9 Dirty water tank lid
10 Static brushbar
11 Solution release trigger
12 Cord wrap
13 Upper hose wrap
14 Power cord
15 Carry handle
16 Cord release clip
17 Handle release pedal
18 Lower hose/tool caddy
19 Solution supply socket
20 Solution tube plug
21 Hose
22 Solution spray trigger
23 Hose adaptor
24 Wash tool
25 Vax carpet cleaning solution
26 Float chamber filter
2
Machine Overview
13
14
15
18
19
4
8
9
10
6
5
7
1
12
11
16
17
2
3
2221
SOLUTION
25
26
Unit
Accessories
20
vax.co.uk 3
General Safety Information
This carpet washer is intended for household use only and NOT
for commercial or industrial use.
PLEASE KEEP INSTRUCTIONS FOR FURTHER USE.
When using the carpet washer, basic safety precautions should
always be observed, including the following:
1. Do not leave the carpet washer unattended when
plugged in. Unplug the appliance from the socket
when not in use.
2. Only use the carpet washer indoors on dry surfaces.
3. Turn off all controls on the carpet washer before
disconnecting or connecting from the mains supply.
4. Always unplug the carpet washer before connecting
or disconnecting the vacuum hose and accessories.
5. Always unplug the carpet washer before carrying out
any maintenance.
6. Children should be supervised to ensure that they do
not play with the appliance.
7. This appliance is not intended for use by children
under eight years of age and persons with reduced
physical, sensory or mental capabilities or lack of
experience and knowledge, unless they have been
given supervision or instruction concerning use of
the appliance in a safe way and understands the
hazards involved.
8. Cleaning and maintenance shall not be made by
children without supervision.
9. The appliance should only be used as described in
the quick start guide or in the full online user guide.
10. Only Vax recommended attachments should be used
with this appliance.
11. Do not use this carpet washer if it has been dropped,
damaged, left outdoors or dropped into water. Do not
use this carpet washer with a damaged cord or plug.
If the supply cord is damaged return the carpet
washer to a Vax authorised Service Agent or a
suitably qualified person for examination, repair
or adjustment.
12. Do not pull or carry this appliance by the cord. Do not
use the cord as a handle, close a door on the cord or
pull the cord around sharp edges or corners. Do not
run the carpet washer over the cord. Keep the cord
away from heated surfaces.
13. Do not handle the plug or the carpet washer with
wet hands.
14. Keep hair, loose clothing, fingers and all parts of the
body away from openings and moving parts.
15. Do not pick up with the machine any hot coals,
cigarette butts, matches or any hot, smoking or
burning objects.
16. Do not pick up with the machine any flammable or
combustible materials (lighter fluid, petrol, kerosene
etc.) or use the machine in the presence of explosive
liquids or vapours.
17. Do not use the machine on areas where there may
be harmful or toxic material (chlorine, bleach,
ammonia, drain cleaner etc.)
18. Store the carpet washer in a cool, dry area.
19. Do not use an extension cord with this machine.
20. Do not carry the appliance while the motor is
still running.
21. To prevent dirty water from running into the motor,
do not hold the appliance upside-down or lay it on its
side. Use the appliance in a normal cleaning position.
22. Do not use without all water tanks and solution
tanks in place.
23. Do not use the carpet washer unless the carpets
have been dry vacuumed thoroughly first.
24. Keep the unit on the floor.
25. Do not put any objects into openings. Do not use
with any openings blocked and do not restrict
airflow. Keep all openings free of dust, lint, hair or
anything that might reduce airflow.
26. Do not attempt to remove blockages with sharp
objects as they may cause damage.
27. Using improper voltage may result in damage to the
motor and possible injury to the user. The correct
voltage is listed on the rating label.
28. Do not use without all of the filters in place.
29. Take extra care when cleaning on the stairs.
30. Keep the area you are cleaning well lit.
31. Do not unplug the machine by pulling on the cord.
WARNING: Always switch off and unplug the carpet washer from
the electrical outlet before assembling, filling and emptying the
clean water tank, emptying the dirt water tank, or before
connecting/disconnecting the attachments.
IMPORTANT: Carpets should be dry vacuumed thoroughly
before washing.
CAUTION: The carpet washer is a very powerful unit.
Before plugging the cord into the electrical outlet, make sure
all controls on the unit are turned off. Hold the carpet washer
firmly when starting and in use.
IMPORTANT: If the hose or tools are blocked, switch off the
carpet washer and remove the blockage(s) before re-starting
your machine.
IMPORTANT: Cleaning filters maintains cleaning performance.
Vax recommends that your filters should be checked and cleaned
periodically. If your filters are washable make sure that they are
completely dry before inserting them back into the vacuum cleaner.
IMPORTANT: The motor is equipped with a thermal cut-out. If for
any reason the unit should overheat, the thermostat will
automatically turn the unit off. Should this occur, unplug the carpet
washer from the electrical outlet and turn off the switch. Check the
hose for blockages. Clean the filters. Allow the unit to cool for
approximately one hour (if you have cleaned the filters you will
need to wait twenty four hours for the filters to dry before putting
them back in the machine). To re-start the machine, plug it into an
electrical socket and switch back on.
