Whirlpool ART 228/80 A+/SF Bruksanvisning

Whirlpool kylskåp ART 228/80 A+/SF

Läs nedan 📖 manual på svenska för Whirlpool ART 228/80 A+/SF (4 sidor) i kategorin kylskåp. Denna guide var användbar för 7 personer och betygsatt med 4.5 stjärnor i genomsnitt av 2 användare

Ladda ner PDF
Sida 1/4
EN
Quick guide
THANK YOU FOR BUYING A WHIRLPOOL PRODUCT
In order to receive a more complete assistance, please
register your product on www . whirlpool . eu/ register
Before using the appliance carefully read the Safety
Instruction.
PRODUCT DESCRIPTION
FIRST TIME USE
Wait at least two hours, after the installation, before connecting
the appliance to the power supply. Connect the appliance to the
power supply it starts the operation automatically. The ideal storage
temperatures for the food are preset in the factory.
After turning the appliance on, you must wait for 4-6 hours for the
correct storage temperature to be reached for a normally lled
appliance. Position the antibacterial anti-odour lter in the fan as
demonstrated in the lter packaging (if available). If the audible signal
sounds, it means that the temperature alarm has intervened: press the
button to switch o the acoustic alarms.
CONTROL PANEL
1. 2.
1. On/stand-by
2. Refrigerator temperature - Fast cool
6TH SENSE FRESH CONTROL
The appliance is automatically able to quickly reach the optimal
internal preservation temperature. The function enables to control also
the humidity of the appliance. In order for it to function correctly, the
fan must also be turned on. It is possible to turn the function on/o
(see Fan description).
FAN*
The Fan improves temperature distribution inside the product,
allowing better preservation of stored food and reduction of excess
humidity. The fan is switched on by default and can be activate/
deactivate manually. The fan operating mode is adjusted based on
product condition. You can turn the fan on/oby pressing the
and “On/Stand-by” buttons at the same time for 3 seconds. The
lit 6thSense FreshControl symbol indicates that the fan is on and
therefore the 6thSense FreshControl function is on. If the ambient
temperature exceeds 27°C, or if drops of water are present on the
glass shelves, it is essential that the fan is on to ensure the proper
preservation of the food. Deactivation of the fan allows energy
consumption to be optimised.
Note: the fan restarts automatically after a power cut or after turning o
the appliance. Do not obstruct the air intake area with food items.
ANTIBACTERIAL FILTER*
Remove it from the box placed in the Fruit and vegetable drawer and
insert into the cover of fan. The replacement procedure is included in
the lter box.
ON/STAND-BY
Press the button for 3 seconds to turn the appliance o. In
Stand-by mode the light in the refrigerator compartment does not turn
on. Press the button again briey to reactivate the appliance.
Note: this does not disconnect the appliance from the power supply.
REFRIGERATOR COMPARTMENT TEMPERATURE
It is possible to set a dierent temperature with the button.
There are ve possible controls.
• From a less cold temperature (left)
• to a colder temperature (right).
FAST COOL
Press the button for 3 seconds to quickly cool the
refrigerator compartment or 6 hours before putting large quantities of
food to be frozen in the freezing zone. When the function is turned on
the icon lights up.
The function automatically turns o after 30 hours, or manually by
pressing the button again for 3 seconds.
Note: avoid a direct contact between the fresh food and the food that is
already frozen To optimise the freezing speed, drawers can be removed
and the food can be placed directly on the bottom of the compartment.
* Available only on certain models
* Available only on certain models
“0° ZONE” COMPARTMENT*
The “ ” compartment is specically designed to maintain a low
0°ZONE
temperature and the correct humidity to preserve fresh food for longer
(for example, meat, sh, fruits and winter vegetables).
Humidity control technology coupled with Active0 provides the best
food preservation when the food is not completely packed.
TURNING ON AND TURNING OFF THE COMPARTMENT
The internal temperature of the compartment is approximately 0°
when the compartment is turned on.
To turn on the compartment, press the button (1) for more than one
second until the symbol (2) lights up. The lit symbol (2) means that the
compartment is working. Press the button (1) again for more than one
second to turn o the compartment. The temperature inside depends
on the general temperature of the refrigerator.
1
2
.
.
For the correct functioning of the “ ” compartment, it is 0°ZONE
necessary that:
• the appliance is turned on;
• the fridge temperature is between +2°C and +6°C;
• the “0°ZONE” compartment is turned on
• Vacation Mode and Stand by are not selected
Note:
-if the symbol does not light up when you turn on the compartment,
check that the drawer is properly inserted; if the problem persists
contact the authorised Technical Assistance Service;
-when the “0°ZONE” compartment is inserted in the appliance you
may hear a faint noise, which you should consider as normal;
Important: be careful when positioning food and containers that are
small in size on the upper shelf of the “ “ compartment in order
0°ZONE
to prevent them accidentally falling between the shelf and the back
wall of the refrigerator compartment.
REMOVING THE “0° ZONE“ COMPARTMENT
Carry out the following steps:
1. To make it easier to remove the compartment, we recommend
that you empty (and possibly remove) the lower door shelves.
2. Remove the compartment by rotating it upwards.
3. Remove the white plastic shelf under the compartment.
Note: it is not possible to remove the upper shelf and side supports.
To use the “0° ZONE“ compartment again, carefully reposition the
white plastic shelf under the compartment before inserting the drawer
and turning the function back on.
To have a larger refrigerator volume and to reduce energy
consumption, it is recommended to remove the “ “
0°ZONE
compartment.
Clean the compartment and its components occasionally using a cloth
and a solution of warm water (taking care not to submerge the white
plastic shelf under the drawer) and neutral cleaning agents specically
for cleaning the inside of the refrigerator. Do not use abrasive cleaning
agents.
Before cleaning the compartment (also externally) it is necessary
to remove the drawer to disconnect the electrical supply.
STOP FROST SYSTEM*
The STOP FROST SYSTEM facilitates the defrost procedure for the
freezer compartment.
The STOP FROST accessory is designed to collect some of the frost
that forms in the freezer compartment and it is easy to remove and
clean, therefore reducing the time needed to defrost the freezer
compartment.
To remove the frost on the STOP FROST accessory follow the cleaning
procedure demonstrated below.
PROCEDURE TO CLEAN THE STOP FROST ACCESSORY
1. Open the freezer compartment door and remove the upper
drawer.
2. Unfasten the STOP FROST accessory and remove it, taking care not
to drop it on the glass shelf below.
Note: if the accessory is jammed or dicult to remove, do not keep
trying to remove it, but proceed with the complete defrost of the freezer
compartment.
3. Close the door of the freezer compartment.
4. Remove the frost on the accessory by rinsing it under running (not
hot) water.
5. Let the accessory drip dry and dry the plastic parts with a soft
cloth.
6. Reinsert the accessory by placing the back part on the projections
shown in gure, then refasten the handle of the accessory to the
clasps above.
7. Reinsert the upper drawer and close the door of the freezer
compartment.
It is possible to clean the STOP FROST accessory on its own without
completely defrosting the freezer compartment.
Cleaning the STOP FROST accessory regularly helps to reduce the need
to completely defrost the freezer compartment.
Note: the product specications, including volume and energy, are
calculated without the STOP FROST accessory.
HOW TO STORE FOOD AND BEVERAGE
***
**
Legend
TEMPERATE ZONE
Suggested for storage of tropical fruit, cans, drink, eggs,
sauces, pickles, butter, jam
COOL ZONE
Suggested for storage of cheese, milk, daily food,
delicatessen, yoghurt
COOLEST AREA
Suggested for storage of cold cuts, desserts, meat and
sh
FRUIT & VEGETABLE DRAWER
FREEZER DRAWERS
FREEZING ZONE DRAWER
(Max cool zone)
Suggested to freeze fresh/cooked food
** For models with "0 ° ZONE" COMPARTMENT the "coolest area" is the one
highlighted in the legend
*** Only for CB310 e CB380 models (refer to the Rating plate located at side
of Fruit and vegetable drawer)
