FOR CAR USE ONLY/NUR FÜR AUTOMOBILGEBRAUCH/POUR APPLICATION AUTOMOBILE

UNIQUEMENT/SOLO PARA USO EN AUTOMÓVILES/PER IL SOLO UTILIZZO IN AUTOMOBILE

PREMIUM INFOTAINMENT SYSTEM

X701D-Q5

X701D-A4

X701D-A4R

Installation Manual

Einbauanleitung

Manuel d'installation

Manual de instalación

Manuale di installazione

1-EN

Before installing or connecting the unit, please read

the following thoroughly for proper use.

WARNING

MAKE THE CORRECT CONNECTIONS.

Failure to make the proper connections may result in fire or product

damage.

USE ONLY IN CARS WITH A 12 VOLT NEGATIVE GROUND.

(Check with your dealer if you are not sure.) Failure to do so may

result in fire, etc.

BEFORE WIRING, DISCONNECT THE CABLE FROM THE

NEGATIVE BATTERY TERMINAL.

Failure to do so may result in electric shock or injury due to electrical

shorts.

DO NOT ALLOW CABLES TO BECOME ENTANGLED IN

SURROUNDING OBJECTS.

Arrange wiring and cables in compliance with the manual to prevent

obstructions when driving. Cables or wiring that obstruct or hang up

on places such as the steering wheel, shift lever, brake pedals, etc. can

be extremely hazardous.

DO NOT SPLICE INTO ELECTRICAL CABLES.

Never cut away cable insulation to supply power to other equipment.

Doing so will exceed the current carrying capacity of the wire and

result in fire or electric shock.

DO NOT DAMAGE PIPE OR WIRING WHEN DRILLING

HOLES.

When drilling holes in the chassis for installation, take precautions so

as not to contact, damage or obstruct pipes, fuel lines, tanks or

electrical wiring. Failure to take such precautions may result in fire.

DO NOT USE BOLTS OR NUTS IN THE BRAKE OR

STEERING SYSTEMS TO MAKE GROUND CONNECTIONS.

Bolts or nuts used for the brake or steering systems (or any other

safety-related system), or tanks should NEVER be used for

installations or ground connections. Using such parts could disable

control of the vehicle and cause fire etc.

KEEP SMALL OBJECTS SUCH AS BATTERIES OUT OF

THE REACH OF CHILDREN.

Swallowing them may result in serious injury. If swallowed, consult a

physician immediately.

DO NOT INSTALL IN LOCATIONS WHICH MIGHT HINDER

VEHICLE OPERATION, SUCH AS THE STEERING WHEEL

OR SHIFT LEVER.

Doing so may obstruct forward vision or hamper movement etc. and

results in serious accident.

DO NOT OBSTRUCT AIRBAGS OR ANY OTHER SAFETY

RELEVANT PARTS OF THE VEHICLE WHILE INSTALLING

THE PRODUCT.

Doing so may lead to failure of the vehicle's safety systems and

results in severe injury or death. If you are unclear where such parts

are located, please review your car's user manual or contact your car

manufacturer.

CAUTION

HAVE THE WIRING AND INSTALLATION DONE BY

EXPERTS.

The wiring and installation of this unit requires special technical skill

and experience. To ensure safety, always contact the dealer where you

purchased this product to have the work done.

USE SPECIFIED ACCESSORY PARTS AND INSTALL THEM

SECURELY.

Be sure to use only the specified accessory parts. Use of other than

designated parts may damage this unit internally or may not securely

install the unit in place. This may cause parts to become loose

resulting in hazards or product failure.

ARRANGE THE WIRING SO IT IS NOT CRIMPED OR

PINCHED BY A SHARP METAL EDGE.

Route the cables and wiring away from moving parts (like the seat

rails) or sharp or pointed edges. This will prevent crimping and

damage to the wiring. If wiring passes through a hole in metal, use a

rubber grommet to prevent the wire's insulation from being cut by the

metal edge of the hole.

DO NOT INSTALL IN LOCATIONS WITH HIGH MOISTURE

OR DUST.

Avoid installing the unit in locations with high incidence of moisture

or dust. Moisture or dust that penetrates into this unit may result in

product failure.

PRECAUTIONS

• Be sure to disconnect the cable from the (–) battery post before

installing your X701D. This will reduce any chance of damage to

the unit in case of a short-circuit.

• Be sure to connect the colour coded leads according to the diagram.

Incorrect connections may cause the unit to malfunction or damage

to the vehicle's electrical system.

• When making connections to the vehicle's electrical system, be

aware of the factory installed components (e.g. on-board

computer). Do not tap into these leads to provide power for this

unit. When connecting the X701D to the fuse box, make sure the

fuse for the intended circuit of the X701D has the appropriate

amperage. Failure to do so may result in damage to the unit and/or

the vehicle. When in doubt, consult your Alpine dealer.
