1
Introduction
The ALOGIC USB-C to USB-A and Power Splitter lets you use the latest ALOGIC USB-C
DisplayLink Power dock with Power Delivery with a laptop with USB-A connection and a
legacy barrel type (DC Jacks) or onelink power connection.
The splitter has been designed for a small footprint for minimal use of desk space. Integrated
security loop allows for the splitter to be anchored securely to any desk with a lock.
It comes included with all the popular legacy laptop charging DC jacks for universal
compatibility with all popular laptop brads as per the below list:
Specifications
Model DCAP-SPL
Input USB-C with Power
Output Data: USB-A/USB 3.0 (20cm)
Power: DC Jack (20cm)
Warranty 2 Years
TIP Notebook
A Most Notebook
C Dell
G Acer
H HP
M Dell
I HP
O Asus
D1 Lenovo
Package Contents
ALOGIC USB-C to USB-A and Power Splitter
Set of Power tips
User Manual
2
3
4
Physical Layout
Power tips
USB-C
1
2
USB-A
DC Jack
3
4
User Instructions
1. Connect a USB-C to USB-C cable to a ALOGIC DisplayLink
dock with Power Delivery and the other end to the
ALOGIC Power Splitter.
2. Proceed to connect the tethered USB-A to the available
USB-A port on your laptop.
3. Select the appropriate notebook DC Jack and connect it to
your Notebook power Jack port.
* Power Tip NB DC Jack Table information below.
4. Charging will commence once connected and the ALOGIC
DisplayLink dock with Power Delivery is turned on.
TIP Notebook
A Most Notebook
C Dell
G Acer
H HP
M Dell
I HP
O Asus
D1 Lenovo
