IG-641RPOE
Quick Setup Guide
Declaration of Conformity
We, Manufacturer/Importer
Declare that the product
Industrial Unmanaged PoE Switch
IG-641RPOE
is in conformity with
In accordance with 2014/30/EU and 2014/35/EU Directive
Clause
Manufacturer/Importer
Description
AirLive Technology Corporation
4F, No.132, Lane 235, Baoqian Rd., Xindian Dist.,
New Taipei City 23145, Taiwan
■
■CE marking
Name : A van Rossem Position/ Title : Product Manager
EN 55032:2015 Electromagnetic compatibility (EMC)
■EN 62368-1 Electromagnetic compatibility (LVD)
Date : May 2024Place : Republic of China (Taiwan)
Industrial Unmanaged Gigabit PoE Switch
AirLive Technology Co ion drporat eclares tha hi evt t s d ice
is in compliance with the ntesse ial require tsmen and
oth l ter re evan provis sion of i / direct ve 2014 30/EU.
Regulatory Approvals
CE Marking Warning
This is a Class A product. In a domestic environment this product may cause radio
interference in which case the user may be required to take adequate measures.
CE Statement
This product complies with the 2014/30/EU and 2014/35/EU directives,
including the following safety and EMC standards:
EN 55032:2015+A11:2020
■
Electromagnetic compatibility (EMC)
EN IEC 61000-3-2:2019
■
Electromagnetic compatibility (EMC)
EN 61000-3-3:2013+A1:2019
■
Electromagnetic compatibility (EMC)
EN 55035:2017+A11:2020
■
Electromagnetic compatibility (EMC)
EN 62368-1:2014+A11:2017
■
Electromagnetic compatibility (LVD) - Safety
RoHS Statement
This product complies with RoHS directive 2011/65/EU and amendment
Commission Delegated Directive (EU)2015/863.
IEC 62321-3-1:2013
■
IEC 62321-5:2013
■
IEC 62321-4:2013+AMD1:2017
■
IEC 62321-7-1:2015
■
IEC 62321-7-2:2017
■
IEC 62321-6:2015
■
IEC 62321-8:2017
■
IG-641RPOE

Mounting the Switch
Quick Setup Guide
1. Screw the DIN-Rail bracket on with the bracket and screws in the
accessory kit.
2. Hook the unit over the DIN rail.
3. Push the bottom of the unit towards the DIN Rail until it snaps into place.
A. Din-Rail
1. Un-Screw the DIN Rail bracket from the Switch and attached the
wall-mounting plate on the same location with the plate and screws
in the accessory kit.
B. Wall Mount
1. The DC power interface is a 4-pin terminal block with polarity signs on the
top panel.
2. The Switch can be powered from two power supply (input range 48V~55V).
The DC power connector is a 4-pin terminal block.
C. Power Connection
IG-641RPOE
Industrial Unmanaged Gigabit PoE Switch
The images can differer from the real product, images for guide purpose only.
LED DEF INIT NSIO
Power
Link/Act
ON
OFF
Green ON
Green OFF
Green Blinking
Power is on and normal.
The switch is not receiving power.
Link Normal.
Link Off.
Link Data Transmitting.
DIP Switch Control
V: VLAN Mode
G: Default Mode
E: Extend Mode
Port isolation mode. In this mode ports 1~4 cannot communicate with each other and can only
communicate with the Uplink ports.
Normal mode. All ports can communicate with each other.
Extension mode. PoE power supply and data transmission distance can be extended to 250meter at the
transmission rate of 10Mbps Port 1~4 only.
*** Installation images for illustration purpose only
