User Instructions

9/14

specications, diagrams, images, and instructions herein are

subject to change without notice. ADJ Products, LLC logo and

identifying product names and numbers herein are trademarks

of ADJ Products, LLC. Copyright protection claimed includes all

forms and matters of copyrightable materials and information

now allowed by statutory or judicial law or hereinafter granted.

Product names used in this document may be trademarks or

registered trademarks of their respective companies and are

hereby acknowledged. All non-ADJ Products, LLC brands and

product names are trademarks or registered trademarks of their

respective companies.

ADJ Products, LLC and all aliated companies hereby dis-

claim any and all liabilities for property, equipment, building,

and electrical damages, injuries to any persons, and direct or

indirect economic loss associated with the use or reliance of

any information contained within this document, and/or as a

result of the improper, unsafe, unsucient and negligent as-

sembly, installation, rigging, and operation of this product.

Europe Energy Saving Notice

Energy Saving Matters (EuP 2009/125/EC)

Saving electric energy is a key to help protecting the enviroment.

Please turn o all electrical products when they are not in use. To

avoid power consumption in idle mode, disconnect all electrical

equipment from power when not in use. Thank you!

Inno Pocket Wash

ADJ Products, LLC - www.adj.com - Inno Pocket Wash Instruction Manual Page 3ADJ Products, LLC - www.adj.com - Inno Pocket Wash Instruction Manual Page 2

• DMX-512 Protocol Compatible (4 DMX Channel Modes: 9 Chan-

nels, 11 Channels, 19 Channels, & 21 Channels)

• 3 Operating Modes - Sound Active, Show Mode, & DMX Control

• 5 Dimmer Curves (Standard, Stage, TV, Architectural, & Theatre)

• Internal Microphone

• Digital Display for Address and Function Setting

• 4 Preprogrammed Shows

• UC-IR Compatiable (Not Included)

Inno Pocket Wash Features

Caution! There are no user serviceable parts inside this unit. Do not

attempt any repairs yourself, doing so will void your manufactures

warranty. In the unlikely event your unit may require service please

contact ADJ Products, LLC.

During operation the housing may become extremely hot. Avoid

touching the unit with bare hands while in use.

ADJ Products, LLC will not accept any liability for any resulting dam-

ages caused by the non-observance of this manual or any unauthor-

ized modication to this unit.

Inno Pocket Wash Handling Precautions

Inno Pocket Wash Warranty Registration

The Inno Pocket Wash 2 year (730 days) limited warranty. carries a

Please fill out the enclosed warranty card to validate your purchase

and warranty. You may also register your product online at www. adj-

products.com. All returned service items whether under warranty or

not, must be freight pre-paid and accompany a return authorization

(R.A.) umber. If the unit is under warranty you must provide an copy

of your proof of purchase invoice. Please contact ADJ Products, LLC

customer support for a R.A. number.

To optimize the performance of this product, please read these

operating instructions carefully to familiarize yourself with the basic

operations of this unit. These instructions contain important safety

information regarding the use and maintenance of this unit. Please

keep this manual with the unit, for future reference.

Inno Pocket Wash General Instructions

Inno Pocket Wash General Information

Unpacking: Thank you for purchasing the Inno Pocket Wash by ADJ

Products, LLC. Every Inno Pocket Wash has been thoroughly tested

and has been shipped in perfect operating condition. Carefully check

the shipping carton for damage that may have occurred during ship-

ping. If the carton appears to be damaged, carefully inspect your x-

ture for any damage and be sure all equipment necessary to operate

the unit has arrived intact. In the event damage has been found or parts

are missing, please contact our toll free customer support number for

further instructions. Please do not return this unit to your dealer with-

out contacting customer support rst.

Introduction: The Inno Pocket Wash is a DMX intelligent, moving

head, mini LED was. The Inno Pocket Wash can operate as a stand

alone fixture or in a Master/Slave set up. The Inno Pocket Wash has

three operating modes; a sound active, show mode, DMX controlled.

This fixture is suitable for theaters, studios, retail stores, and other

similar locations. For best results use fog or special effects smoke to

enhance the beams projections.

Customer Support: ADJ Products, LLC provides a toll free cus-

tomer support line, to provide help and to answer any question should

you encounter problems during your set up or initial operation. You

may also visit us on the web at www.adj.com for any comments or

suggestions. Service Hours are Monday through Friday 8:00 a.m. to

4:30 p.m. Pacic Standard Time.

Voice: (800) 322-6337

Fax: (323) 582-2941

E-mail: support@americandj.com

Warning! To prevent or reduce the risk of electrical shock or re, do

not expose this unit to rain or moisture.

Warning! This may cause severe eye damage. Avoid looking directly

into the light source at all times!

For Your Own Personal Safety, Please Read and Understand This

Manual Completely Before You Attempt To Install Or Operate

This Unit!

• To reduce the risk of electrical shock or re, do not expose this unit

rain or moisture

• Do not spill water or other liquids into or on to your unit.

• Be sure that the local power outlet match that of the required volt-

age for your unit.

• Do not attempt to operate this unit if the power cord has been

frayed or broken.

• Do not attempt to remove or break o the ground prong from

the electrical cord. This prong is used to reduce the risk of electrical

shock and re in case of an internal short.

• Disconnect from main power before making any type of connection.

• Do not remove the cover under any conditions. There are no user

serviceable parts inside.

• Never operate this unit when it’s cover is removed.

• Always be sure to mount this unit in an area that will allow proper

ventilation. Allow about 6” (15cm) between this device and a wall.

• Do not attempt to operate this unit, if it becomes damaged.

• This unit is intended for indoor use only, use of this product out-

doors voids all warranties.

• Always mount this unit in safe and stable matter.

• Power-supply cords should be routed so that they are not likely to

be walked on or pinched by items placed upon or against them,

paying particular attention to cords at plugs, convenience recep-

tacles, and the point where they exit from the appliance.

• Cleaning -The fixture should be cleaned only as recommended by

the manufacturer. See page 29 for cleaning details.

• Heat -This fixture should be situated away from heat sources such

as radiators, heat registers, stoves, or other appliances (including

amplifiers) that produce heat.

• The fixture should be serviced by qualified service personnel when:

A. Objects have fallen, or liquid has been spilled into the appliance.

B. The appliance has been exposed to rain or water.

C. The appliance does not appear to operate normally or exhibits

a marked change in performance.

Inno Pocket Wash Safety Precautions

ADJ Products, LLC - www.adj.com - Inno Pocket Wash Instruction Manual Page 5ADJ Products, LLC - www.adj.com - Inno Pocket Wash Instruction Manual Page 4

The Inno Pocket Wash is fully operational in two dierent mounting

positions, hanging upside-down from a ceiling or set on a at level

surface. To avoid internal damage to the unit, never mount the unit on

its side as illustrated above. Be sure this xture is kept at least 0.5m

away from any ammable materials (decoration etc.). Always use

and install the supplied safety cable as a safety measure to prevent

accidental damage and/or injury in the event the clamp fails (see next

page).

When installing the unit, the trussing or area of installation must be

able to hold 10 times the weight without any deformation. When

installing the unit must be secured with a secondary safety attach-

ment, e.g. and appropriate safety cable. Never stand directly below
