Ultra Short Throw Lens – Installation Guide
1
Table of Content
Important Notice ................................................................................................................................ 2
Packing Check List ............................................................................................................................ 2
Projection Lens Overview ................................................................................................................. 3
Installing the Projection Lens ........................................................................................................... 4
Projection Distance and Size ............................................................................................................ 9
Projection Lens Specifications ....................................................................................................... 10
Projection Lens Dimensions ........................................................................................................... 10
About the VIVITEK Support ............................................................................................................ 11
Ultra Short Throw Lens – Installation Guide
2
Important Notice
Before using the Ultra Short Lens, make sure to read below important notice.
Be sure to turn the power off and disconnect the power cable from the wall outlet before replacing the Lens. Improper
operation may cause to electrical shock or injury to eyes by intense light from the projector.
Please remove the lens cap before installing the lens to the projector, the projection light may heat the lens cap and
melt it, this may raise safety issue or damage the projector.
Make sure the projective film on the Lens is removed before turning on the projector; the protective film may be melt
during projection then resulting in damage or deformation.
Do not place any object near the projection light path, the intense light from the projection lens may result in fire or burn
injures.
Use a clean, soft and dry cloth or Lens cleaning wipes to wipe away dirt or dust adhered on the lens.
Do not use the cloth containing oil, dust or water for cleaning. Once dust and dirt adhered on the lens surface, please
clean the glass with lens cleaning wipe.
Keep all the original packing material even you finish the installation, the packing material may be used for avoiding
damage during transportation.
Packing Check List
Item Part Description Qty.
1
Ultra short throw with adaptor bracket
1
2
Bracket assembly
This bracket assembly is composed by one base bracket and four
arms, it’s is a part of support kit for joining Ultra Short Throw Lens
and the projector. Use flat screw to fix the bracket assembly on
the bottom of the projector and joint the arm with projection lens
by hex socket cap screw.
2
3
Flat screw 4*0.7*20mm:
The screws are used for fixing bracket assembly to the bottom of
the projector
1
4
Hex socket cap screw, 6*1*14 mm
Hex socket cap screws are used for jointing the arm of bracket
assembly and the projection lens.
2
5
Wrench
The wrench is used to drive hex socket cap screw
1
Ultra Short Throw Lens – Installation Guide
3
Projection Lens Overview
Note
There is one lens cap to cover the lens cap, please remove the lens cap before installing the lens to the projector. The
projected light may heat the lens cap and melt it; it may raise safety issue or damage the projector.
One protective film is attached on projection light outlet for avoiding scratch or dust on this protection surface, please
remove the protective film before tuning on the projector. Improper operation may cause to the projective film.
Projection light outlet Mounting bracket
(Screw holes x 2, Guide Pin x 2)
Motor for Focus Adjustment
Motor for Focus Plane Adjustment
Lens Surface
