Installation Guide
Countertop Side Trim
Countertop Rear Trim
2
Installation (Side Trim)
1. Remove the outside grates and grate supports
next to the counter.
2. Locate and remove the screws holding the grate
support side trim in place. Keep the screws for
reuse.
3. Lift the grate support side trim out. It will not be
reinstalled.
4. Locate and remove the screws holding the heat
shield in place. Keep the screws for reuse.
5. Lift the heat shield out and set aside for reuse.
6. Place the countertop side trim into place. Align
with the countertop and the landing ledge.
Replace and secure with the original screws.
7. Replace the heat shield and align the slotted
screw holes with the screw holes in the side trim.
Replace and secure with the original screws.
8. This countertop side trim was designed to
accommodate most installations. If the trim needs
to be shorter, cut at the rear to fi t.
For Models:
R24CSTSS - 24” D. VGIC Open Burner Ranges
C A U T I O N
The heat shield must be replaced only if it
is part of the original product.
Grate support side trim
(standard with product)
Heat shield
(not on all products)
Countertop side trim
(optional accessory)
Heat shield
(not on all products)
3
Installation (Side Trim)
Place the countertop side trim template against the side of the range or rangetop. The fl ange of the template should
be wrapped around the back of the unit. The top of the template should be even with the top edge of the outer trim.
Mark the holes and remove template. Using a 9/64” drill bit, drill the three designated holes into the side of the range or
rangetop. Place the countertop side trim into place and secure with the provided screws.
For Models:
P24CSTSS - 24” D. 5 Series VGCC/VGSC/VDSC/VESC/VISC Ranges and VGRT Rangetops
24” D. RDSCG/RDSCD/RDSCE D3 Ranges
RD24CSTSS - 24” D. 3 Series RVGR/RVDR/RVER Ranges
