Sida 1/8
AD- 400
CD Player with USB/SD and FM Tuner
Item ref: 2.982 95 UK
User Manual
Version 1.1
Caution: Please read this manual carefully before operating
Damage caused by misuse is not covered by the warranty
952.982 User Manual UK
Introduction
Thank you for choosing the Adastra -400 CD player with USB/SD and FM tuner as a professional audio AD
source. This unit is designed to offer high quality playback of digital audio media and FM radio stations .
Please read this manual to gain the best results from your product and avoid damage through misuse.
SAFETY SYMBOL AND MESSAGE CONVENTIONS
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
AVIS
RISQUE DE CHOC ELECTRIQUE NE PAS
OUVRIR
This symbol indicates that dangerous voltage constituting a risk of electric shock is
present within this unit
This symbol indicates that there are important operating and maintenance instructions in
the literature accompanying this unit.
SAFETY NOTICE
1. Prior to use, read through this manual
2. Keep the manual in good condition
3. Pay attention to safety warnings
4. Observe all operating requirements
5. Do not use the device near water or wet areas
6. For cleaning, only use a lint-free, dry cloth
7. Install according to the specifications
8. Place away from heat sources or heating appliances
9. Use mains lead provided and avoid damage to cable or connectors
10. Unplug power from mains during stormy weather or if unused for long periods
11. In case of malfunction, water ingress or other damage, consult qualified service personnel
12. Do not place in damp areas or near liquids or moisture. Do not spill liquids on the housing
13. Please pay attention to warning symbols during transit and placement
14. Terminals marked with the symbol are HAZARDOUS LIVE and should only be connected by qualified personnel
15. Ensure that the apparatus is connected to a mains socket with a protective EARTH connection
16. Ensure correct operation of the mains switch
Warning
To prevent the risk of fire or electric shock, do not expose any components to rain or moisture.
If liquids are spilled on the casing, stop using immediately, allow unit to dry out and have checked by qualified personnel before
further use. Avoid impact, extreme pressure or heavy vibration to the case
Do not allow foreign objects into the CD slot or USB/SD inputs.
No user serviceable parts inside Do not open the case refer all servicing to qualified service personnel. – –
Safety
• Check for correct mains voltage and condition of IEC lead before connecting to power outlet
Placement
• This unit can be used free-standing o r fixed into a 19” rack
• Ensure adequate support and access to controls and connectors when rack-mounting
Cleaning
• Use a soft cloth with a neutral detergent to clean the housing as required
• Use a vacuum cleaner to clear apertures and controls of any dust or debris build-ups
• Do not use strong solvents for cleaning the unit
952.982 User Manual UK
Front panel
Rear panel
Connection
Ensure the Power ( ) is switched off and connect the supplied IEC mains lead into the power inlet (20) with 12
the plug top into a suitable mains power outlet.
Connect the output from the AD-400 to a mixer or amplifier line input using the RCA output connectors (22) or
if available, using the optical digital output connector (23).
If the FM radio is to be used, connect an external aerial or antenna to the FM Antenna connector (24).
For installations where the AD-400 may be away from line-of-sight, an I.R. remote eye is provided, which can
be connected to the IR Remote connector (21).
1.
SD Card slot
11.
Mute/Power
2.
USB input
12.
Power on/off switch
3.
CD slot
13.
Numerical track select
4.
LCD display
14.
Random play
5.
I.R. remote detector
15.
Repeat mode
6.
Eject
16.
Reverse - /Seek
7.
Play/Pause
17.
Forward + /Seek
8.
Stop
18.
CD/USB/SD select
9.
Previous (track/channel)
19.
FM tuner select
10.
Next (track/channel)
20.
Mains power inlet IEC and fuse holder
23.
Optical digital audio output
21.
I.R. remote eye connection
24.
FM antenna connection (F-type)
22.
Left + Right RCA outputs
