Sida 1/8

'RFXPHQW1XPEHU 'HVFULSWLRQ0$18$/-%/2Q7LPH5HYLVLRQ 3DJHRI49

8VHU*XLGH  

*XLGHGHO¶XWLOLVDWHXU 

*XtDSDUDHOXVXDULR 

%HQXW]HUKDQGEXFK 

0DQXDOHG¶LVWUX]LRQL 

࡙࡯ࠩ

࡙࡯࡙ࠩ࡯ࠩ࡯ࠗࠟ

࡯ࠗࠟ

࡯ࠗࠟ࡯ࠗࠟ࠼

࠼

࠼࠼ 

,$.1PVKOG

VKOGOCEJKPGHQT[QWTK2QF



6KOG5QWPF5[PE%JCTIG

Document Number: 950-0068-001 Description: MANUAL, JBL On Time Revision: 09 Page 2 of 49

Important Safety Instructions

Please read the following operation precautions before use:

Rating Information on the bottom of the Unit

Important Note for all Electronic Products: Before inserting or unplugging audio cables from the source device's

Minimum distances around the apparatus for sufficient ventilations is not less

than 10mm;

The ventilation should not be impeded by covering the ventilation openings with

items such as newspaper, table-cloths, curtains etc;

No naked flame sources such as lighted candles should be placed on the apparatus;

Attention should be drawn to the environmental aspects of battery disposal;

The use of apparatus in moderate climates;

Mains plug is used as the disconnect device. It shall remain readily operable and

should not be obstructed during intended used. To be completely disconnected the

apparatus from supply mains, the mains plug of the apparatus shall be disconnected

from the mains socket outlet completely.

headphones or line-level output jacks, it is good practice to turn off the device. This will prolong the life of your

unit, help protect your device from static electricity, and avoid potential damage.

Introduction to your JBL On Time,a time machine for your iPod

TM.Time, Sound, Sync, Charge

The JBL ON TIME is the latest innovation from JBL, a long time leader in the manufacture of high-end and professional component audio systems. JBL’s audio heritage

combined with continual research has provided the unique technologies included in the JBL ON TIME.

JBL “On Time” is a revolution in time travel for the iPod

TM. Imagine waking up to your favorite song stored on your iPod

TM. No more buzzer or bad radio reception.

On time is a compact, high performance time machine and sound center. Connected to your iPod

TM, iPod miniTM , MP3 player or other music source, the on time

will provide clean, powerful sound while providing time keeping, alarm and radio features. The world’s first time machine with an intuitive user interface that is

simple to navigate.

Compatibility

The JBL on time is compatible with all docking versions of the iPod

TM, including the iPod miniTM and iPodTM Photo. A stereo mini jack connection also allows you to

enjoy high quality audio from a variety of other devices such as, iPod Shuffle

TM , MP3 and CD players, desktop computers (all platforms) , satellite radio and

laptops.

Easy to use music and navigation controls

Music Controls – Just a touch increases or decrease the volume. Another touch and you choose iPod, radio or auxiliary. JBL on time remembers your source and

the last volume setting even after the system shuts down.

Time and alarm features

The intuitive user interface allows for all functions to be programmed easily. The JBL On Time includes two alarms for independent wake times. The navigation

buttons provide instant access to the menus. The automatic time set feature provides one button time setting. Navigate the intuitive menu structure to change

settings such as language, alarms and snooze. Radio functions such as channel presets are simple

Display

The large backlight LCD display provides for easy viewing and menu navigation. Automatic dimming provides the correct brightness level in any room environment.

A dome light provides a glow for your iPod. Lighted buttons are easy to find in the dark.

Additional Features

OnePoint design - The OnePoint iPod

TM connectors provide the connection to you computer. Connect the standard iPod

TM cable to the rear of the on time and

every time you dock your iPod, you will have a connection for synchronizing and charging.

Evercharge Topology - The JBL on time provides power to charge your iPod

TM even when not connected to the computer or if the system is off.

Backup battery – The on time memory is keep by a backup battery. Even with the power out, the on time will provide the alarm function.

TimeCrawler – The JBL On Time has the ability to set the clock automatically from any local radio station that transmits the time in their signal.

Advanced Technology

The JBL on time combines many proprietary technologies to provide the highest quality sound. The on time will provide astonishing bass and clear accurate sound

from any direction.

Halo acousticsTM - The horizontal acoustic level optimization or Halo acousticsTM design provides a full, rich sound field from any direction. The upward firing

tweeter and horizontal low and midrange transducers provides a 360 degree sound ﬁeld.

PhoenixTM and RidgeTM Transducers – The two aluminum domed full range transducers are driven by powerful Neodymium magnets. The RidgeTM tweeter

provides accurate high frequencies. This two way design provides a full rich frequency response from the lowest bass to the highest highs.

COE (Computer Optimized Equalization) – The JBL on time system equalization was computer optimized to provide a rich, complete sound stage.

OCT (Optimized Compression Topology) – The JBL on time utilizes a proprietary compression technology to insure clean accurate sound at high output levels.

Read these instructions.

Keep these instructions.

Heed all warnings.

Follow all instructions.

Do Not use this apparatus near water.

Clean only with dry cloth.

Do Not block any ventilation openings. Install in accordance with the

manufacturer’s instructions.

Do Not install near any heat sources such as radiators, heat registers, stoves, or

other apparatus (including amplifiers) that produce heat.

Do Not defeat the safety purpose of the polarized or grounding type plug. A

polarizing plug has two blades with one wider than the other. A grounding type

plug has two blades and a third grounding prong. The wide blade or third prong,

are provided for safety. If the provided plug does not fit into your outlet, consult

an electrician for replacement of the obsolete outlet.

10 Protect the power cord from being walked on or pinched particularly at the plugs,

convenience receptacles, and at the point where they exit from the apparatus.

11 Only use attachments/accessories specified by the manufacturer.

12 Unplug this apparatus during lightning storms or when unused for long periods of

time.

13 Refer all servicing to qualified service personnel. Servicing is required when the

apparatus has been damaged in any way, such as power-supply cord or plug is

damaged, liquid has been spilled or objects have fallen into the apparatus, the

apparatus has been exposed to rain or moisture, does not operate normally, or

has been dropped.

14 TO PREVENT THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE THE

COVER (OR BACK). THERE ARE NO USER SERVICEABLE PARTS INSIDE

THIS UNIT, PLEASE REFER SERVICING TO QUALIFIED HARMAN

MULTIMEDIA CORPORATION SERVICE PERSONNEL.

15 Never remove grille covers in order to service the speaker system. The speaker

system does not contain any user serviceable parts. Refer all servicing to the

Harman Multimedia Technical Support Group.

WARNING: TO PREVENT FIRE OR ELECTRICAL SHOCK HAZARD,

DO NOT EXPOSE THIS PRODUCT TO RAIN OR MOISTURE.

WARNING: THE APPARATUS (AC/DC ADAPTOR AND MAIN UNIT)

SHALL NOT BE EXPOSED TO DRIPPING OR SPLASHING AND

THAT NO OBJECTS FILLED WITH LIQUID, SUCH AS VASES, SHALL

BE PLACED ON THE APPARATUS.

SEE MARKING ON BOTTOM OF PRODUCT

THE LIGHTNING

FLASH AND

ARRWOHEAD

WITHIN THE

TRIANGLE IS A

WARNING SIGN

ALERTING YOU

OF “DANGEROUS

VOLTAGE”

INSIDE THE

THE

EXCLAMATION

POINT WITHIN

THE TRIANGLE IS

A WARNING SIGN

ALERTING YOU

OF IMPORTANT

INSTRUCTIONS

ACCOMPANYING

THE PRODUCT.

CAUTION: TO REDUCE

THE RISK OF

ELECTRIC SHOCK, DO

NOT REMOVE COVER.

NO USER

SERVICEABLE PARTS

INSIDE. REFER

SERVICING TO

QUALIFIED SERVICE

PERSONNEL.

CAUTION

RISK OF ELECTRIC SHOCK

DO NOT OPEN

PRODUCT

Document Number: 950-0068-001 Desc iption: M NU L, JBL On Time Revision: 0 Page 3 of r A A 9 49

Unpacking

Carefully unpack your speaker system and identify all components:

• A On Time

• B Power Supply

• C iPod adaptors

• D Aux audio cable

• E AM antenna

General Setup

1) Unpack the JBL On Time and iPod adaptors and power adaptor

2) Choose the appropriate iPod adaptor and place into docking station

3) Place the iPod into the adaptor

4) Plug power adaptor into jack marked 15Vdc in

5) Plug adaptor into wall outlet

6) If an additional audio source is used, connect source into Aux In

7) Unwind the FM wire antenna. Straighten the wire for the best reception

8) Connect external AM Antenna for better reception

9) If the use of an additional subwoofer is desired, connect to Sub Out jack

10) For backup memory settings, install 3 AAA batteries

Music Control Navigation

Alarm control

Clock Setting Instructions:

1) From the Press any Navigation key. “PLEASE SET CLOCK SCREEN”

2) Use “Left/Right” button to set “hour” and press Enter

3) Use “Left/Right” button “minute” and press Enter

4) Use “Left/Right” button “day” and press Enter

5) The JBL On Time will confirm the clock is set.

Timecrawler – Auto time set

The JBL On Time features which can set the clock automatically. The On Time scans to find a radio station that transmits the time, receives the signal and sets the clock. TimeCrawler,

1) Press the “Menu Up/Back” button until you reach the “JBL On Time” screen

2) Use “Left/Right” button to select “Set” and press Enter

3) Use “Left/Right” button to “SetCLK” and press Enter

4) Use “Left/Right” button “Auto” and press Enter

The On Time will search for a radio station transmitting the time. When TimeCrawler finds a station, the On Time will display the % complete. The On Time will then show the time has

been set. If the On Time is not successful with Timecrawler, it will instruct you to set the time manually. Please follow the Clock Setting Instructions shown above.

*The accuracy of TimeCrawler is based on the accuracy of the local radio station clock.

Playing music

1) Press “Mode Select” button to select the source (iPod, Radio, Aux.)

2) Press “+” button to increase volume

3) Press “-“ button to decrease volume

Radio Tuning and Presets:

1) Press the “Menu Up/Back” button until you reach the “JBL On Time” screen

2) Select “listen” and press Enter

3) Select “radio” and press Enter

4) Select “FM” or “AM” and press Enter

On/Off/Cancel
