Roma Pro

ZRP-E36BS, ZRP-E48BS

EN Use, Care, and Installation Guide

FR Guide d’utilisation, d’entretien et d’installation

Roma Pro Use, Care, and Installation Guide

ZEPHYRONLINE.COM

Contents

Page

Safety Information 4-6 ............................................................................

Types of Safety Warnings 4 ...................................................................

General Safety 4-5 ..................................................................................

Operation 6 ...........................................................................................

Electrical Requirements 6 ......................................................................

Federal Communication Commission Interface Statement 6 .................

List of Materials 7 ...................................................................................

Installation Instructions 8-16 .....................................................................

Ducting Calculation Sheet 8 ..................................................................

Mounting Height, Clearance, & Ducting ........................................... 9-10

Ducting Options 11 .................................................................................

Hood Speciﬁcations 12 ............................................................................

Electrical Supply 13 .................................................................................

Cable Lock 13 .........................................................................................

Mounting the Hood 14 .............................................................................

PBD-1300B Dual Blower Installation 15-16 .................................................

Features & Controls 17-20 ..........................................................................

Electronic LCD Controls 17-18 ....................................................................

Optional RF Remote Control ............................................................19-20

Maintenance 21-22 ....................................................................................

Hood & Filter Cleaning 21-22 .....................................................................

Swivel LumiLight LED 22 .........................................................................

ACT™ Conversion 23-24 ............................................................................

Airﬂow Control Technology (ACT™) ................................................... 23

Enabling ACT™ .................................................................................. 24

Wiring Diagram .................................................................................. 25

Troubleshooting............................................................................... 26-27

List of Parts & Accessories .................................................................. 28

Limited Warranty 29 ...............................................................................

Product Registration 30 ...........................................................................

4Roma Pro Use, Care, and Installation Guide

R O M A P R O

WA L L

P R O

Safety Information

Your safety and the safety of others are very important.

We have provided many important safety messages in this

manual for your appliance. Always read and obey all safety

messages.

This is the Safety Alert Symbol. This symbol alerts you to

potential hazards that can cause severe bodily injury or death.

All safety messages will follow the Safety Alert Symbol and either

the words “DANGER WARNING CAUTION” “ ” or “ ”

DANGER

Danger means that failure to heed this safety statement may

result in severe injury or death.

READ AND SAVE THESE INSTRUCTIONS

WARNING - TO REDUCE THE RISK OF FIRE, ELECTRIC SHOCK,

OR INJURY TO PERSONS, OBSERVE THE FOLLOWING:

a) Use this unit only in the manner intended by the

manufacturer. If you have questions, contact the manufacturer.

b) Before servicing or cleaning unit, switch power o at service

panel and lock the service disconnecting means to prevent

power from being switched on accidentally. When the service

disconnecting means cannot be locked, securely fasten a

prominent warning device, such as a tag, to the service panel.

General Safety

WARNING

Warning means that failure to heed this safety statement

may result in extensive product damage, serious personal

injury, or death.

CAUTION

Caution means that failure to heed this safety statement

may result in minor or moderate personal injury, property or

equipment damage.

WARNING

To reduce the risk of ﬁre or electric shock, do not use this fan

with any solid-state control device.

WARNING

CAUTION

For General Ventilating Use Only. Do Not Use To Exhaust

Hazardous Or Explosive Materials And Vapors. Take care

when using cleaning agents or detergents. Suitable for use in

household cooking area.

WARNING

WARNING - TO REDUCE THE RISK OF A RANGE TOP GREASE

FIRE:

a) Never leave surface units unattended at high settings.

Boilovers cause smoking and greasy spillovers that may ignite.

Heat oils slowly on low or medium settings.

b) Always turn hood ON when cooking at high heat or

when ﬂambeing food. (i.e. Crepes Suzette, Cherries Jubilee,

Peppercorn Beef Flambe’).

c) Clean ventilating fans frequently. Grease should not be

allowed to accumulate on fan or ﬁlter.

d) Use proper pan size. Always use cookware appropriate for

the size of the surface element.
