Sida 1/11

Jeep/Chrysler/Dodge

SGS-CH01 1/11z

Jeep Wrangler

SGS-CH01

Factory Radio Camera Interface

with Active Guideline system

Installation Manual

z Model: Wrangler

z Model Year: 2011-2018 Model Year Active Guidlines Static Guidelines

Jeep Wrangler (JK) 2007-2010

Wrangler (JK) 2011-2018

Note

zDesign and speciﬁcations are subject to change without notice for improvement.

To Ensure Safe Use, Always Follow These Precautions

zThe installation of this product requires specialized skills and experience. We recommend that you have the

product installed by an Alpine authorized dealer.

zBefore you use this product, be sure to carefully read this installation manual and the separate user's manual

so that you can use the product correctly. Alpine Electronics bears no responsibility for problems that arise as

a result of failure to follow the instructions in the manuals.

zThis manual includes a number of symbols that are intended to help you use the product safely, to prevent

harm to you and others, and to protect against damage to property. These symbols and their meanings are

listed below. Make sure you fully understand these symbols before you begin reading the main text.

Explanations of Injury and Damage That May Result from Incorrect Use

Warning Ignoring the content marked by this indication and using the product incorrectly is

expected to lead to death or serious injury.

Caution Ignoring the content marked by this indication and using the product incorrectly is only

expected to lead to injury or property damage.

DISCLAIMER: The active guideline feature of this product is calibrated for use with JEEP WRANGLER model years

2011-2018. The accuracy of the active guideline system cannot be guaranteed if used in conjunction with other

vehicles or those which contain non-factory parts which may affect the turning radius of the vehicle.

* The speciﬁed vehicles have been tested and have met compatibility specs at the time of testing. Compatibility is

not guaranteed if the manufacturer has made production changes to the listed vehicles above.

Warning: Before you begin wiring, remove the ground wire from the negative

terminal of the battery. Failing to do so can lead to electric shock, injury or damage

to equipment.

Introduction

zCongratulations on purchasing the SGS-CH01. This installation manual is designed to take you through the

installation of SGS-CH01. Please familiarize yourself with the owners manual and if you still have additional

questions please call 1-800-TECH-101.

Jeep/Chrysler/Dodge

SGS-CH01 2/11z

Types of Precautions

Forbidden

Indicates actions that are

forbidden (must not be performed)

Forbidden

Indicates that disassembly is

forbidden.

Mandatory

Indicates actions that are

mandatory (must be performed)

Marks content that should receive

your full attention.

Warning

Do not disassemble or modify the product.

Doing so could lead to an accident, fire, or

electric shock.

Store screws and other small objects

where small children cannot reach them.

If one of these small objects is swal-

lowed, consult with a doctor immediately.

When replacing fuses, be sure to

use fuses with the specified current

rating. Failing to do so could lead to

an accident or fire.

Only connect the product to a 12 VDC

negative ground car. Failing to do so could

lead to an accident or fire.

Before you begin wiring, remove the

ground wire from the negative terminal of

the battery. Failing to do so could lead to

electric shock or injury.

Do not cut the insulation on a cord and take

power from another device. Doing so could

lead to fire or electric shock.

Do not install the product in a location

where it will obstruct the driver’s forward

view; interfere with the operation of the

steering wheel, gearshift, or the like; or

pose a threat to passengers. Doing so could

lead to an accident or injury.

When making a hole in the vehicle body, be

careful to avoid damaging pipes, the fuel

tank, electrical wiring, and the like. This

kind of damage could lead to an accident

or fire.

When installing and grounding the product,

do not use any of the bolts or nuts of the

steering wheel, brakes, fuel tank, or the

like. Doing so could make the brakes stop

working or lead to fire.

Do not install the product near the

passenger-side airbag. Doing so could

interfere with the operation of the airbag

and lead to an accident or injury.

Bundle cords so that they don’t interfere

with driving. Wrapping cords around the

steering wheel, gearshift, brake pedal,

or the like, could lead to an accident or

damage equipment.

Caution

Connect the product properly according to

the instructions. Failing to do so could lead

to fire or an accident.

Do not sandwich cords between the seat

railing or allow them to touch protrusions.

Resulting breaks or shorts could lead to

electric shock or fire.

Do not block vents or heat sinks. Doing so

could lead to fire or damage equipment.

Use the accessories according to the

instructions, and attach them securely.

Failing to do so could lead to an accident

or damage equipment.

Do not install the product where it may be

exposed to water or in a place with high

levels of humidity or dust. Doing so could

lead to fire or damage equipment.

The installation and wiring of this product

requires specialized skills and experience.

Have the product installed by an Alpine

authorized dealer.

Forbidden

Forbidden Mandatory

Mandatory

Forbidden

Jeep/Chrysler/Dodge

SGS-CH01 3/11z

Tools Possibly Required (This Will Vary Depending On The Vehicle)

Panel Removing Tool Sockets Phillips Screwdriver

Wire Cutters Extension Ratchet

Crimpers Pliers Torx Screwdriver

Accessory List

Installation Kit Parts

Interface Module Camera Harness Main Harness

CAM TRIG

Cable Ties x 2 Velcro x 2

Warning: Before you begin wiring, remove the ground wire from the negative

terminal of the battery. Failing to do so can lead to electric shock, injury or damage

to equipment.
