Wet Sounds REVO CX-10 XS-W-SS Bruksanvisning

Wet Sounds högtalare REVO CX-10 XS-W-SS

Läs nedan 📖 manual på svenska för Wet Sounds REVO CX-10 XS-W-SS (8 sidor) i kategorin högtalare. Denna guide var användbar för 3 personer och betygsatt med 4.5 stjärnor i genomsnitt av 2 användare

Ladda ner PDF

Sida 1/8

MARINE COAXIAL / FULL RANGE

SPEAKER SYSTEMS

OPERATION / INSTALLATION MANUAL

HIGH PERFORMANCE MARINE AUDIO

wetsounds.com

10 CX

Wet Sounds REVO CX Operations / Installation Manual

1REVO 10 CX OPERATION

REVO 10 CX

MARINE COAXIAL / FULL RANGE

SPEAKER SYSTEMS

OPERATION / INSTALLATION MANUAL

PLEASE TAKE A MOMENT TO READ THE INSTRUCTION MANUAL BEFORE STARTING

YOUR INSTALLATION. IF YOU HAVE ANY QUESTIONS OR CONCERNS, PLEASE

CONTACT YOUR CERTIFIED WET SOUNDS DEALER OR WET SOUNDS AT:

877-WET-SPKR (1-877-938-7757)

www.wetsounds.com

Wet Sounds REVO CX Operations / Installation Manual

THANK YOU FOR PURCHASING WET SOUNDS! 2

CONGRATULATIONS!

Thank You for purchasing the Wet Sounds REVO10 CX series Speaker

System.

Wet Sounds professional marine audio products represent the ultimate

in high performance marine audio. Wet Sounds products are speciﬁcally

engineered to withstand the rigorous marine environment.

The REVO series are state of the art Marine Speaker Systems designed

to provide great reproduction for your marine or off-road audio system.

The REVO 10 CX series is equipped with a 1.25” titanium dome tweeter. RGB

LED lighting is included on the underside of the tweeter for a wide variety of

colors to be viewed on the cone. REVO 10 CX series speakers are built with

Aluminum baskets, providing improved marine stability and strength over

conventional materials used in most marine speakers.

Wet Sounds has developed a rubber spider that is built to last much

longer than the traditional cotton spiders used in most marine speakers.

The tweeter on REVO speakers is mounted on the grill, which keeps the mid

woofer sealed eliminating any chance of water intrusion through the pole

piece as common on many marine coaxial speaker systems. Eight different

grill designs are available.

SPECIFICATIONS

REVO Speciﬁcations REVO10 CX

Power Handling RMS 350 Watts

Power Handling Peak 700 Watts

Frequency Response 35Hz – 22kHz

Sensitivity (@ 1 Watt/1 Meter) 90 dB

Weight (pair) 29.8 Lbs (13.5 Kg)

Diameter 11.02 inches w/grill (279.9mm)

Mounting Depth 4.72 inches (119.8mm)

Hole Cut Out 9.45 inches (240.03mm)
