Sida 1/4

IP Mini Dome 2 MPx (1080p, 4 mm)

Art. no. IPCB42510B

• 2 MPx (Full HD 1080p) resolution: 1920 x 1.080 @ 30 fps

• 4 mm fixed lens

• Ultra low-light performance for excellent results in low-light environments

• 120 dB WDR function to compensate for image contrasts

• Vandalism and weather protected housing (IK08 & IP66)

• IR LEDs (range up to 10m)

• Supports H.264, H.265, MJPEG (incl. dynamic GOP)

• microSD card slot for internal data storage

• 12 V DC & PoE (802.3af)

Due to its compact dimensions, the IP Mini Dome is a discreet surveillance camera for outdoor and indoor use.

The dome is available in several versions with different fixed lenses from 2.8 mm (IPCB42510A) to 4 mm

(IPCB42510B) and even 6mm (IPCB42510C).Discreet Full HD 24/7 outdoor surveillanceThe IP Mini Dome provides

video streams in 2 MPx resolution with up to 30 fps. The weatherproof IP66 housing allows outdoor use. Due to

integrated IR LEDs, the camera can be also used day and night. Access to the camera is possible at any time via

app.3 lens variants for maximum flexibilityThe IP Mini Dome is available in 3 versions with different fix lenses.

Therefore, the camera offers maximum flexibility in the planning and installation of video surveillance projects.

The IP Mini Dome IPCB42510A with a 2.8 mm fixed lens and a horizontal viewing angle of 108° is ideal for

wide-angle surveillance scenes. The IP Mini Dome IPCB42510C with a 6 mm fixed lens and a horizontal viewing

angle of 53° is a popular variant for installation in corridors.Recording and compatibilityThe recording can be

done either on an ABUS recorder, 3rd party video management software or locally on a microSD card.

Furthermore, the camera is compatible with the ABUS Secvest alarm center and the ABUS access control system

wAppLoxx.Comfortable installationThe IP Mini Dome is mounted on the ceiling or optionally with a bracket on

the wall. We recommend our installation box (TVAC31460) and the wall bracket (TVAC31450). The free “ABUS IP

Installer” software is available for simple setup in the network. The software finds the camera quickly and easily

within the network and supports during the installation process.ABUS Link Station App: Live Access &

Push-NotificationsThis camera is compatible with the ABUS Link Station App. The app provides easy online access

to the camera – directly without intricate adjustments or portforwarding. It also provides a simple solution for

Page 1 of 4

Technical alterations reserved. Misprints and errors excepted. Copyright. © ABUS 11/2023

IP Mini Dome 2 MPx (1080p, 4 mm)

Art. no. IPCB42510B

internet connections with IPv6 adresses. The app allows live view, plays recorded videos and photos and

supports push notifications in case of an event.Note: The camera does not come with a power supply, as it can

be powered via PoE.The effective IR range will depend on the installation location. If there are surfaces that

absorb light or no objects that reflect IR light in the field of view, the IR range will be reduced and/or the video

image will be too dark. Reflective objects in the immediate vicinity of the camera (e.g. roof gutter or wall) may

also result in the reflection of IR light, which can disturb the image.

Page 2 of 4

Technical alterations reserved. Misprints and errors excepted. Copyright. © ABUS 11/2023

IP Mini Dome 2 MPx (1080p, 4 mm)

Art. no. IPCB42510B

Technical Data:

Protection class IK 8

ONVIF Profile G, S, T

Colour RAL9003

Image enhancement WDR, BLC, HLC, 3D DNR,

Vertical Display

Video Content Analysis

(VCA)

Tripwire Detection,

Intrusion Detection

ICR day/night function Yes

Technology IP

Design Dome

Compatible with Secvest Yes

Compatible with wAppLoxxYes

Vertical viewing angle 45 °

Other functions Auto Backup Recording,

Secvest Connectivity

Compatible with wAppLoxx

Pro

Yes

Compatible with ABUS Link

Station

Yes

Dimensions (LxWxH)97x100x53 mm

Alarming E-Mail, NAS, FTP

Connections 1 x RJ45, 1 x DC

Number of users 32

Number of IR LEDs 10

Resolution 2MPx

Resolution modes Stream 1: 1.920 x 1.080 @

25 fps, Stream 2: 640 x 480

@ 25 fps, Stream 3: 1.920 x

1.080 @ 25 fps

Motion detection 8 zones

Image sensor 1/2.8" Progressive Scan

CMOS

Pixels (effective) 1920(H) x 1080(V) pixel

Frame rate 1/16, 1/8, 1/4, 1/2, 1, 2, 4, 6,

8, 10, 12, 15, 16, 18, 20, 22,

25, 30 fps

Aperture at minimum

illumination (colour)

F1.6

Width 100 mm

Focal length 4 mm

Dynamic range (WDR) 120 dB

Electronic shutter 1/3 - 1/100000 s

Functions Scene Change Detection

Backlight compensation WDR, BLC, HLC

Simultaneous network

access

Height 53 mm

Horizontal viewing angle 87 °

IR LEDs Yes

IR range (up to) 10 m

Camera type Mini Dome

Compatible with NVR, Hybrid DVR, IPCam

Plus

Length 97 mm

Power consumption 9,5 W

Max. resolution @ frame

rate

1920 x 1080 @ 30 fps

Max. operating

temperature

60 °C

Max. humidity 95 %

Microphone No

Min. operating

temperature

-30 °C

Minimum illumination

(colour)

0,009 lx

Minimum illumination (IR) 0 lx

Net weight 0,4 kg

Video network bandwidth32 kBit/s - 16 MBit/s

Network access RJ45

LAN network access RJ45 10M/100M

self-adaptive

Network camera protocols IPv4/v6, HTTP, HTTPS, FTP,

SMTP, UPnP, DNS, DynDNS,

NTP, RTSP, TCP, UDP, DHCP,

ONVIF Profile S, ONVIF

Profile G, ABUS Server,

Secvest Link

Lens Fix

Lens mount M12

PoE standard IEEE 802.3af

Private zones 4

Noise reduction 3D DNR

Page 3 of 4
