TM
PRO 80
Owner’s Manual & “Limited” Warranty
Technology Specifications:
Thank You for purchasing this Wet Sounds™ product. Wet Sounds™ marine audio products
represent the ultimate in high performance standards. The PRO 80 is specifically engineered
to withstand the rigorous marine environment. Utilizing the state of the art acoustic
engineering and three dimensional computer aided design, the “PRO” series from Wet
Sounds™ represents advanced technologies that are used today in professional concert hall
and stadium applications.
Please take a moment to read the instruction manual before starting your installation. This
manual will explain the benefits of the technologies developed by Wet Sounds™ and will
help you understand the installation and use of this product. If you have any questions or
concerns please contact your certified Wet Sounds™ dealer. You may also contact Wet
Sounds™ technical support by dialing 1-877-WET-SPKR (1-877-938-7757)
SPEAKER SPECIFICATIONS
RMS: 200 watts
Continual: 300 watts
Peak: 400 watts
Mid Bass: 8 inch EFG cone woofers with polyurethane surround
High Frequency: Pro-Axial™ Driver - Coaxially mounted Titanium Diaphragm High Output
Horn Loaded Compression Driver
Impedance: 4 ohm
Frequency Response: 20Hz to 20 kHz
Sensitivity: 90DB at 1W/1M
The PRO 80 has our proprietary WdET™ (Wide Dispersion Enhanced Throw) technology.
Unlike most conventional designs, by having WdET™ technology, the PRO 80 provides
remarkable volume and amazing sound quality off axis and on axis. Through several test the
PRO 80 was confirmed to project volume at 80 feet without any loss of detail or information.
Not only does the PRO 80 achieve volume and sound quality at a minimum of 80 ft, but with
the WdET™ technology the rider can enjoy quality sound while riding outside the wake and
being almost parallel to boat.
The driver compliment in each PRO 80 combines one 8 inch EFG™ driver and one
concentrically mounted HLCD (Horn Loaded Compression Driver). For stellar performance
and higher yielding for the marine environment, Wet Sounds™ developed a proprietary cone
material called EFG™, which is an epoxy fiberglass composite mix. This cone material
incorporates characteristic values that are impermeable to damage from intermittent Ultra
Violet exposure and minimal moisture exposure. Like the EFG™ cone material, the
Polyurethane that is used for the surround will provide protection against Ultra Violet
exposure and moisture. This will prevent deterioration of the surround yielding longer life
and better reliability. We do, however, encourage you to either remove or cover your tower
speakers when they are not in use. Limiting exposure to Ultra Violet Rays and to moisture
will help extend the life of your tower speakers.
1
The high frequency transducer is an HLCD (horn loaded compression driver). This driver
was designed to provide a wide; horizontal trajectory that would not only produce sound in
the directed path but will disperse sound off axis with little to no degradation. The HLCD is
considered to be one of the most efficient transducer designs providing remarkable output
while using less power. This unique design incorporates the HLCD mounted to the rear of the
8” EFG™ driver. Through the voice coil former, the compression sound travels out of the
horn flare that is mounted coaxially to the 8” EFG™ driver. Using the HLCD transducer in
the PRO 80 will provide phenomenal volume and accurate clarity.
***Caution: Do not spray any of the speakers directly with any liquid base substance.
Warranty will be voided if improper care is discovered during extensive examination of the
product.
Installation:
Wiring Diagram Picture-See Attached
WC Speaker Connector Picture and Directions-See Attached
Trick Connect™ Bracket Assembly:
The PRO 80 uses one Trick Connect™ bracket per speaker. This bracket is designed to give
you the option to have speakers facing the rear (stern) or facing forward (bow). Trick
Connect™ also allows you to remove the speakers fairly quick and painless.
There are three essential pieces to the Trick Connect™ bracket assembly; the tower clamp;
the U-bracket and the rubber inserts.
The tower clamp attaches to the tower using the one of the six provided inserts. There is also
a rubber strip that you should use to wrap the tower. This will prevent scratching from the
clamp and movement of the tower speaker.
The U-bracket that is attached to the speaker is designed to slide within the grooves of the
clamp. DO NOT attach the speaker to the tower clamp until the clamp is securely attached to
the tower first.
The bracket is a 2 7/8 inch bracket. If your tower is 2 7/8 inches, you will not need to use the
inserts but we recommend that you still use the rubber strips to help secure and prevent
scratching.
For other size towers there are 6 insert sizes per bracket.
The sizes are
2 ½ 1 ¾
2 ¼ 1 5/8
2 1 ½
2
