O M B R A
W A L L
C O R E
Ombra is the perfect combination
of form and function with its ca-
pacitive touch controls and optional
hybrid bae lters. Ombra features
a powerful 600 CFM blower with
our exclusive Airow Control Tech-
nology™ (ACT™) to meet local code
requirements. Available in sleek black
stainless steel and stainless steel.
TOP
FRONT
SIDE
8 3/4”
12”
29 , 35 ”7/8” 7/8
7/8”
6”
Standard
min. ducted - 27 1/2”
min. recirc - 32”
max. 42 1/2”
Z1C-01OMS
Z1C-01OMBS
min. ducted - 46 1/2”
min. recirc. - 50 1/2”
max. 80”
1 9/16”
19 3/4”
6 7/8”
TM
C
INTERNAL BLOWER
STANDARD
INTERNAL BLOWER with ACT™
AIRFLOW CONTROL TECHNOLOGY™*
Min. - Max. CFM
Min. - Max. Sones
200 - 600
1 - 6
*AIRFLOW CONTROL TECHNOLOGY™ (ACT™)
200 - 390
1 - 4
200 - 290
1 - 3
ZEPHYRONLINE.COM
is an exclusive feature built into specic Zephyr hoods which can
limit the maximum blower CFM to meet local code requirements.
Shown in Black Stainless Steel
Shown in Stainless Steel

O M B R A
W A L L
C O R E
Specications subject to change, check zephyronline.com for up-to-date information.
Zephyr Ventilation | 2277 Harbor Bay Parkway, Alameda, CA 94502 | 888.880.VENT
SEP18.0101
CEILING HEIGHT
DUCT COVER
EXTENSION
STANDARD
DUCT COVER
Ducted Mounting Height**
Recirc Mounting Height**
Ducted Mounting Height**
Recirc Mounting Height**
MODEL
Stainless Steel
Black Stainless Steel
Size
Blower CFM (Min. - Max.)
Sones (Min. - Max.)
ACT 390 CFM (Min. - Max.)
ACT 390 Sones (Min. - Max.)
ACT 290 CFM (Min. - Max.)
ACT 290 Sones (Min. - Max.)
FEATURES
ACT™ Technology
Controls
Speed Levels
Auto Delay-O
Lighting
Dual-Level Lighting
Filters
Recirculating Option
Duct Cover Extension Option
DUCT SPECIFICATIONS
Vertical Internal Blower
Horizontal Internal Blower
AC POWER
OPTIONAL ACCESSORIES
Recirculating Kit
Duct Cover Extension
Bloom™ GU10 LED
Hybrid Bae Filter Kit
Make-Up Air Kit
MOUNTING HEIGHT RANGE**
WARRANTY
ZOM-E30AS
ZOM-E30ABS
30”
200 - 600
1 - 6
200 - 390
1 - 4
200 - 290
1 - 3
Yes
Capacitive Touch
4*
Yes
Halogen, 35W x2
Yes
Aluminum Mesh x2
Yes
Yes, Up to 12’ Ceiling
6” Round
NA
120V, 60Hz at Max. 3.5A
ZRC-01OM
Z1C-01OMS (ss)
Z1C-01OMBS (black ss)
Z0B0040
Z0F-B002
MUA006A
26” - 34”
3 years parts, 1 year labor
*When ACT™ is enabled the maximum speed levels will change. ACT 390 CFM = 3 speeds and ACT 290 CFM = 2 speeds.
**Mounting height refers to distance between top of a 36” tall cooking surface and bottom of hood.
ZOM-E36AS
ZOM-E36ABS
36”
200 - 600
1 - 6
200 - 390
1 - 4
200 - 290
1 - 3
Yes
Capacitive Touch
4*
Yes
Halogen, 35W x2
Yes
Aluminum Mesh x2
Yes
Yes, Up to 12’ Ceiling
6” Round
NA
120V, 60Hz at Max. 3.5A
ZRC-01OM
Z1C-01OMS (ss)
Z1C-01OMBS (black ss)
Z0B0040
Z0F-B002
MUA006A
26” - 34”
3 years parts, 1 year labor
8.5’
26” - 34”
26” - 34”
NA
NA
8’
26” - 33.5”
26” - 28.5”
NA
NA
9’
29.5” - 34”
29.5” - 34”
26” - 30.5”
26” - 26”
9.5’
NA
NA
26” - 34”
26” - 32”
10’
NA
NA
26” - 34”
26” - 34”
10.5’
NA
NA
26” - 34”
26” - 34”
11’
NA
NA
26” - 34”
26” - 34”
12’
NA
NA
28” - 34”
28” - 34”
AIRFLOW CONTROL TECHNOLOGY™ (ACT™)
TM
C
ZEPHYRONLINE.COM
is an exclusive feature built into specic Zephyr hoods which can
limit the maximum blower CFM to meet local code requirements.
