Alfatron ALF-PA100V Bruksanvisning
Alfatron
Mixerkonsol
ALF-PA100V
Läs nedan 📖 manual på svenska för Alfatron ALF-PA100V (20 sidor) i kategorin Mixerkonsol. Denna guide var användbar för 3 personer och betygsatt med 4.5 stjärnor i genomsnitt av 2 användare
Sida 1/20
ALFATRON ALF-PA100V
Safety Operation Guide
In order to guarantee the reliable operation of the equipment and safety of the staff,
please abide by the following in installation, using and maintenance:
1) The system must be earthed properly. Please do not use two blade plugs and
ensure the alternating power supply ranged from 100v to 240v and from 50Hz to
60Hz.
2) Do not put the switcher in extreme temperatures.
3) As the power generates heat when running, the working environment should be
maintained with good ventilation, in case of damage caused by overheating.
4) Please turn off the general power switch in humid weather or if left unused for long
periods of time.
5) Before following operation, ensure that the alternating current wire is pull out of the
power supply:
Take off or reship any components of the equipment.
Take off or rejoin any pin or other link of the equipment.
6) As to non-professional or without permission, please DO NOT try to open the casing
of the equipment, DO NOT repair it on your own, in case of accident or increasing
the damage of the equipment.
7) DO NOT splash any chemicals or liquid onto the equipment.
8) NOTICE: Please read this user manual carefully before using this product. Pictures
shown in this manual are for reference only, different model and specifications are
subject to real product.
This manual is for operation instruction only, not for any maintenance usage. Any
changes of functions and parameters will be informed separately. Please refer to
the dealers for the latest details.
All rights reserved. No part of this publication may be copied or reproduced
without permission.
ALFATRON ALF-PA100V
Table of Contents
1. Introduction ................................................................................................................. 1
1.1 Introduction to PA100V ...................................................................................... 1
1.2 Features ............................................................................................................ 1
1.3 Package Contents ............................................................................................. 1
2. Panel Description ........................................................................................................ 2
2.1 Front Panel ........................................................................................................ 2
2.2 Rear Panel ......................................................................................................... 3
3. System Connection ..................................................................................................... 4
3.1 Usage Precautions ............................................................................................ 4
3.2 System Diagram ................................................................................................ 4
3.3 Audio Signal Connection .................................................................................... 4
3.3.1 Audio Output ............................................................................................ 4
3.3.2 Audio Inputs ............................................................................................. 5
3.4 System Applications ........................................................................................... 6
4. System Operations ..................................................................................................... 6
4.1 Operations of Front Panel .................................................................................. 6
4.1.1 Audio switching ........................................................................................ 6
4.1.2 Volume/EQ controlling ............................................................................. 7
4.2 Operations of IR Remote ................................................................................... 7
4.3 Operations of Control Software ......................................................................... 8
4.3.1 Connection with Computer ...................................................................... 8
4.3.2 Installation/uninstallation of RS232 Control Software .............................. 8
4.3.3 Running Environment .............................................................................. 9
4.3.4 Function Settings ..................................................................................... 9
4.3.5 RS232 Communication Commands ...................................................... 11
5. Specifications ............................................................................................................ 13
6. Panel Drawing .......................................................................................................... 14
7. Troubleshooting and Maintenance ............................................................................ 15
8. After-sales Service ...................................................... Error! Bookmark not defined.
Produktspecifikationer
