User Instructions

7/14

ULTRA HEX BAR 6

ADJ Products, LLC

6122 S. Eastern Ave. Los Angeles, CA 90040 USA

Tel: 323-582-2650 / Fax: 323-725-6100

Web: www.adj.com / E-mail: info@americandj.com

A.D.J. Supply Europe B.V.

Junostraat 2

6468 EW Kerkrade

Netherlands

service@adjgroup.eu / www.adj.eu

Tel: +31 45 546 85 00 / Fax: +31 45 546 85 99

Ultra Hex Bar 6 Specifications

Model: Ultra Hex Bar 6

Voltage: 100V ~ 240V/50~60Hz

LEDs: 6 x 10W 6-in- Hex LED’s

Beam Angle: 40 Degrees

Working Position: Any safe working position

Power Draw: 55W

Power Cord Daisy Chain: 12 Fixtures Max.

Fuse: 2 Amp

Weight: 6lbs./ 2.82Kgs.

Dimensions: 23” (L) x 4.5” (W) x 6.5” (H)

585 x 110 x 165mm

Colors: RGBAW + UV Color Mixing

DMX Channels: 5 DMX Modes: 6 Channel Mode,

7 Channel Mode, 8 Channel Mode,

12 Channel Mode, & 18 Channel

Mode

Warranty: 2 Year (730 days)

Please Note: Specications and improvements in the design of

this unit and this manual are subject to change without any prior

written notice.

Auto Sensing Voltage: This xture contains a automatic voltage

switch, which will auto sense the voltage when it is plugged into

the power source.

specications, diagrams, images, and instructions herein are

subject to change without notice. ADJ Products, LLC logo and

identifying product names and numbers herein are trademarks

of ADJ Products, LLC. Copyright protection claimed includes all

forms and matters of copyrightable materials and information

now allowed by statutory or judicial law or hereinafter granted.

Product names used in this document may be trademarks or

registered trademarks of their respective companies and are

hereby acknowledged. All non-ADJ Products, LLC brands and

product names are trademarks or registered trademarks of their

respective companies.

ADJ Products, LLC and all aliated companies hereby dis-

claim any and all liabilities for property, equipment, building, and

electrical damages, injuries to any persons, and direct or indi-

rect economic loss associated with the use or reliance of any

information contained within this document, and/or as a result

of the improper, unsafe, unsucient and negligent assembly,

installation, rigging, and operation of this product.

Europe Energy Saving Notice

Energy Saving Matters (EuP 2009/125/EC)

Saving electric energy is a key to help protecting the enviroment.

Please turn o all electrical products when they are not in use. To

avoid power consumption in idle mode, disconnect all electrical

equipment from power when not in use. Thank you! ADJ Products, LLC - www.adj.com - Ultra Hex Bar 6 User Manual Page 22

Ultra Hex Bar 6 Warranty

MANUFACTURER’S LIMITED WARRANTY

A. ADJ Products, LLC hereby warrants, to the original purchaser, ADJ Products, LLC products

to be free of manufacturing defects in material and workmanship for a prescribed period from

the date of purchase (see specific warranty period on reverse). This warranty shall be valid only if the

product is purchased within the United States of America, including possessions and

territories. It is the owner’s responsibility to establish the date and place of purchase by acceptable

evidence, at the time service is sought.

B. For warranty service you must obtain a Return Authorization number (RA#) before sending back the

product–please contact ADJ Products, LLC Service Department at 800-322-6337. Send the product

only to the ADJ Products, LLC factory. All shipping charges must be pre-paid. If the requested repairs or

service (including parts replacement) are within the terms of this warranty, ADJ Products, LLC will pay

return shipping charges only to a designated point within the United States. If the entire instrument is

sent, it must be shipped in it’s original package. No accessories should be shipped with the product. If

any accessories are shipped with the product, ADJ Products, LLC shall have no liability whatsoever for

loss of or damage to any such accessories, nor for the safe return thereof.

C. This warranty is void if the serial number has been altered or removed; if the product is modified in any

manner which ADJ Products, LLC concludes, after inspection, affects the reliability of the product; if the

product has been repaired or serviced by anyone other than the ADJ Products, LLC factory unless prior

written authorization was issued to purchaser by ADJ Products, LLC; if the product is damaged because

not properly maintained as set forth in the instruction manual.

D. This is not a service contract, and this warranty does not include maintnance, cleaning or periodic check

up. During the period specified above, ADJ Products, LLC will replace defective parts at its expense

with new or refurbished parts, and will absorb all expenses for warranty service and repair labor by

reason of defects in material or workmanship. The sole responsibility of ADJ Products, LLC under this

warranty shall be limited to the repair of the product, or replacement thereof, including parts, at the sole

discretion of ADJ Products, LLC. All products covered by this warranty were manufactured after August

15, 2012, and bear indentifying marks to that effect.

E. ADJ Products, LLC reserves the right to make changes in design and/or improvements upon its products

without any obligation to include these changes in any products theretofore manufactured.

No warranty, whether expressed or implied, is given or made with respect to any accessory supplied with

products described above. Except to the extent prohibited by applicable law, all implied warranties made

by ADJ Products, LLC in connection with this product, including warranties of merchantability or fitness,

are limited in duration to the warranty period set forth above. And no warranties, whether expressed or

implied, including warranties of merchantability or fitness, shall apply to this product after said period

has expired. The consumer’s and/or Dealer’s sole remedy shall be such repair or replacement as is

expressly provided above; and under no circumstances shall ADJ Products, LLC be liable for any loss or

damage, direct or consequential, arising out of the use of, or inability to use, this product.

This warranty is the only written warranty applicable to ADJ Products, LLC Products and

supersedes all prior warranties and written descriptions of warranty terms and conditions heretofore

published.

MANUFACTURER’S LIMITED WARRANTY PERIODS:

 •LightingProducts=1-year(365days)LimitedWarranty(Such as: Special Effect Lighting, Intelligent

Lighting, UV lighting, Strobes, Fog Machines, Bubble Machines, Mirror Balls, Par Cans, Trussing,

Lighting Stands etc. excluding LEDs and lamps)

 •LaserProducts=90-DayLimitedWarranty

 •L.E.D.Products=2-year(730days)LimitedWarranty(excluding motors, PCB boards, and power

supplies, which have a 1-year (365 day Limited Warranty) and batteries which have a 180 day

limited warranty).

Ultra Hex Bar 6 Introduction

ADJ Products, LLC - www.adj.com - Ultra Hex Bar 6 User Manual Page 2

Unpacking: Thank you for purchasing the Ultra Hex Bar 6 by ADJ

Products, LLC. Every Ultra Hex Bar 6 has been thoroughly tested and

has been shipped in perfect operating condition. Carefully check the

shipping carton for damage that may have occurred during shipping.

If the carton appears to be damaged, carefully inspect your xture for

any damage and be sure all accessories necessary to operate the unit

has arrived intact. In the case damage has been found or parts are

missing, please contact our toll free customer support number for fur-

ther instructions. Do not return this unit to your dealer without rst con-

tacting customer support.

Introduction: The Ultra Hex Bar 6 is a DMX intelligent, LED bar fix-

ture. This xture can be used in a stand alone mode or connected in a

Master/Slave conguration. This par has six operating modes: Sound

Active mode, Auto mode, Program mode, RGBWA + UV dimmer mode,

Static Color mode, and DMX control mode.

Customer Support: ADJ Products, LLC provides a customer support

line, to provide set up help and to answer any question should you

encounter problems during your set up or initial operation. You may

also visit us on the web at www.adj.com for any comments or sugges-

tions. Service Hours are Monday through Friday 8:00 a.m. to 4:30 p.m.

Pacic Standard Time.

Voice: (800) 322-6337

Fax: (323) 582-2941

E-mail: support@americandj.com

Warning! To prevent or reduce the risk of electrical shock or re, do

not expose this unit to rain or moisture.

Caution! There are no user serviceable parts inside this unit. Do not

attempt any repairs yourself, doing so will void your manufactures war-

ranty. In the unlikely event your unit may require service please contact

ADJ Products, LLC.

PLEASE recycle the shipping carton when ever possible.

ADJ Products, LLC - www.adj.com - Ultra Hex Bar 6 User Manual Page 21

Ultra Hex Bar 6 Trouble Shooting

Listed below are a few common problems the user may encounter,

with solutions.

Unit not responding to DMX:

1. Check that the DMX cables are connected properly and are

wired correctly (pin 3 is “hot”; on some other DMX devices

pin 2 may be ‘hot’). Also, check that all cables are connected

to the right connectors; it does matter which way the inputs

and outputs are connected.

Unit does not respond to sound:

1. Quiet or high pitched sounds will not activate the unit.

2. Make sure that Sound Active mode is activated.

Ultra Hex Bar 6 Cleaning

Due to fog residue, smoke, and dust cleaning the internal and exter-

nal optical lenses must be carried out periodically to optimize light

output.

1. Use normal glass cleaner and a soft cloth to wipe down the

outside casing.

2. Clean the external optics with glass cleaner and a soft cloth

every 20 days.

3. Always be sure to dry all parts completely before plugging

the unit back in.

Cleaning frequency depends on the environment in which the fixture

operates (i.e. smoke, fog residue, dust, dew).

Disconnect the unit from its power source. Remove the power cord

from the unit. Once the cord has been removed, you will find that the

fuse holder is located inside the power socket. Insert a flat-head screw

driver into the power socket and gently pry out the fuse holder. Remove

the bad fuse and replace with a new one. The fuse holder also has a

holder for a spare fuse.

Ultra Hex Bar 6 Fuse Replacement

With this feature you can connect the xtures to one another

using the IEC input and output sockets. The quantity that can be

connected is 12 xtures maximum. After 12 xtures you will need

to use a new power outlet. They must be the same xtures. DO

NOT mix xtures.

Ultra Hex Bar 6 Power Cord Daisy Chain
