EN
Quick guide
THANK YOU FOR BUYING A WHIRLPOOL PRODUCT
In order to receive a more complete assistance, please
register your product on www . whirlpool . eu/ register
Before using the appliance carefully read the Safety
Instruction.
PRODUCT DESCRIPTION
FIRST TIME USE
Wait at least two hours, after the installation, before connecting
the appliance to the power supply. Connect the appliance to the
power supply it starts the operation automatically. The ideal storage
temperatures for the food are preset in the factory.
After turning the appliance on, you must wait for 4-6 hours for the
correct storage temperature to be reached for a normally lled
appliance. Position the antibacterial anti-odour lter in the fan as
demonstrated in the lter packaging (if available). If the audible signal
sounds, it means that the temperture alarm has intervened: press the
button to switch o the acoustic alarms.
CONTROL PANEL
1. Thermostat control reference
2. Freezer and refrigerator compartment
temperature knob
3. LED light bulb
1.
2.
3.
FREEZING FRESH FOOD
Place the fresh food to be frozen in the FREEZING ZONE in the freezer
compartment avoiding the direct contact with the food that is already
frozen. To optimize the freezing speed, the lower drawer can be
removed and the food can be placed directly on the bottom of the
compartment.
FAN*
You can turn the Fan on/o by pressing the button on the base (as
shown in the gure). If the ambient temperature
exceeds 27°C, or if drops of water are present on the
glass shelves, it is essential that the fan is on to ensure
the proper preservation of the food. Deactivation of the
fan allows energy consumption to be optimised.
FREEZER AND REFRIGERATOR COMPARTMENT TEMPERATURE
This Fridge/Freezer is switched on using the thermostat located inside
the refrigerator compartment. The temperature of both compartments
is adjusted by turning the thermostat knob.
Thermostat set to 1/2 : minimum refrigeration (less cold)
Thermostat set to 3-5 : medium refrigeration
Thermostat set to 6/7 : maximum refrigeration (colder)
Setting the Thermostat knob to • turns the whole appliance o (no
refrigeration, no light).
* Available only on certain models
400011188402
HOW TO STORE FOOD AND BEVERAGE
**
***
Legend
TEMPERATE ZONE
Suggested for the storage of tropical fruit, cans, drinks,
eggs, sauces, pickles, butter, jam
COOL ZONE
Suggested for the storage of cheese, milk, daily food,
delicatessen, yogurt
COOLEST AREA
Suggested for storage of cold cuts, desserts, meat and
sh
FRUIT & VEGETABLE DRAWER
FREEZER DRAWERS
FREEZING ZONE DRAWER
(Max cool zone)
Suggested to freeze fresh/cooked food.
** For models with "0 ° ZONE" COMPARTMENT the "coolest area" is
the one highlighted in the legend
*** Only for CB310 e CB380 models (refer to the Rating plate
located at side of Fruit and vegetable drawer)
TROUBLESHOOTING
What to do if... Possible reasons Solutions
The appliance doesn’t work. There may be an appliance power
supply problem.
Make sure:
• there is not a power outage;
• the plug is properly inserted in the power socket and the double-
pole switch (if present) is in the correct position (on);
• the household electrical system protection devices are ecient;
• the power cable is not damaged;
• the thermostat knob is not turned to “•”.
The inside light does not
work.
It may be necessary to replace the light
bulb.
Disconnect the appliance from the power supply and contact the
Technical Assistance Service if you need a replacement.
The internal temperature
of the compartments is not
cold enough.
The reasons could vary (see “Solution”)
column.
Check that:
• the doors are closed properly;
• the appliance is not installed near a heat source;
• the temperature is appropriately set;
• the circulation of air through the ventilation grilles on the base of
the appliance is not obstructed.
There is water on the
bottom of the refrigerator
compartment.
The defrost water drain is blocked. Clean the defrosting water drain (see section “Cleaning and
Maintenance").
Excessive amount of frost in
the freezer compartment.
The door to the freezer compartment is
not closed properly.
• Check that there is nothing preventing the door from closing
properly.
• Defrost the freezer compartment.
• Make sure the appliance has been correctly installed.
The front edge of the
appliance that the door
gaskets seal against is hot.
This is not a problem. It prevents
condensation from forming.
A solution is not needed.
The temperature of the
refrigerator compartment is
too cold.
• The set temperature is too cold.
• A large amount of fresh food may
have been placed in the freezer
compartment.
• Try to set a less cold temperature.
• If fresh food has been put in the freezer compartment, wait until
the freezing has been completed.
• Turn o the fan (if present) described in the paragraph “FAN”.
You can download the Safety Instructions, User Manual, Product Fiche and Energy data by:
• Visiting our website docs . whirlpool . eu
• Using QR Code
• Alternatively, contact our After-sales Service (See phone number in the warranty booklet). When
contacting our After-sales Service, please state the codes provided on your product's identication plate.
