Sida 1/6
SPC-L500F / FB
SPC-L350F / FB
In Cabin Speaker Flush Mount
Installation Manual / Einbauanleitung
SPC-L500/350F
EN The In-Cabin speakers requires an additional
subwoofer.
Our recommendation is the Alpine SWC-D84L.
GE Die In-Cabin Lautsprecher benötigen einen
zusätzlichen Subwoofer.
Unsere Empfehlung ist der Alpine SWC-D84L.
SWC-D84L
EN The In-Cabin speakers can be installed horizontally or even vertically.
GE Die In-Cabin Lautsprecher können sowohl horizontal wie auch
vertikal installiert werden.
1. In-Cabin Speaker/
2. Speaker grill/ Lau
3. Metal brackets/ M
4. Plasc cover/ Kun
Parts list / Teileliste / Liste des pièces
6
5
ben
usskabel
•PH2 Screwdriver /
•Drilling machine with
90° countersink (for screwhead D=7 mm) and a 2mm drill /
Bohrmaschine mit
90° Kegelsenker (für Schraubenkopf D=7 mm) und 2mm Bohrer
+ 2mm
SPC-L500/350F
1
2
3
EN Fix the two metal brackets
with the attached screws
as shown.
GE Befestigen Sie die beiden
Metallhalter mit den
beiliegenden Schrauben
wie abgebildet.
EN Prepare the right cut-out inside
the cabinet or the wall cover.
GE Bereiten Sie den
entsprechenden Ausschnitt im
Möbelstück oder der Wand-
verkleidung vor.
EN Insert the speaker and mark
the holes of the metal
brackets. Remove the SP
and drill four 2mm holes.
Afterwards increase the holes
with a 90° countersink.
GE Setzen Sie den montierten
Lautsprecher in den
vorbereiteten Ausschnitt und
markieren die Löscher der
beiden Metallwinkel. Dann
entnehmen Sie den LS und
bohren zuerst vier 2mm
Löcher. Danach vergrößern
Sie die Bohrlöcher mit einem
90° Kegelfräser.
2mm
SPC-L500/350F
Produktspecifikationer
Varumärke: | Alpine |
Kategori: | hi-fi system |
Modell: | SPC-L500FB |
