User Instructions
12/16
Caution: Fog Machines may set o Smoke Alarms!
ENTOUR VENUE
©2016 ADJ Products, LLC all rights reserved. Information,
specications, diagrams, images, and instructions herein are
subject to change without notice. ADJ Products, LLC logo and
identifying product names and numbers herein are trademarks
of ADJ Products, LLC. Copyright protection claimed includes all
forms and matters of copyrightable materials and information
now allowed by statutory or judicial law or hereinafter granted.
Product names used in this document may be trademarks or
registered trademarks of their respective companies and are
hereby acknowledged. All non-ADJ Products, LLC brands and
product names are trademarks or registered trademarks of their
respective companies.
ADJ Products, LLC and all aliated companies hereby dis-
claim any and all liabilities for property, equipment, building, and
electrical damages, injuries to any persons, and direct or indi-
rect economic loss associated with the use or reliance of any
information contained within this document, and/or as a result
of the improper, unsafe, unsucient and negligent assembly,
installation, rigging, and operation of this product.
Europe Energy Saving Notice
Energy Saving Matters (EuP 2009/125/EC)
Saving electric energy is a key to help protecting the enviroment.
Please turn o all electrical products when they are not in use. To
avoid power consumption in idle mode, disconnect all electrical
equipment from power when not in use. Thank you!
ADJ Products, LLC - www.adj.com - Entour Venue Instruction Manual Page 6 ADJ Products, LLC - www.adj.com - Entour Venue Instruction Manual Page 7
Entour Venue Layout
A. Hanging Bracket
B. Unique Anti-Spill Tank
C. Quick Connector
D. Blue LCD Screen
E. 6 Buttons of Control
F. DMX 5-Pin XLR Output
G. DMX 5-Pin XLR Input
H. DMX 3-Pin XLR Output
I. DMX 3-Pin XLR Input
J. Breaker
K. Power Cord
L. Fog Output
M. Sponge
N. Sitting Feet
O. Ventilation
A
C
B
D
O
M
E
N
F
N
GHIJK
M
L
L
Entour Venue Layout
A. Hanging Bracket
B. Unique Anti-Spill Tank
C. Quick Connector
D. Blue LCD Screen
E. 6 Buttons of Control
F. DMX 5-Pin XLR Output
G. DMX 5-Pin XLR Input
H. DMX 3-Pin XLR Output
H. DMX 3-Pin XLR Output
I. DMX 3-Pin XLR Input
J. Breaker
K. PowerCon Input
L. Fog Output
M. Sponge
N. Sitting Feet
O. Ventilation
A
C
B
D
O
M
E
N
F
N
GHIJK
M
L
L
US Version European Version
ADJ Products, LLC - www.adj.com - Entour Venue Instruction Manual Page 8 ADJ Products, LLC - www.adj.com - Entour Venue Instruction Manual Page 9
Entour Venue General Set-Up
1. Open the shipping carton and carefully remove the unit from the shipping
carton.
2. Be sure to remove all the packing material especially around the nozzle.
3. Set the fog machine on a flat dry surfaceand fill the fog fluid reservoir with
American DJ brand fog juice. Place the feeder tube with the filter deep
inside the reservoir and tighten the cap.
4. Plug the unit in to a matching power supply and the unit will begin to heat
up. Wait about 45 seconds for the fogger to reach normal operating
temperature.
5. Follow the operating instructions on the next pages for proper operation.
Entour Venue Control Panel
Fan Speed
& Volume Adjustment
Increasing numerical value for Function
Decreasing numerical value
for Function
Timer Fog,
adjustable by Function Button
Constant Fog, adjustable by Function Button
Manual Fog,
Max. Fan Speed & Volume
Version:
1.0
Warming
Up……
Entour Venue Start Up
START UP:
1. Connect the provided PowerCon cable to the fog machine
input. Then plug the power cord into a matching power
source. There is no ON/OFF switch.
2. Primary power is now “On”.
3. 2 Seconds after power is applied the unit
will begin to warm up.
Entour Venue CAD Drawing
253mm/9.96” 434mm/17”
394mm/15.5”
