Thank you for choosing Watson Pro
Please read this user manual carefully, and keep
it for reference before using the battery.
AM-98-SHL
VM-98-SHL
High Load
Slim Li-ion Battery with LED
and 3-Stud or V-Mount
SAFETY INSTRUCTIONS
Make sure the battery is fully charged before use.
When not in use, remove the battery from its device. Some
electronic equipment will draw current even when the switch is off.
Do not short-circuit the terminals. This battery is protected with
an internal self-resetting fuse, but short circuits may still cause
severe damage to the battery.
Do not attempt to open the battery case under any circumstances.
Do not remove the battery from any equipment that is powered on.
Always power off your equipment before removing the battery.
Use the battery only under proper environmental conditions: 14°F
to 122°F (-10°C to 50°C) and with a relative humidity (RH) less than
85%.
Storage environment: short-term (one month) -4°F to 122°F (-20°C
to 50°C) and RH 45% to 75%; medium-term (three months) -4°F
to 104°F (-20°C to 40°C) and RH 45% to 75%; long-term (one year)
23°F to 86°F (-5°C to 30°C) and RH 45% to 75%.
The battery may be warm during use or recharging. This is normal.
The battery should be charged up to 50% for long-term storage.
After 4 months of storage, the battery will require a recharge up
to 50%.
Keep the battery out of fire, heat, and high pressure.
Do not expose the battery to rain or moisture.
Do not drop the battery or expose it to strong shocks.
Keep this unit away from water and any flammable gases or liquids.
Clean the battery and terminals with a clean, soft, and dry cloth.
When operation time has noticeably decreased, the battery may
need to be replaced.
Keep this product away from children.
Store the battery in a cool, dry place.
All images are for illustrative purposes only.
PRODUCT FEATURES
Five-segment battery-level
indicators for real-time
monitoring of remaining
battery capacity.
Built-in D-tap connector powers
your camera accessories.
USB 2.0 Standard-A connector
provides 5 V/1 A to power
or charge USB devices.
Built-in intelligent control
circuit for protection against
over-current, low voltage,
overheating, and short circuits.
OVERVIEW
1. USB outport
Press the battery check
button to start charging
or to power your device.
1. Battery-level LED meter
Shows the remaining battery
capacity. When the capacity
reaches less than 9%, the
bottom LED will flash.
2. Battery-level check button
3. V-Mount/3-stud mount
interface
4. D-tap port
12 V, 10 A max.
1
2
3
4
5
5
2
3
4
1
4
Produktspecifikationer
| Varumärke: | Watson |
| Kategori: | Accus kamera |
| Modell: | AM-98-SHL |
