Läs nedan 📖 manual på svenska för Whirlpool AWM 5125/5 (17 sidor) i kategorin tvättmaskin. Denna guide var användbar för 2 personer och betygsatt med 4.5 stjärnor i genomsnitt av 2 användare
Sida 1/17
3
CONTENTS
BEFORE USING THE WASHING MACHINE
FIRST WASH CYCLE
PRECAUTIONS AND GENERAL
RECOMMENDATIONS
DESCRIPTION OF THE WASHING MACHINE
CHILD SAFETY (IF AVAILABLE)
PREPARATION OF THE WASHING
DETERGENTS AND ADDITIVES
WASHING PROGRAMME
REMOVING THE FILTER
DRAINING RESIDUAL WATER
CARE AND MAINTENANCE
TROUBLESHOOTING GUIDE
AFTER-SALES SERVICE
ACCESSORIES
TRANSPORT AND HANDLING
INSTALLATION
ELECTRICAL CONNECTION
30110234GB.fm Page 3 Thursday, July 7, 2005 7:16 PM
4
BEFORE USING THE WASHING MACHINE
1.Removing the packaging and check
•After unpacking, make sure that the washing
machine is undamaged. If in doubt, do not use the
washing machine. Contact After-Sales Service or
your local retailer.
•Keep the packaging materials (plastic bags,
polystyrene parts, etc.) out of reach of children,
as they are potentially dangerous.
2.Remove the transit bolts
•The appliance is fitted with transit bolts to
prevent internal damage during transport.
Before using the washing machine you must
remove the transit bolts (see “Installation/
Remove the transit bolts”).
3.Install the washing machine
•Remove the protective foil from the control
panel (if available).
•Move the machine without carrying it at the top.
•Install the appliance on a solid and level floor
surface, preferably in a corner of the room.
•Adjust the feet to ensure that the machine is
stable and level (see “Installation/Adjust the
feet”).
4.Water supply
•Connect the water supply inlet hose in
accordance with regulations of your local water
company (see “Installation/Connect the water
inlet hose”).
•Water supply: cold water only
•Tap: 3/4” threaded hose connection
•Pressure: 100-1000 kPa (1-10 bar).
5.Drain hose
•Connect the drain hose to the siphon or hook it
over the edge of a sink by means of the “U” bend
(see “Installation/Connect the water drain hose”).
•If the washing machine is connected to a built-in
drainage system, ensure the latter is equipped
with a vent to avoid simultaneous loading and
draining of water (siphoning effect).
6.Electrical connections
•Electrical connections must be carried out by a
qualified technician in compliance with the
manufacturer’s instructions and current standard
safety regulations.
•Voltage information, power consumption and
electrical protection data are supplied on the
inside of the appliance door.
•The appliance must be connected to the mains
exclusively by means of a socket with an earth
connection in accordance with established
regulations. The appliance must be earthed by
law. The manufacturer declines all liability for
damage to property or injury to persons or
animals deriving either directly or indirectly from
failure to observe the directions.
•Do not use extension leads or multi sockets.
•Before any maintenance on the washing machine
disconnect it from the mains supply.
•Access to the mains plug or to disconnection
from mains supply via a double-pole switch must
be ensured at all times following the installation.
•Do not operate the washing machine if it has
been damaged during transport. Inform the
After-Sales Service.
•Mains cable replacement is only to be carried out
by After-Sales Service.
•The washing machine must only be used in the
household for the prescribed uses.
Minimum housing dimensions:
Width: 600 mm
Height: 825 mm
Depth: 600 mm
30110234GB.fm Page 4 Thursday, July 7, 2005 7:16 PM
5
FIRST WASH CYCLE
PRECAUTIONS AND GENERAL
RECOMMENDATIONS
1.Packing
•The packing box may be fully recycled as confirmed
by the recycling symbol. Adhere to local
regulations when disposing of packaging material.
2.Energy saving tips
•Achieve the best use of energy, water, detergent
and time by using the recommended maximum
load size.
•Do not exceed the detergent dosages indicated
in the manufacturer’s instructions.
•The Eco Flap - a special system in the outlet - will
prevent detergent loss from the drum to avoid
detergent loss into the environment.
•Use “Prewash” for heavily soiled laundry only!
Save detergent, time, water and energy
consumption by not selecting “Prewash” for
slight to normally soiled laundry.
•Pretreat stains with stain remover or soak dried
in stains in water before washing to reduce the
necessity of a hot wash program.
•Save energy by using a 60° C instead of a 90° C
wash programme or a 40° C instead of a 60° C
wash programme.
•Save energy and time by selecting a high spin
speed to reduce the water content in laundry
before using a tumble dryer (for machines with
adjustable spin speed).
3.Disposing of packaging and old appliances
•This appliance is marked according to the
European directive 2002/96/EC on Waste
Electrical and Electronic Equipment (WEEE).
By ensuring this product is disposed of correctly,
you will help prevent potential negative
consequences for the environment and human
health, which could otherwise be caused by
inappropriate waste handling of this product.
The symbol on the product, or on the
documents accompanying the product, indicates
that this appliance may not be treated as
household waste. Instead it shall be handed over
to the applicable collection point for the recycling
of electrical and electronic equipment.
Disposal must be carried out in accordance with
local environmental regulations for waste disposal.
For more detailed information about treatment,
recovery and recycling of this product, please
contact your local city office, your household
waste disposal service or the shop where you
purchased the product.
•The washing machine is built from reusable
materials. The washing machine must be disposed of
in compliance with local waste disposal regulations.
•Before scrapping, cut off the power cable so that the
washing machine cannot be connected to the mains.
•Remove detergent from compartment if you
intend scrapping your appliance.
4.Child safety
•Children must not be allowed to play with the
washing machine.
5.General recommendations
•When the appliance is not in use unplug it and
turn off the tap.
•Before cleaning or carrying out maintenance,
switch off the washing machine and disconnect it
from the mains supply.
•To clean the outside of the washing machine, use
a neutral detergent and a damp cloth.
•Do not use abrasive detergents.
•Do not attempt to force the door open.
•If necessary, the power cable may be replaced
with an identical one obtained from our After-
Sales Service. The power cable must only be
replaced by a qualified technician.
6.EC Declaration of Conformity
•This washing machine has been designed,
constructed and distributed in compliance with
the safety requirements of EC Directives:
73/23/EEC Low Voltage Directive
89/336/EEC EMC Directive
93/68/EEC CE Marking Directive
We recommend the first wash cycle be made without laundry.
This will remove any residual water used in testing your washing machine.
1. Turn on the tap.
2. Close the appliance door.
3. Pour a small amount of detergent (about 30 ml) into the detergent dispenser .
4. Select a short program (see programme chart).
5. Press the “On/Off” button.
30110234GB.fm Page 5 Thursday, July 7, 2005 7:16 PM
