L01
Portable Megaphone
Item ref: 952.001 UK
User Manual
Version 1.2
Caution: Please read this manual carefully before operating
Damage caused by misuse is not covered by the warranty
952.001UK User Manual
Introduction
Thank you for choosing the Adastra L01 portable megaphone for voice reinforcement.
This product is designed to offer convenient and easy operation for a wide range of portable public
address requirements. Please use the instructions to gain the best results from your L01 megaphone. se
Safety
The L01 megaphone can produce high sound pressure levels at close quarters. Please be aware not to aim
the horn flare toward listeners at close proximity, which may risk damage to the listeners’ hearing.
The L01 operates from cell batteries. It is advised to use alkaline or NiMH batteries and remove 4 x “C”
these when not in use for long periods of time. Some batteries can leak fluids which are corrosive and can
cause damage to the internal circuitry.
Positioning during operation
When in use, the hand grip of the megaphone should be folded out fully and held firmly with the flare
facing toward the audience. Keeping the strap around the wrist is advised for added security. In loop
between uses, the megaphone can be placed on a flat surface with the flare facing downward, protected
by the rubber trim around the flare edge.
Cleaning
The housing is water resistant and can be cleaned with a damp cloth. Do not use detergents or solvents
on the housing and take care not to allow liquids to get inside the housing at the rear or via the battery
compartment.
952.001UK User Manual
Rear control panel
Setting up
Before operating the L01 megaphone, it will be necessary to load it with 4 x “C” cell batteries.
To access the rear battery compartment, press the battery compartment release button (5) and the rear
section of the megaphone will flip upwards to reveal the battery holder.
Load in the C cell batteries with alternate polarities as shown in the diagram below. Note the imprinted
“+” and “ ” symbols inside the compartment and ensure that the correct polarities are observed.-
Fold down the rear section to cover the battery compartment until it clicks firmly shut.
1.
Microphone
2.
LED indicator
3.
Volume control
4.
Speech / Off / Siren switch
5.
Battery compartment release button
