Read this manual carefully

before operating this watercraft.

OWNER’S/OPERATOR’S MANUAL

2016 WaveRunner

V1 Sport

F4F-F8199-70-E0

Read this manual carefully before operating this watercraft. This manual

should stay with the WaveRunner if it is sold.

Important manual information

EJU44190

Declaration of Conformity for Personal Watercraft (PWC)

with the requirements of Directive 2013/53/EU

Name of PWC Manufacturer: YAMAHA MOTOR CO., LTD.

Address: 2500 Shingai, Iwata, Shizuoka 438-8501, Japan

Name of Authorised Representative: YAMAHA MOTOR EUROPE N.V.

Address: Koolhovenlaan 101, 1119 NC Schiphol-Rijk, The Netherlands

Name of Notified Body for exhaust and noise emission assessment: SNCH

VX1050D-R / V1 Sport, VX1050E-R / V1

0499ID Number:

Address: 11, route de Luxembourg BP 32, Sandweiler, L-5230. Luxembourg

U S - Y A M A 0 0 0 1 L 5 1 6

Conformity assessment module used:

for construction:

for exhaust emissions:

for noise emissions:

DESCRIPTION OF WATERCRAFT

DESCRIPTION OF ENGINE

Craft Identification Number : starting from

Model name / Commercial name :

CDesign Category :

Other Community Directives applied

Electromagnetic Compatibility Directive 2004/108/EC and 2014/30/EU

EN 55012:2007/A1:2009

Standards

EN 61000-6-2:2005

B+C

B+D

B+E

B+F

Model Name:

6FB

Combustion Cycle:

4 stroke

Fuel Type:

Petrol

ESSENTIAL REQUIREMENTS

Essential requirements Standards Other normative

document / method Technical file Please specify in more detail

(* = mandatory standard)

Annex I.A Design and construction *EN ISO 13590:2003

Annex I.B Exhaust emission *EN ISO 18854:2015

Annex I.C Noise emission *EN ISO 14509

This declaration of conformity is issued under the sole responsibility of the manufacturer. I declare on behalf of the

manufacturer that the PWC(s) mentioned above complies (comply) with all applicable essential requirements in the way

specified.

Name / Title: Y. Henmi / General Manager of Engineering Section, Boat Business Unit

(identification of the person empowered to sign on behalf of the manufacturer)

Signature:

Date and place of issue: January 18 th, 2016, Shizuoka, Japan
