Indoor Luminaire
Evanston Pendant
120~277VAC / 60Hz
Page 1 of 2 8061256 R0
Model EVNP2532LAJUDSN #
Safety Precautions
Read all safety precautions and installation instructions carefully before installing or servicing this xture. Failure to comply with these instructions could result in
potentially fatal electric shock and/or property damage.
It is recommended that a qualied electrician perform all wiring. This fixture must be wired in accordance with all national and local electrical codes.
Do not handle any energized xture or attempt to energize any xture with wet hands or while standing on a wet or damp surface or in water.
This xture is designed for use in a 120-277VAC, 60Hz fused circuit. The xture is compatible with Triac (forward-phase or leading edge) / ELV (reverse phase or trailing
edge) and 0-10 V dimmers. Make sure that the power source conforms to the requirements of the xture. (See labels on the xture housing).
To reduce the risk of electrical shock, and to assure proper operation, this xture must be adequately grounded. To accomplish proper grounding, there must be a
separate ground wire (green) contact between this xture and the ground connection of your main power supply panel.
This xture is intended to be used for general indoor lighting in dry or damp wet locations.
Disclaimer
Changes or modications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. NOTE: This
equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules and Canadian ICES-005 (B) / NMB-005
(B). These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates uses and can radiate
radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no
guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be
determined by turning the equipment o and on, the user is encouraged to try to correct the interference by one or more of the following measures:
• Reorient or relocate the receiver antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit dierent from that to which the receiver is connected.
• Consult with the dealer or an experienced radio/TV technician for help.
Any modications to this xture may void the warranty and interfere with the safe operation of the luminaire.
Operation is subject to the following two conditions: (1) this device may not cause interference, and (2) this device must accept any interference, including interference
that may cause undesired operation of the device.
Assembly Instructions
1. Preparing for installation-
A. before installing or servicing any part of this xture. Disconnect electrical power
B. Remove xture from box. Separate contents of parts bag.
2. Fixture Assembly.
A. Attach xture shade (1) to xture LED pan (2) using 6 provided screws (3). Hand
tighten to make sure they are secured tightly. Do not over tighten and strip threads.
B. Choose desired height for xture stems using any , stems of the 6” 12” & 18”
provided to achieve your preferred hang length to the top of the shade.
C. Feed xture wiring from top of shade up through both stems that are going to be
used all the way through the Hang Straight into the canopy.
D. Starting with the bottom stem thread each stem together one at a time until the
Canopy is securely tightened to the stems.
E. Tighten the stems to the canopy at the three locations with the desired stem lengths
to get the look wanted.
3. Wiring- all wiring must take place inside junction box.
Caution: Make sure power is o at fuse or circuit breaker box. Check power wires for any damage or scrapes. Use wire suitable for at least 90C (194F).
Note: Most dwellings built before 1985 have supply wire rated to 60C. Consult a qualied electrician before installing.
A. ical shock, overheating, low or no light output, and This unit will not operate properly unless connected to a “grounded” electrical circuit. Electr
shortened LED life can result if proper grounding is not done. Securely attach power source ground wire and xture ground wire to green ground
screw on circular mounting bracket.
B. r NEC (National Electrical Code) requirements, cut the co Then remove the ends of the three wires for Fo rd about 7” above the canopy. 3/8” from
connection purposes.
C. . Fixture will operate normally w/o connection to any dimmers. Connect white xture lead to white (N) wire from supply For none-dimming xture
power source. Connect black xture lead to black (L) wire from supply power source. Gray and purple wires are not to be used and must be
individually capped to prevent shorting.
D. Connect white xture lead to (N) wire from dimming source per dimmer wiring instructions. Connect black xture lead to For TRIAC dimming.
black (L) wire from dimmer supply power source. Gray and purple wires are not to be used and must be individually capped to prevent shorting.
E. . Connect gray wire from the xture to the dimmer source gray wire. Connect purple wire from the xture to the For (0-10V) dimming xture
dimmer source purple wire. Connect white xture lead to white (N) wire from supply power source. Connect black xture lead to black (L) wire from
dimmer supply power source.
F. . Pull on each wire lead to make sure connections are secure. Make certain no bare wires are exposed outside of wire Do not mix wires
connectors. Tuck all connections neatly into junction box.
Limited Factory Warranty
AFX Inc. hereby warranty that this xture is free from defects in materials and workmanship when installed and used under normal operating
conditions for a period of 5 years from the date of shipment from the factory. This warranty covers all component parts and extends only to
replacement of defective xture or components: it does not cover failure due to improper installation, misuse, mishandling or damage
incurred in transit.
Indoor Luminaire
Evanston Pendant
120~277VAC / 60Hz
Page 2 of 2 8061256 R0
Model # EVNP2532LAJUDSN
4. Color Changing Temperature Adjustment, CCT (if desired).
A. Adjust the two switches on each board accordingly to the desired color temperature as seen below. All boards must be set the same way. Fixture is preset Note:
to 3500K from factory.
5. Ceiling Mounting.
A. Align mounting gem bar ) over tapped holes in the junction box (Not Included) Secure mounting cross bar to the junction box with two provided screws (5), (4 .
making sure the gem bar ) is tight up against the ceiling. (4
B. Lift xture ) with stem and canopy ) ush up to ceiling aligning two threaded stems (7) with clearance holes in the canopy (6 (1 (6 ).
C. Secure the xture canopy (6) ush to ceiling with the two decorative thumb nuts (8) provided.
D. Place diuser (9) inside shade resting on bottom ring to give the nished look.
6. Restore power at the fuse or breaker box.
Limited Factory Warranty
AFX Inc. hereby warranty that this xture is free from defects in materials and workmanship when installed and used under normal operating
conditions for a period of 5 years from the date of shipment from the factory. This warranty covers all component parts and extends only to
replacement of defective xture or components: it does not cover failure due to improper installation, misuse, mishandling or damage
incurred in transit.
