Sida 1/8
CONTENTS OF THE BOX:
• 1 x Quadcopter
• 1 x 2.4 GHz remote (6x AA-batteries not included)
• 1 x 7,4V 1200 mAh Li-po battery
• 4 x Spare propeller
• 1 x Charger
• 1 x Manual
SPECIFICATIONS:
• 2.4GHz Assembled quadcopter drone Ready-to-fly
• 6-axis Gyroscope
• 4 main engines
• 1 Li-po Battery 7,4V 1200mAh
• Height: 110 mm
• Length: 255 mm
• Width: 255mm
• Weight: g
Specifications
Safety precautions
• Children should only use this model under the supervision of an adult
• Keep hands, face, hair and clothes away from blades.
• Stand out of reach of moving parts of the copter
• Always fly in an open and safe environment where you will not cause any danger to others
• For the remote control, we recommend AA batteries with a voltage of 1.5 to 1.2 volts
• Always follow local laws and regulations! Contact your reseller when in doubt.
• This model is not suitable for children under 14 years and contains small parts
• The model and the transmitter must be switched off after use
• For people without experience, we recommend that you learn to fly with an experienced user during your first flights
• Before each flight, test the distance limit of the transmitter
• Keep these instructions safe
• Read the manual carefully and completely
• After using the copter ALWAYS disconnect the battery and remove it from the device
Q212 Spaceship
INSTRUCTION MANUAL
Copyright WLtoys.eu | DroneX BV
The user must return used batteries and rechargeable batteries.
It is forbidden to dispose of used batteries in the bins containing
household waste! Batteries / accumulators containing
hazardous substances are marked with the crossed out wheelie
bin. The symbol indicates that the product should be recycled.
The chemical symbols for the respective hazardous substances
are Cd (cadmium), Hg (mercury), Pb (lead). The used batteries
can be disposed for free of charge at collection points in your
community, stores or wherever batteries are sold. You are kindly
requested to conform to your legal obligations and contribute to
the protection of our environment.
Battery recycling recommendations
- Keep the batteries out of reach of children
- Non-rechargeable batteries should not be recharged
- Always charge the battery to 100%
- Ensure that the battery wires are not in contact to avoid a short-circuit
- Never damage the battery mechanically (this could cause an explosion)
- When charging the battery, always ensure that you do so on a non-combustible surface
- Do not leave charging without supervision
- The ignition wires of the battery must not be modified or damaged
- The battery should not be placed near children (unless you have an adult supervision)
- The technical design of the battery must not be changed
- Touching of damaged batteries can cause injury. If there is contact with skin or eyes, seek medical attention immediately!
- Do not charge directly after the flight or when the battery is warm
DO NOT FLY:
- Around people or animals
- Around large groups of people
- In limited visibility or dark conditions
- Winds above 2 Beaufort
- Near high voltage pylons and / or other types of cabling
- During thunderstorms, rain or high humidity. The device is not water-resistant.
For the sensitive and rational conservation, protection and improvement of the quality of the environment, protection of human
health and the preservation of natural resources, the user must send an unusable product to relevant facilities created to this
purpose in accordance with the law.
The crossed out wheelie bin means that the product must be recycled (WARNING: do not throw it in your bin).
Li-po Battery instructions
- Unequally charged batteries or different battery types should not be used together
Battery charging
- Use recommended batteries or similar
- The terminals must not be short-circuited
- This model is equipped with a rechargeable Li-po Battery. Li-po batteries require special attention, follow the manual
- The batteries must be charged with the charger supplied by WLtoys
- After using the product, remove the batteries if you will not use it again for a long period of time
Copyright WLtoys.eu | DroneX BV
1. LED
2. Li-po Battery
Plug the charger into a wall socket and connect the battery to
the charger. This can only be done in one way: by firmly
connecting the charging cable. If the green light is on, the
battery is fully charged and can be disconnected. Then do not
forget to unplug the charger from the wall socket.
Green LED ON = charging battery
Green LED OFF = charged battery
Green LED flashing = damaged battery
Red LED ON = charger
Red LED OFF = damaged charger / not connected to a wall
socket
Input : 220V
Charging Current : 500mA
Full Voltage: 4.2 +/- 0.03V
1. Power LED
2. Module 1 : Water jet; bubble jet; video; basket up; lead
single missile
3. Throttle/Yaw control stick
4. Throttle trim
5. Yaw trim
6. 40% agility
7. 60% agility
8. 80% agility
9. LCD display
10. Power switch
11. Antenna
12. Roll (when 100%)
13. Direction control stick
14. Forwards and backwards trim
15. Crab trim
16. 100% agility
17. Lighting control
18. Module 2 : Taking photos(Headless mode if available,
press 2 sec)
1. Stick mode 1/3 indicator
2. Throttle trim tips
3. Yaw trim tips
4. Percentage of the reaction
5. Transmitter battery indicator
6. Stick mode 2/4 indicator
7. Forwards and backwards trim tips
8. Crab trim tips
Warning : Always place the battery on a heat resistant surface and never leave it unattended!
Remote Control / Transmitter
Copyright WLtoys.eu | DroneX BV
