Sida 1/4
FUZZISTOR TM
The Fuzzistor™ provides classic silicon transistor distortion with
complete control over the of the clean and Fuzz sound, amount BLEND
of FUZZ from subtle to crushing, LEVEL for gain matching, and TILT EQ
that changes the harmonic structure of the Fuzz from booming to
gnarly.
Features:
• Silicon transistor distortion
• Intuitive four knob control layout
• Gig-saver bypass (signal passes even if your battery dies)
• Powered by a nine-volt battery or optional universal power
supply
• Heavy duty steel construction
• Three- year limited warranty
Owner’s Manual
Manual Version 1.1
I. Functions
A. Top Panel:
BLEND: Controls the mix ratio between clean and distorted signal s .
When the knob is set to the 12:00 position, the two signals are mixed at a 50:50
ratio.
When the turnedBLEND knob is counterclockwise the mix ratio favors the clean
signal. When this knob is turned clockwise the mix ratio is reversed and favors the
distorted signal.
LEVEL: Controls the output leveloverall .
TONE: Controls the tone of the distorted signal.
FUZZ: Changes the character of the distorted signal. Turning the knob clockwise will
intensify the distortion, enriching the harmonic content of the sound.
ENGAGE: Toggles between on and off. The blue LED indicates that the effect is on.
B. Side Panel:
IN: ¼” input
DC IN: This is a standard 2.1mm DC jack. The center terminal polarity is negative.
OUT: ¼” output
C. Specifications:
C urrent consumption:………………………..4.5mA
Input impedance: ............................................1MΩ (Effect On)
Output impedance: .........................................1 KΩ
External DC Power: 10VDC, center terminal negative -………………………..9
II. Sample Settings
Please visit our website, www.aguilaramp.com, for sample settings.
III. How to change the battery
This operation can be done quickly and easily with a standard #2 Philips screw
d river!
The battery is easily accessible by loosening the screw on the bottom of the unit. The
battery compartment will slide forward and you will be able to see the padded area
to insert the battery and attach the battery clips. Once the battery has been replaced,
simply slide the compartment back in and tighten the screw.
