Akg H600 Bruksanvisning

Akg mikrofon H600

Läs nedan 📖 manual på svenska för Akg H600 (2 sidor) i kategorin mikrofon. Denna guide var användbar för 3 personer och betygsatt med 4.5 stjärnor i genomsnitt av 2 användare

Ladda ner PDF
Sida 1/2
H 500 & H 600
Shock Mount
H 500 Description
The AKG H 500 shock mount is designed for permanent
installation of E and ES version goosenck modules from the
Discreet Acoustics Modular series. This mount provides
attenuation of structure-borne noise by 12 dB.
The H 500 shock mount consists of a durable plastic shell
and flexible inner rubber boot. It allows for quick and easy
set up and break down of a sound system. The H 500
requires a mounting hole of 2.0 inches (50 mm).
Features
• Isolation from physical vibration
• Rugged design
• Fast set up
• Economical
H 600 Description
The AKG H 600 shock mount is designed for permanent
installation of E and ES version gooseneck modules from the
Discreet Acoustics Modular series. This mount provides
maximum attenuation of structure-borne noise (20 dB).
Each mount consists of a durable low profile plastic shell
with a flexible inner rubber boot, and, for added security,
features a locking clutch that prevents easy removal of the
gooseneck module. Included with the H 600 is the A 608
insert. The A 608 grips the narrow section of the gooseneck
and allows for custom height adjustments. The H 600
requires a 2.1 inch (53 mm) mounting hole.
Features
• Isolation from physical vibration
• Custom height adjustment
• Security
• Rugged design
Microphones · Headphones · Wireless Microphones · Wireless Headphones · Headsets · Electroacoustical Components
Limited Warranty
Valid only in the United States. AKG Acoustics warrants AKG products against defects in material
or workmanship for a period of two years from the date of original purchase for use, and agrees to
repair or, at our option, replace any defective unit without charge for either parts or labor. Important:
This warranty does not cover damage resulting from accident, misuse or abuse, lack of reasonable
care, the affixing of any attachment not provided with the product, loss of parts or connecting the
product to any but the specified receptacles. This warranty is void unless service or repairs are
performed by an authorized service center. No responsibility is assumed for any special, incidental
or consequential damages. However, the limitation of any right or remedy shall not be effective
where such is prohibited or restricted by law. Simply take or ship your AKG product prepaid to our
service department. Be sure to include your sales slip as proof of purchase date. (We will not repair
transit damage under the no-charge terms of this warranty.) Note: No other warranty, written or oral
is authorized by AKG Acoustics, Inc. This warranty gives you specific legal rights, and you may also
have other rights which vary from state to state. Some states do not allow the exclusion or
limitation of incidental or consequential damages or limitation on how long an implied warranty
lasts, so the above exclusions and limitation may not apply to you.
Specifications subject to change without notice.
AKG Acoustics GmbH
Lemböckgasse 21–25, P.O.B. 158, A-1230
Vienna/AUSTRIA
Tel: (43 1) 86 654-0*, Fax: (43 1) 86 654-516
Internet: http://www.akg.com
AKG Acoustics; A Division of Harman Pro Germany
Bodenseestraße 228, D-81243 München/GERMANY
Tel: (089) 87 16-0, Fax: (089) 87 16-200
Arbiter Pro Audio
Wilberforce Road, London NW9 6AX/ENGLAND
Tel: (0181) 202 1199, Fax: (0181) 202 7076
AKG ACOUSTICS, U.S.
914 Airpark Center Drive
Nashville, TN 37217, U.S.A.
Tel: (615) 620-3800, Fax: (615) 620-3875
Studer Japan Ltd.
2-43-7, Uehara, Shibuya-ku, Tokyo 151-0064/JAPAN
Tel: (813) 3465-2211, Fax: (813) 3465-2214
Erikson Pro Audio
620 McCaffrey, St-Laurent, Quebec, H4T 1N1, CANADA
Tel: (514) 738-3000, Fax: (514) 737-5069
Internet: www.jam-ind.com/eriksonpro
AKG is constantly improving and modifying its products, therefore, specifications are subject to change without notice.
120
º
2
.910
"
[73.9mm
]
0
.17
3"
[4.4mm
]
2
.
33
2"
[59.2mm
]
OLE SIZ
2
.
000"
[50.8mm
]
0
.
3
4
6"
[8.8mm
]
1.
959"
[49.8mm
]
1.1
88"
[30.2mm
]
Graphical Data H 500
0
.7
80"
[19.8mm
]
1.2
0
1
"
[
30.5mm
]
120
º
2.717"
[69.0mm
]
H
OLE SIZ
E
2
.12
6"
[54.0mm
]
2.717"
[69.0mm
]
0
.7
80"
[
19.8mm
]
1 221"
1.221
[31.0mm
]
0
.
0
7
9"
[2.0mm
]
Graphical Data H 600
DS-H 500 & H 600

Produktspecifikationer

Varumärke: Akg
Kategori: mikrofon
Modell: H600
