Compact mobile 1

Part of the action

Compact mobile

Operating Instructions

CONTENTS:

1. INTRODUCTION

2. PRECAUTIONARY MEASURES

3. OPERATING ELEMENTS

4. SUMMARY OF OPERATIONS

5. TECHNICAL DATA

1. INTRODUCTION

Welcome to AER. Thank you for purchasing the Compact mobile.

You have chosen a professional, compact and powerful amplifier that was specially

developed to amplify acoustic instruments. The internal battery allows you to play up to

3/6 hours without connecting the amp to the mains.

Two channels make it possible to operate a microphone and an instrument indepen-

dently of each other. The dynamically controlled power amplifier and the broad-spec-

trum loudspeaker system guarantee distortion-free reproduction even at high volumes.

To obtain maximum enjoyment from your amplifier please read this manual carefully

before using your Compact mobile.

2. PRECAUTIONARY MEASURES

When you use your Compact mobile, always take basic safety precautions to reduce to

a minimum the risk of injury by fire or by electric shock.

➧Read all the directions in these operating instructions and make sure that you under

stand them.

➧Pay attention to all warnings, instructions and supplementary text written on the

Compact mobile.

➧Always use a grounded mains connection with the appropriate supply voltage. If you

are uncertain whether the connection is grounded, have a qualified expert check it.

➧Do not let your Compact

mobile come into contact with water and never touch the

amplifier if you have wet hands.

➧Always operate your Compact

mobile in a place where no one can trip over the

cables causing injury to themselves or damage to the cables.

➧Do not operate your Compact

mobile near devices with strong electromagnetic

fields such as large mains transformers, generators, neon lights etc. Do not lay the

signal cable parallel to power lines.

➧Do insure that your Compact

mobile is switched off before plugging in the power

cable to the mains.

➧Before cleaning your Compact

mobile, unplug it from the mains supply. Use a damp

cloth to clean it. Do not use cleaning agents, and be careful that no liquid finds its

way into the amp.

➧There are no parts within your Compact

mobile that can be serviced by the user.

Refer all repairs and servicing to an agent authorised by AER.

Any unauthorised repair or servicing will void the two year warranty!

➧Keep these operating instructions in a safe place.

3. OPERATING ELEMENTS

Front (from left to right):

Channel 1:

Input socket for a 6.3 mm jack plug

High/Low switch to adjust input sensitivity

High impedance only instruments with a piezoelectric pick-up,

Low for instruments with active preamplifiers and magnetic sound pick-ups

Clip overload indicator

Gain input level control

Colour mid-range contour filter

Bass tone control for bass

Middle tone control for mid-range

Treble tone control for treble

Compact mobile 2

Part of the action

Channel 2:

Input XLR combination with a socket for a 6.3 mm jack plug and XLR male socket

Line/Mic switch to adjust input sensitivity

Line: sources with line level, instruments with active preamplifiers

and magnetic sound pick-ups, symmetrical microphone inputMic:

with 30 V phantom source

Clip overload indicator

Gain input level control

Bass tone control for bass

Treble tone control for treble

Eff. Pan panorama control to distribute the effects between the channels

Select switch for two effect programmes (reverberation, reverberation/delay)

Return level control for the internal effect

Power power indicator lamp

Master level control for the overall volume

Low batt. low charge indicator lamp

Charge charge indicator lamp

48V on/off 48V phantom power on/off

Aux–Return level control for the Aux–Input (e.g. CD–player)

Rear (from left to right):

Aux–In input for CD and tape

Phones headphone output

Tuner output for a tuner after the master control

Line-out preamplifier output after the master control

DI-out XLR output before the master control

Send output for an external effect device

Return input for an external effect device or another signal source, for example

CD–player

Footswitch connection for a double foot switch with which the effects can be

switched on and off.

12V/DC only connection for an external 12V/DC–battery, not suitable for

a connection to a board–net.

DC on/off On/Off–switch for an external battery–connection.

Power on/off combined mains switch with a mains socket and a fuse-

holder (1 A slowblow) for both operating–modes

Compact mobile 3

Part of the action
