Sida 1/3

VWM-01 / VWM-02 / VWA-01 & VWA-04

Installation Manual

Video Wall Mounting Kit

VWM-01 VWM-02

2 3 4 5

VWM-01 Enclosed Parts

M6x12

*1 pcs *4 pcs *4 pcs

M8x14

*2 pcs *2 pcs

2 3 4 5

VWM-02 Enclosed Parts

M6x12

*1 pcs *4 pcs *4 pcs

M8x14

*2 pcs *2 pcs

Optional Proles VWA-01 + Brackets VWA-04

VWA-01 L= 2.000 mm VWA-04

Single use In-line use

Videowall use

VWM-01:

Installation of single-use or in-li use ne

VWM-02:

Easy installation of Videowall. Push- ction for out fun

build-in videowall sy c cting ervice of , ea onne and s

t displays. he

(ev lowes line c ill VWM- ) en t an st be 01

OPTIONAL

VWA- : 01

To install displays raigh in li For easy st t one ne. and

fas in-line or videowall set .t up

VWA- ( tional) 01 op

VWM-01/02

VWM-02

VWM-01VWM-01VWM-01

Set-up Guide

VWM-01/02

VWM-02

Physical Dimensions (mm)

500

93+10

526

100

200

300

400

280

65 40

8.5

1050

Max.fine adjustment

6.5 mm

93+10

430

17.5

8.5

52.5

93-293

(stroke=200)

+10

532

500

52.5-252

100

200

300

400

Max.fine adjustment

6.5mm

8.5

400

VWM-01 VWM-02

Installation

Sli t wallbrackets (2) wit the slot nut in the slot of the aluminium profile (1).de he

Positio te t m a sleightly turn on t lts. na he nd he bo

VWM-01: Mo t the brackets (3) with screw (4 or 5) on the backside of the display.un

VWM-02: Screw only t screws (4 or 5) in the V holes of t display and k he ESA he eep

a clearance of 4 m m.

Screw now the brackets with Profile(s) t wall. Line-up t profile(s) by on he he

ad g justin the wallbrackets (2).

For videowall installation check dist ce (H + 1 mm) and distan ance (W- mm) 264

an he edd make sure t profiles are levell (horizontally as well as vertically).

To sav installation time we sug st to use our itional profile VWA- . e ge add 01

VWM-01: Hook t display with brackets to the aluminium profile a make sure he nd

that justing screw (c) does t touch the profile.ad no

VWM-02: Hook t mo les to the aluminimum profile a make sure t t adjustinghe du nd ha

screw (c) d s not touch the profile. Place lt (a) with associated washer in t oe bo he

sliding nut, but not do tighten. Place the two modules with a rizontal distance ho

according to the width of t V . he ESA

265 97.5

97.5

265 265

W - 264 mm

H + 1 mm

4 5

Installation

Place the screen(s) in the center of the aluminium profile. Adjust vertical positions by slightly turning screw (d) or balance horizontallity by adjusting

screw (e). if installation is perfect, fix the brackets at the profile by screw ( c).

For videowall installation keep a clearancy of 1mm between the screens.

1 mm !

400

2.1 - 4 mm

e4x

4 5

1 mm !

4 5

VWM-02: Hook the brackets (6) to the aluminimum profile. Place bolt (a) with associated washer in the sliding nut, fix bracket with bolt (c) into the washer

through (b) but do not tighten. Place the two brackets (6) with a horizontal distance according to the width of the VESA and push sleightly on the brackets

(6) so they push out. Hang the display in the open bracket (6) by glyding the screws (4) or (5) into the key holes.

VWM-02: After hanging screen(s) on pushed-out brackets (6) teight-up screws (4) or (5). Keep a distance of 1 mm between 2 screens.

Check horizontal positions and fine-tune it by turning screw (e).

Check virtical position in the push-open and push-closed position and be aware of the 1 mm free space when opening and closing the brackets.

Push the screen, mounted on a VWM-02, by pressing against the indicated positions until a slight click is heard. The screen is now locked in the closed

position. Turn screws (c) to teight-up the mounts.

Hang the remaining screens by repeating the steps 4 until 10. Consider a spacing between the screens of about 1mm.

Replace screen

Press on the screen until a slight click is heard. The screen is now unlocked and will come forward when loosening pressure. Sufficiently loosen the

screws (4) or (5) at the rear of the screen, so that the screen can be lifted out of the keyholes.

Remove the screen from the “Push to Open” modules and if needed replace it with a new screen. Tighten the bolts (from Step A) again. Push on the

screen until a slight click is heard. The screen is locked in the closed position. If a display on the lowest profile needs service, then only press on the
