Sida 1/21

www.alfatronelectronics.com

ALFATRON ELECTRONICS GmbH GERMANY

ALF HD- -12 / 20X -TC, ALF- -SD- 12 / 20X TC PTZ Tracking

Camera

User Manual

ALF HD- - -12 20X - -TC and ALF 12 20X- -SD- TC

FCC Statement

NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the

FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.

This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the

instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will

not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which

can encouraged be determined by turning the equipment off and on, the user is to try to correct the interference by one or

more of the following measures:

---Reorient or relocate the receiving antenna.

---Increase the separation between the equipment and receiver.

---Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.

---Consult the dealer or an experienced radio/TV technician for help.

WARNING: Changes or modifications not expressly approved by the party responsible for compliance could void the user's

authority to operate the equipment.

Radiation Exposure

This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment.

This device complies with Industry Canada licence-exempt RSS standard(s). Operation is subject to the following two conditions:

(1) this device may not cause interference, and

(2) this accept device must any interference, interference that including may cause undesired operation of the device.

Radiation Exposure:

This equipment complies with IC radiation exposure limits set forth for an uncontrolled environment.

Do not dispose of this product with the normal household waste at the end of its life cycle. Return it to a collection point for the

recycling of electrical and electronic devices. This is indicated by the symbol on the product, user manual or packaging. The materials

are reusable according to their markings. By reusing, recycling or other forms of utilisation of old devices you make an important

contribution to the protection of our environment. Please contact your local authorities for details about collection points.

ALF HD- - -12 20X - -TC and ALF 12 20X- -SD- TC

Preface

This manual describes the functions, installation and operation principles and methods of the product in detail. Before installing

and using product, this please read it carefully.

1. Safety precautions

• During transportation, storage, installation, it is and use, necessary to prevent heavy pressure, severe

vibration, and immersion to avoid damage to the product.

• The product made shell is of organic material. Ensure product does not encounter corrosive liquid, gas, or

solid substances.

• Do rained it limit not let the product get wet or on. Do not use beyond the of temperature and humidity.

• When cleaning the lens, please use a soft dry cloth to wipe. When there is a lot of dust, please use a neutral

cleaner and wipe gently.

• Do not use a strong or corrosive detergent to avoid scratching the lens and affecting the image.

• This product has no parts that users can repair by themselves, and the damage caused by users ‘self-

disassembly does not fall within the scope of warranty.

2. Electrical safety

• The installation and use of products must strictly comply with the national and local electrical safety standards.

• Do specifications not use power adapters beyond the of the power supply, equipment otherwise the

components will will burn out and not work properly.

• In the process of using the product, we should keep enough distance -from the high power equipment, and do

a good job of lightning protection, surge protection and other protective measures when necessary.

• When the product is not in use, please disconnect the power switch and disconnect the

power adapter from the power socket.

• The product uses a DC 12V power supply, and the polarity of the power plug is as shown in

the picture.
