T
PHASE COHERENT
CARDIOI MICROPHONED
PCC160
he AKG/Crown
PCC160 (Phase
Coherent
Cardioid
®
) a rface-is su
mounted half - supercardioid
microphone intended for professional
applications stage oors, lecterns,on
conference
tables, and news desks wherever—
improved gain-
before-feedback and articulation are important.
Similar the Pressure Zone Microphoneto
®
(PZM
®
), the PCC designed used ais to be on
relatively large boundary surface. Unlike the PZM,
the Phase Coherent Cardioid uses a subminiature
supercardioid mic capsule. Its directional polar
pattern improves gain-before-feedback, reduces
unwanted room noise and rejects sounds from the
rear. rface-mounting creates a -supercardi- Su “half
oid” polar pattern increases directivity 3 dB.and
Since the microphone capsule placed ais on
boundary, direct and reected sounds arrive at
the diaphragm -phase. This coherent addition in
of direct reected waves increases sensitivity and
6 and prevents phase cancellations. The mic dB
capsule small enough ensure phase coher-is to
ency the highest frequencies the audibleup to in
spectrum, resulting a wide, smooth frequencyin
response free phase interference. Clarity of and
reach are also enhanced.
Self-contained electronics eliminate the need
for -line preamp box. The PCC can an in 160 be
phantom powered directly from the console or
other remote power source providing 12 to 48
volts. battery power required, a battery supply If is
unit can inserted anywhere the mic line rightbe in
up or the console to mixer. A switch “bass tilt”
allows the user tailor the low-end response forto
particular applications.
Thanks its low prole and black nish, theto
microphone becomes almost invisible use. Ain
side-mounted connector complements the form
factor the PCC160, allowing the unit of to be
placed eectively at the stage edge, at the top of a
lectern or other tight spots. desired, the cablein If
can hard-wired for bottom entry.be
The heavy-gauge, all steel body protects the unit
from accidental abuse. Permanent mounting is
enabled screw holes the base. Engineeringby in
attention- -detail assured years trouble- to has of
free use from this reliable microphone.
Capable of withstanding up to 120 dB with-SPL
out distorting, the PCC160 will never overload
in practical use. Its electret condenser capsule
provides a wide, smooth frequency response from
50 Hz to 18 kHz. RFI suppression is included.
Self-noise w, and sensitivity ry high is lo is ve to
override mixer noise distant-miking applica-in
tions. Output impedance is 150 ohms, balanced.
Features
Industry-standard stage oor microphone
Phase Coherent Cardioid design prevents color-
ation from rface sound reectionssu
High output overrides mixer input noise
Specications
Type:
Phase Coherent Cardioid.
Element:
Electret condenser.
Frequency response (typical):
50 at 18,000 Hz to Hz
30 1. degrees incidence rface. See Fig. to su
Polar pattern:
Half-supercardioid (supercardioid in the
hemisphere above the primary boundary).
See Fig. 2 and Fig. 3.
Impedance:
150 ohms nominal (85 ohms actual),
balanced. (Recommended load impedance 1000
ohms or greater.)
Open-circuit sensitivity:
22mV/Pa* ( 1–33 dB re
V/Pa*).
Power sensitivity:
–31 dB re 1 milliwatt/Pa*
EIA rating: - 123 dBm .
Equivalent noise level (self noise):
22 dB typical
(0
dB = 0.0002 dyne/cm
2
), A-weighted.
S/N ratio:
72 dB at SPL.94 dB
Maximum SPL for 3% THD:
120 SPL.dB
Polarity:
Positive pressure the diaphragm pro-on
duces positive voltage pin 2 with respect pin on to
3 of output connector.
Cable:
15-foot, black, two-conductor shielded cable
with Switchcraft TA3F connector A3M con- and
nector.
Operating voltage:
Standard phantom power
:
12 to
48 volts positive pins 2 3 with respectDC on and
to pin 1.
Safe Operating Temperature:
–10° +50° C to or
+14° to +122° F.
Current drain:
4 nominal.mA
Materials:
All steel construction.body
Finish:
black.
Net weight:
11.5 oz. (326 g).
Dimensions:
See Fig. 5.
Optional accessories:
AKG/Crown phantomPH1A
power supply (one channel, battery or AC-adapter
powered).
*1 pascal = dynes/cm10
2
= microbars = SPL.10 94 dB
Half-supercardioid polar pattern rejects the
pit orchestra oers high gain-before- and
feedback
Very rugged
Low prole
Fig. 1
Frequency Response
Frequency in Hz
Fig. 2
Vertical Plane Polar Response
1 kHz
200 Hz
4 kHz
Fig. 3
Horizontal Plane Polar Response
1 kHz
200 Hz
4 kHz

Operating Instructions
Unbalanced operation:
If you are using a phantom
power supply that does NOT include isolation an
transformer, and you desire unbalanced output, an
use pin 2 hot and pin 1 ground. This proce- as as
dure prevents distortion the PCC rcuit. in ci
Do not
unbalance the output the supply connectingof by
pin 3 pin to 1.
If you are using a phantom supply
containing isolation transformer (such thean as
AKG/Crown AC/Battery Supply), then you PH1A
can
unbalance the output connecting pin 3 by to
pin 1
in the cable feeding the mixer. This results in
6 dB
more sensitivity.
The PCC includes two keyhole slots its base in to
accept mounting screws. To screw the PCC ato
surface, refer to Fig. 4 and Fig. 5.
Note:
The porous foam liner in the housing must
go toward the front the microphone; the denseof
foam liner goes toward the rear. Otherwise the
frequency response polar pattern will and be
degraded.
BASS LT SWITCH: the bottom the micro- TI On of
phone a bass-tilt switch which allows the user is to
tailor the low-end response for particular applica-
tions. general, use the AT position. Use theIn FL
CUT position reduce room rumble and r-han- to ai
dler noise. Use the BOOST position to compensate
for low-frequency losses when the PCC placedis
on small boundaries such as lectern shelf-tops.
Architects’ & Engineers’ Specications
The microphone shall be the AKG/Crown
Model
PCC . The microphone shall 160 be a
half-supercardioid electret
condenser type,
utilizing a subminiature transducer rugged of
construction. A smooth frequency
response from
50 18,000 shall tained, with a Hz to Hz be ob
uniform o-axis response, over 20
dB down the at
rear nulls. The microphone will
exhibit excellent
o-axis response and gain- fore-feedback.be
The microphone shall employ the principle of
phase coherency achieved mounting a small- by
diameter element ry near a boundary, thus ve
eliminating comb ltering the audible spectrum. in
A -foot (4.6-m), two-conductor shielded cable15
with TA3F A3M connectors shall suppliedand be
with the microphone.
The microphone shall have a sensitivity of 22
mV/Pa*. The microphone shall accept a 120
dB input while providing SPL no greater than 3
percent THD (open- rcuit termination). Equivalentci
noise shall dBA typical. The AKG/Crown be 22
Model
PCC 160is specied.
P 1CC 60
Warranty
AKG/Crown professional microphone products are
guaranteed against malfunction r a period of threefo
years from e of original rchase. Please refer dat pu to
the enclosed full warranty statement r more detail.fo
Service
If the microphone does not function properly,
check verify that aimed correctly to it is and is
connected described the Operating Instruc- as in
tions. If there is hum or no signal, repair or
replace the cable.
If you determine that the microphone product is
defective, return the complete product in its
original packaging to one of the addresses
below. For further assistance or technical
support call the international helpdesk at
+43 676 83200 888.
Fig. 5
Dimensions
Fig. 4
Removing the Cover
AKG ACOUSTICS GMBH
LAXENBURGERSTRASSE 254
1230 VIENNA
AUSTRIA
AKG ACOUSTICS, U.S. SERVICE
24950 GROVE VIEW ROAD
MORENO VALLEY, CA 92551
U.S.A
© 2015 HARMAN International Industries,
Incorporated. All rights reserved. AKG is a
trademark of AKG Acoustics GmbH, registered in
the United States and/or other countries.
Features, specications and appearance are
subject to change without notic e.
www.akg.com
