Sida 1/14
ENQuick Guide
1
FILLING THE SALT RESERVOIR
The use of salt prevents the formation of LIMESCALE on the dishes and on
the machine’s functional components.
• It is mandatory that the salt reservoir never be empty.
• It is important to set the water hardness.
The salt reservoir is located in the lower part of the dishwasher and must be
lled when the SALT REFILL indicator light in the control panel is lit.
1. Remove the lower rack and unscrew the reservoir cap
(anticlockwise).
2. Only the rst time you do this: ll the salt reservoir
with water.
3. Position the funnel and ll the salt reservoir (see gure)
right up to its edge (approximately 1 kg); it is not unu-
sual for a little water to leak out.
4. Remove the funnel and wipe any salt residue away from the opening.
Make sure the cap is screwed on tightly, so that no detergent can get into
the container during the wash program (this could damage the water sof-
tener beyond repair).
Whenever you need to add salt, it is mandatory to complete the pro-
cedure before the beginning of the washing cycle to avoid corrosion.
WATER SOFTENING SYSTEM
Water softener automatically reduces water hardness, consequently prevent-
ing scale buildup on heater, contributing also to better cleaning eciency.
This system regenerates itself with salt, therefore it is required to rell
salt container when empty.
Frequency of regeneration depends on water hardness level setting - regen-
eration takes place once per Eco cycles with water hardness level set to . 6 3
Regeneration process starts in nal rinse and nishes in drying phase, be-
fore cycle ends.
• Single regeneration consumes: ~3.5L of water;
• Takes up to 5 additional minutes for the cycle;
• Consumes below 0.005kWh of energy.
A
C
D
FILLING THE RINSE AID DISPENSER
Rinse aid makes dish DRYING easier. The rinse aid
dispenser A should be lled when the RINSE AID
REFILL indicator light in the control panel is lit.
NEVER pour the rinse aid directly into the appli-
ance tub.
FILLING THE DETERGENT DISPENSER
To open the detergent dispenser use the opening device . Introduce the C
detergent into the dry dispenser only. Place the amount of detergent for D
pre-washing directly inside the tub. If all-in-one detergents are used, we
recommend using the TABLET button, because it adjusts the program so
that the best washing and drying results are always achieved.
Usage of detergent not designed for dishwashers may cause malfunc-
tion or damage to the appliance.
Program
Programs description
Drying
phase
NaturalDry
Available options *)
Duration
of wash
program
(h:min)
**)
Water
con-
sumption
(litres/cycle)
Energy
consump-
tion
(kWh/cycle)
1.
Eco 50°- Program is suitable to clean normally soiled tableware, that
for this use, it is the most ecient programme in terms of its com-
bined energy and water consumption, and that it is used to assess
compliance with the EU Ecodesign legislation. 3:35 8.7 0.51
2. Intensive 65° - Program recommended for heavily soiled crockery,
especially suitable for pans and saucepans. 2:45 17.5 1.60
3.
6th Sense® 50-60°- For normally soiled dishes with dried food resi-
dues. Senses the level of soiling on the dishes and adjusts the pro-
gram accordingly. 1:20 - 3:00 7.0 - 14.0 0.70 - 1.10
4. Fast Wash&Dry 50°
- Normally soiled crockery. Everyday cycle, that
ensures optimal cleaning and drying performance in shorter time.
1.25 11.5 1.10
5. Crystals - 45° Program for delicate items, which are more sensitive
to high temperatures, for example glasses and cups. 1:40 12.0 1.20
6. Rapid 30’ - 45° Program to be used for half load of lightly-soiled
dishes with no dried food residues. Without drying. - 0:30 9.0 0.50
7.
Silent
50° - Suitable for night-time operation of the appliance. With
the lowest noise. 3:30 16.0 1.15
8.
Sanitizing - 65° Normally or heavily soiled crockery, with addi-
tional antibacterial wash. Can be used to perform maintenance of
the dishwasher. - 1.50 12.0 1.30
9. Prewash - Use to refresh crockery planned to be washed later.
No detergent to be used with this program. - - 0:10 4.5 0.01
CONTROL PANEL
FIRST TIME USE More information in the Daily Reference Guide on website.
PROGRAMS TABLE
1. On-O / Reset button with indicator light
2. Program selection button with indicator light
3. Multizone button with indicator light
4. Extra Dry button with indicator light / Keylock
5. Eco program indicator light
6. Keylock indicator light
7. Display
8. Program number and remaining time indicator
9. Tablet (Tab) indicator light
10. Closed water tap indicator light
11. Rinse Aid rell indicator light
12. Salt rell indicator light
13. Power Clean® button with indicator light
14. Tablet (Tab) button with indicator light
15. Delay button with indicator light
16. Start/Pause button with indicator light / Drain out
4
1
32
9 16
14 15
65 7 8 11 12 1310
THANK YOU FOR BUYING AWHIRLPOOL PRODUCT.
In order to receive amore complete assistance, please
register your appliance on: www.whirlpool.eu/register
PLEASE SCAN THE
QR CODE ON YOUR
APPLIANCE IN
ORDER TO HAVE
MORE DETAILED
INFORMATION
Before using the appliance carefully read Safety and Installation Instructions.
After installation, please remember to remove all transport protection parts from
the dishwasher.
Quick Guide
EN
2
OPTIONS can be selected directly by pressing the corresponding button (see CONTROL PANEL). If an option is not compatible with the selected
program (see PROGRAMS TABLE), the corresponding LED ashes rapidly 3 times and beeps will sound. The option will not be enabled.
CLEANING THE FILTER ASSEMBLY CLEANING THE SPRAY ARMS
AA
B
C
1 2 3 4
In case you nd foreign objects (such as broken glass, porcelain, bones, fruit seeds etc.)
please remove them carefully.
NEVER REMOVE the wash-cycle pump protection (black detail) (Fig 4).
To remove the upper spray arm,
turn the plastic locking ring in
aclockwise direction.
The lower spray arm may
be removed by pulling it
upwards.
ECO program data is measured under laboratory conditions according to European Standard EN 60436:2020.
Note for Test Laboratories: For information on
comparative EN testing conditions, please send an email to the following address:
dw_test_support@europeanappliances.com
Pre-treatment of the dishes is not needed before any of the programs.
*) Not all options can be used simultaneously.
**) Values given for programs other than the program Eco are indicative only. The actual time may vary depending on many factors such as temperature and
pressure of the incoming water, room temperature, amount of detergent, quantity and type of load, load balancing, additional selected options and sensor cali-
bration. The sensor calibration can increase program duration up to 20 min.
OPTIONS AND FUNCTIONS Please scan on your product in order to have more detailed information.the QR code
CUTLERY RACK
(loading
example for the
cutlery rack)
The third rack
was designed
to house the
cutlery.
UPPER RACK
(loading
example for the
upper rack)
Load delicate and light
dishes: glasses, cups, sau-
cers, low salad bowls.
The upper rack has tip-up
supports which can be
used in a vertical position
when arranging tea/ des-
sert saucers or in a lower
position to load bowls
and food containers.
FOLDABLE
FLAPS WITH
ADJUSTABLE
POSITION
LOWER RACK
(loading
example for the
lower rack)
For pots, lids, plates, salad bowls,
cutlery etc. Large plates and lids
should ideally be placed at the
sides to avoid interferences with
the spray arm.
The lower rack has tip-up supports
which can be used in a vertical
position when arranging plates or
in a horizontal position (lower) to
load pans and salad bowls easily.
POWER CLEAN®
Power Clean® uses the special water jets in the rear of cavity to wash
more intensively the high dirty items. The lower rack has a Space
Zone, a special pull-out support in the rear of the rack that can be
used to support frying pans or baking pans in upright position, thus
taking up less space. Placing the pots/casseroles faced to the Power
Clean® component please activate the POWER CLEAN® on the panel.
LOADING THE RACKS CAPACITY: 10 standard place-settings
CARE AND MAINTENANCE More information in the Daily Reference Guide on website.
KEY LOCK - A long press (for 3 seconds) of EXTRA DRY button, will activate
the KEY LOCK function. To deactivate the KEYLOCK, long press again.
DELAY - The start of the program may be delayed for a period of time
between and hours.0:30 24
The DELAY function cannot be set once a wash cycle has been started .
TABLET (Tab) - If you use powder or liquid detergent, this option
should be o.
MULTIZONE - If there are not many dishes to be washed, a half load-
ing may be used in order to save water, electricity and detergent.
By default the appliance washes dishes in all racks.
EXTRA DRY - A higher temperature during the nal rinse and an
extended drying phase allow for improving drying.
POWER CLEAN® - Thanks to the additional power jets this option
provides a more intensive and powerful wash in the lower rack, in the
specic area. This option is recommended for washing pots and casseroles.
NaturalDry is a convection drying system which automatically opens
the door during/after drying phase to ensure exceptional drying perfor-
mance every day. Door opens at the temperature that is safe to your kitch-
en furniture.
ENQuick Guide
3
In case your dishwasher doesn’t work properly, check if the problem can be solved by going through the following list. For other errors or issues
please contact authorized After-sales Service which contact details can be found in the warranty booklet. Spare parts will be available for a period
of either up to 7 or up to 10 years, according to the specic Regulation requirements.
PROBLEMS POSSIBLE CAUSES SOLUTIONS
The dishwasher does not
ll the water. Display shows:
and , both On/O and F6
START/Pause LEDs are blink-
ing rapidly.
No water in the water supply or the tap is closed.
Make sure there is water in the water supply or the tap running.
The inlet hose is bent. Make sure the inlet hose is not bent (see INSTALLATION) reprogram the
dishwasher and reboot.
The sieve in the water inlet hose is clogged; it is
necessary to clean it.
After having carried out the verication and cleaning, turn o and
turn on the dishwasher and restart a new program.
Dishwasher nishes the cycle
prematurely.
Display shows: and both F15
On/O and START/Pause LEDs
are blinking rapidly.
Drain hose positioned too low or siphoning
into home sewage system.
Check if end of drain hose is placed at correct height (see INSTAL-
LATION).Check for siphoning into home sewage system, install air
admittance valve if necessary.
Air in water supply. Check water supply for leaks or other issues letting air inside.
Detergent leaks.
Depends on the liquid detergent used and can be
emphasized in case of Delay option is activated.
Small leaks will not cause machine malfunction and can be avoided
by changing liquid detergent type or using tablets.
TROUBLESHOOTING
Please scan the on your product in order to have more detailed information.QR code
Policies, standard documentation, ordering of spare parts and additional product information can be found by:
• Using QR code on your product.
• Visiting our website docs.whirlpool.eu/docs and parts-selfservice.europeanappliances.com
• Alternatively, contact our After-sales Service (See phone number in the warranty booklet).
When contacting our After-sales Service, please state the codes provided on your product’s identication plate.
The model information can be retrieved using the QR-Code reported in the energy label.
The label also includes the model identier that can be used to consult the portal of the registry at https://eprel.ec.europa.eu.
IEC 436
:
®/TM/ © 2024 Whirlpool, Produced under license
Produktspecifikationer
| Varumärke: | Whirlpool |
| Kategori: | Diskmaskin |
| Modell: | WH6FB10BS7A0X |
Behöver du hjälp?
Om du behöver hjälp med Whirlpool WH6FB10BS7A0X ställ en fråga nedan och andra användare kommer att svara dig
Diskmaskin Whirlpool Manualer
9 Januari 2025
9 Januari 2025
8 Januari 2025
6 Januari 2025
6 Januari 2025
6 Januari 2025
5 Januari 2025
5 Januari 2025
31 December 2025
26 December 2024
Diskmaskin Manualer
- Diskmaskin Candy
- Diskmaskin Electrolux
- Diskmaskin Samsung
- Diskmaskin ATAG
- Diskmaskin LG
- Diskmaskin Bosch
- Diskmaskin AEG
- Diskmaskin IKEA
- Diskmaskin AEG Electrolux
- Diskmaskin Bauknecht
- Diskmaskin BEKO
- Diskmaskin Delonghi
- Diskmaskin Daewoo
- Diskmaskin Etna
- Diskmaskin Grundig
- Diskmaskin Indesit
- Diskmaskin Inventum
- Diskmaskin Kenwood
- Diskmaskin Miele
- Diskmaskin Medion
- Diskmaskin Siemens
- Diskmaskin Zanussi
- Diskmaskin Zanker
- Diskmaskin Amica
- Diskmaskin Amana
- Diskmaskin Ardo
- Diskmaskin Ariston
- Diskmaskin Arcelik
- Diskmaskin Asko
- Diskmaskin Silverline
- Diskmaskin Bartscher
- Diskmaskin GE
- Diskmaskin Sharp
- Diskmaskin Techwood
- Diskmaskin Fisher And Paykel
- Diskmaskin Bertazzoni
- Diskmaskin Lamona
- Diskmaskin Klarstein
- Diskmaskin Fagor
- Diskmaskin Brandt
- Diskmaskin Omega
- Diskmaskin Smeg
- Diskmaskin Telefunken
- Diskmaskin Gorenje
- Diskmaskin Neff
- Diskmaskin Silvercrest
- Diskmaskin Baumatic
- Diskmaskin Thomson
- Diskmaskin Hoover
- Diskmaskin Black And Decker
- Diskmaskin KitchenAid
- Diskmaskin Teka
- Diskmaskin Nordland
- Diskmaskin Saba
- Diskmaskin Progress
- Diskmaskin Cata
- Diskmaskin Gaggenau
- Diskmaskin Hotpoint-Ariston
- Diskmaskin Zanussi-electrolux
- Diskmaskin Ignis
- Diskmaskin Tomado
- Diskmaskin Maytag
- Diskmaskin Thermador
- Diskmaskin Hisense
- Diskmaskin Hyundai
- Diskmaskin Hanseatic
- Diskmaskin Vox
- Diskmaskin Cylinda
- Diskmaskin Bellini
- Diskmaskin Avanti
- Diskmaskin Westinghouse
- Diskmaskin Vestel
- Diskmaskin ECG
- Diskmaskin Pelgrim
- Diskmaskin Blomberg
- Diskmaskin Bush
- Diskmaskin Magic Chef
- Diskmaskin Swan
- Diskmaskin Emerio
- Diskmaskin Russell Hobbs
- Diskmaskin Constructa
- Diskmaskin John Lewis
- Diskmaskin Summit
- Diskmaskin Hotpoint
- Diskmaskin Midea
- Diskmaskin De Dietrich
- Diskmaskin Junker
- Diskmaskin Blaupunkt
- Diskmaskin Mabe
- Diskmaskin Concept
- Diskmaskin Gram
- Diskmaskin Monogram
- Diskmaskin Frigidaire
- Diskmaskin Iberna
- Diskmaskin Svan
- Diskmaskin Logik
- Diskmaskin Danby
- Diskmaskin Balay
- Diskmaskin Valberg
- Diskmaskin Stirling
- Diskmaskin PKM
- Diskmaskin Frilec
- Diskmaskin Rosieres
- Diskmaskin Scholtes
- Diskmaskin Profilo
- Diskmaskin KKT Kolbe
- Diskmaskin CDA
- Diskmaskin Imperial
- Diskmaskin Castor
- Diskmaskin Schneider
- Diskmaskin Bella
- Diskmaskin Kenmore
- Diskmaskin Hoover-Helkama
- Diskmaskin Philco
- Diskmaskin Juno
- Diskmaskin Nabo
- Diskmaskin Guzzanti
- Diskmaskin Defy
- Diskmaskin Infiniton
- Diskmaskin Aspes
- Diskmaskin White Knight
- Diskmaskin Sunny
- Diskmaskin Blanco
- Diskmaskin Orima
- Diskmaskin Luxor
- Diskmaskin Nordmende
- Diskmaskin Koenic
- Diskmaskin Mach
- Diskmaskin Haier
- Diskmaskin Friac
- Diskmaskin Boretti
- Diskmaskin Ariston Thermo
- Diskmaskin Viking
- Diskmaskin Hansa
- Diskmaskin Rhima
- Diskmaskin Thor
- Diskmaskin Benavent
- Diskmaskin Exquisit
- Diskmaskin Elba
- Diskmaskin Proline
- Diskmaskin Euromaid
- Diskmaskin Corberó
- Diskmaskin Crosley
- Diskmaskin WLA
- Diskmaskin New Pol
- Diskmaskin Ansonic
- Diskmaskin Kelvinator
- Diskmaskin ETA
- Diskmaskin Element
- Diskmaskin Champion
- Diskmaskin Everglades
- Diskmaskin Qilive
- Diskmaskin Bomann
- Diskmaskin Zerowatt
- Diskmaskin Kuppersbusch
- Diskmaskin Continental Edison
- Diskmaskin Jenn-Air
- Diskmaskin Limit
- Diskmaskin Freggia
- Diskmaskin Insignia
- Diskmaskin Listo
- Diskmaskin Edesa
- Diskmaskin Milectric
- Diskmaskin Leonard
- Diskmaskin Kaiser
- Diskmaskin Franke
- Diskmaskin New World
- Diskmaskin AYA
- Diskmaskin Nodor
- Diskmaskin Sammic
- Diskmaskin Jocel
- Diskmaskin Respekta
- Diskmaskin Electra
- Diskmaskin Rex
- Diskmaskin Comfee
- Diskmaskin Atlantic
- Diskmaskin Meireles
- Diskmaskin Dacor
- Diskmaskin Technika
- Diskmaskin Scandomestic
- Diskmaskin V-Zug
- Diskmaskin Godrej
- Diskmaskin Sauber
- Diskmaskin MPM
- Diskmaskin Zenith
- Diskmaskin Esatto
- Diskmaskin Belling
- Diskmaskin Hobart
- Diskmaskin Essentiel B
- Diskmaskin Team
- Diskmaskin Privileg
- Diskmaskin Vivax
- Diskmaskin Edy
- Diskmaskin Ilve
- Diskmaskin Altus
- Diskmaskin Edgestar
- Diskmaskin CaterChef
- Diskmaskin Parmco
- Diskmaskin Caple
- Diskmaskin Eurotech
- Diskmaskin Equator
- Diskmaskin Jolly
- Diskmaskin Vestfrost
- Diskmaskin Kunft
- Diskmaskin EKU
- Diskmaskin Upo
- Diskmaskin Hestan
- Diskmaskin Elettrobar
- Diskmaskin Scancool
- Diskmaskin Trieste
- Diskmaskin Brandy Best
- Diskmaskin Lynx
- Diskmaskin Barazza
- Diskmaskin Flavel
- Diskmaskin Teco
- Diskmaskin Cecotec
- Diskmaskin Bluesky
- Diskmaskin Otsein
- Diskmaskin Winterhalter
- Diskmaskin Tisira
- Diskmaskin Whynter
- Diskmaskin Icecool
- Diskmaskin Marynen
- Diskmaskin Therma
- Diskmaskin La Germania
- Diskmaskin Oranier
- Diskmaskin CombiSteel
- Diskmaskin Foster
- Diskmaskin Black Decker
- Diskmaskin Eudora
- Diskmaskin Hoonved
- Diskmaskin Kucht
- Diskmaskin Kogan
- Diskmaskin Signature
- Diskmaskin Romo
- Diskmaskin Noble
- Diskmaskin JennAir
- Diskmaskin General Electric
- Diskmaskin Elin
- Diskmaskin Fulgor Milano
- Diskmaskin High One
- Diskmaskin Meiko
- Diskmaskin Curtiss
- Diskmaskin Vedette
- Diskmaskin Winia
- Diskmaskin Deante
- Diskmaskin Artusi
- Diskmaskin Elektron
- Diskmaskin Sôlt
- Diskmaskin Fisher Paykel
- Diskmaskin WEG
- Diskmaskin Casselin
- Diskmaskin Hiberg
- Diskmaskin Bar Maid
- Diskmaskin Cosmo
- Diskmaskin ARC
- Diskmaskin CMA Dishmachines
- Diskmaskin FAURE
- Diskmaskin Novamatic
- Diskmaskin Emilia
- Diskmaskin Miele Professional
- Diskmaskin Home Electronics
- Diskmaskin IFB
- Diskmaskin Newpol
- Diskmaskin Royal Catering
- Diskmaskin SEIKI
- Diskmaskin Cookology
- Diskmaskin Eurolux
- Diskmaskin Euro Appliances
- Diskmaskin Dishlex
- Diskmaskin Arthur Martin-Electrolux
- Diskmaskin Elektra Bregenz
- Diskmaskin InAlto
- Diskmaskin Tuscany
- Diskmaskin Porter & Charles
- Diskmaskin Café
- Diskmaskin Pando
- Diskmaskin Classique
- Diskmaskin Kluge
- Diskmaskin Imarflex
- Diskmaskin Koldfront
- Diskmaskin Master Kitchen
- Diskmaskin Pitsos
- Diskmaskin Helkama
Nyaste Diskmaskin Manualer
9 Januari 2025
9 Januari 2025
9 Januari 2025
9 Januari 2025
9 Januari 2025
9 Januari 2025
9 Januari 2025
9 Januari 2025
9 Januari 2025
9 Januari 2025
