AL-SND325F-001

USER MANUAL

SAFETY PRECAUTIONS

INSTRUCTION FOR USE REMOTE CONTROLLER

Declaration of conformity RTTE:

MARKET MAKER BRAND LICENSING

HELPLINE 0811 482 202

81 ROUTE NATIONALE 7

69570 DARDILLY-FRANCE

BUTTON FUNCTION

KEY FEATURES

OPERATION

2.USING CABLE

3.CARE AND MAINTENANCE

1.CONNECT USING BLUETOOTH TECHNOLOGY

WARRANTY CONDITIONS

REASONS FOR WARRANTY EXCLUSIONS: PACKAGE CONTENTS

GETTING STARTED

INSTALLATION

TECHNICAL SPECIFICATION

PARTS IDENTIFICATION

.Read these safety instructions before using your device and store them for possible

future reference.

.If the adaper cord is damaged,have it repaired by the manufacturer,its service or a

similarly qualified person in order to avoid any hazard.

.The power supply must be replaced by a new one in case of malfunction,because this

power supply is not repairable.

.The socket-outlet shall be installed near the equipment and shall be easily accessible.

.The adapter is not intended for use by persons(including children)with reduced

physical,sensory or mental capacity.Persons who have not read the manual,unless they

have received explanations by a person responsible for their safety and supervision

should not use this unit.

.Children should be monitored to ensure that they do not play with the adapter.

.The device should always be readily accessible.

.The device should not be exposed to dripping or splashing water.

.No objects filled with liquids such as vases shall be placed on the device.

.Always leave a minimum distance of 10 cm around the unit to ensure sufficient

ventilation.

.Open flame sources,such as candles,should not be placed on top of the device,

.The device is intended for use only in a temperate climate.

.At full volume,prolonged listening to the portable audio device may damage the user’s

hearing and cause hearing troubles(temporary or pemanent deafness,hearing drone,

tinnitus,hyperacusis).

So we recommend not to listen to the portable audio device at high audio volume

and no more than one hour per day at medium audio volume.

.CAUTION:Danger of explosion if battery is incorrectly replaced or not replaced by the

same type or equivalent.

.The battery should not be exposed to excessive heat such as sunshine,fire or similar.

.Different types of batteries,new and used batteries should not be mixed.

.The battery must be installed according to the polarity.

.If the battery is wom,it must be removed from the product.

.The battery must be disposed of safely.Always use the collection bins provided

(check with your dealer)to protect the environment.

.This product is guaranteed for 1 year against defects in manufacturing or assembly.

.This guarantee only applies to the primary purchase by the end user.It does not cover

issues related to improper handling by the user.Proof of purchase is required in order to

render the warranty valid.

.The warranty does not cover problems associated with improper use,whether it is a result

of negligence,processing,failure to store properly(excessive heat or humidity),improper

installation or unauthorizedrepairs.

.The manufacturer is contractually required to repair or replace the defective product.

ALTEC is under no financial obligation to pay any amount in excess of that paid by the

end user.

Turn ON the unit

Press bluetooth button on the remote controller

Press“SYNC”on the remote controller to go into pairing mode.LED indicator lights keep

blinking once the unit goes on pairing mode.

activate the bluetooth function on your bluetooth device(mobile phone or tablet).

please refer to manufacturer’s instructions for instructions on enabling bluetooth

on your device.

Once you have activated bluetooth on your device,select the(AL-SND325F-001)from

the list of available bluetooth devices.

If required,enter the password‘0000’ to confirm pairing.

Once paired successfully,the LED flashes green,until the unit remains paired.

Choose music from your bluetooth device and play music wireless throuth the speakers.

Turn ON the unit

Connect the 3.5mm stereo cables to the output port on your MP3/MP4/Cell phone/

tablet/Computer sound card(The cable end is color coded to match the output jack

on most sound cards-green color for speaker and red color for microphone).

Note:While connecting through auxiliary,green jack should be connected to the auxiliary port

of your music device.

Turn on your computer(or portable audio device).open media player such as windows

media player,etc,click on PLAY to start playing your music.

Adjust the volume,bass and treble using the remote controller to a comfortable

Listening level.make sure the volume on your speaker system,in your music software and the

main volume control in your operating system are all at an audible level(if any one of these

volume levels are set to the lowest settings,you will not have sound coming from the speakers).

Note:

While connected throuth auxiliary,all the media(Previous track/Next track)can be controlled

using the source device(MP3/MP4/Cell phone/Table etc.)

Read the following recommendations before using the bluetooth multi media speaker system.

following these you will be able to enjoy the product for many years.

Do not expose the unit to liquid,moisture or humidity to avoid the product’s internal circuit

being affected.

Don’t use abrasive cleaning solvents to clean the unit.

Don’t expose the unit to extremely high or low temperature ad this will shorten the life of

electronic devices,destroy the battery or distort certain pladtic parts.

Don’t dispose of the unit in fire as it will result in an explosion.

Don’t expose the unit to contact with sharp objects as this will cause scratches and damage.

Don’t let the unit fall down onto the floor.The internal circuit might get damaged.

Don’t attempt to disassemble and repair the unit.Only qualified personnel

.Expired warranty period

.No proof of purchase

.Visible damage/breakage

.Oxidation

.Improper use

.Use of non-approved accessories

.Product altered,repaired or modified by an unauthorized third party

.Missing or altered serial number

.Warranty voided due to broken or altered packaging

.Damage due to accident,neglect,improper maintenance/care or force majeure

.Damage due to the installation of third-party software or a virus.

Sub-woofer

Satellite speakers-left & right

Remote control

Power adaptor

Instruction manual

1.Place the left and right satellite speakers next to the sub-woofer

2.Connect the satellite speakers to the appropriate connector on the back of the

sub-woofer.It should be connected on the 6(shown on figure I)speaker connection jack.＃

3.Connect the power adapter to the DC input jack 5(shown on figure I)and to a standard ＃

AC electrical outlet(a surge protector is recommended to protect your new bluetooth multi

media speaker system).

4.Power ON the unit using the power ON/OFF switch 4(shown on figure i)on the back ＃

of the sub-woofer.Also press power on button ON the remote controller.

you can now start using the BLUETOOTH 2.1 MULTI MEDIA SPEAKER SYSTEM

Remove the unit from the box.

Remove any packaging from the product.

Please retain all packaging until you have checked and counted all the parts and

the contents

Against the parts list.

2.1 bluetooth speaker

Power:DC 12V 1125mA

Watts sub-woofer

6x2 watts satellite speakers

Total 12 watts sound output

Adaptor technical data:

input:AC 230V/50Hz

Output:DC12V 1125mA

1.Lcd indicator

2.Volume control

3.Air duct

4.Power ON/OFF switch

5.AC input jack

6.Speaker connection jack

7.Microphone input jack

8.Headphone jack

9.Auxiliary jack

10.Satellite connection cable

11.Wireless remote control

Power ON/OFF Pressing this button turns ON or OFF the unit

To avoid possible hearing damage,do not listen at high audio volume for

long periods of time.

Market Maker Brand Licensing,herby declares that this equipment,

conforms to the essential requirements and other relevant provisions of

directive 1999/5/CE.The declaration of conformity can be viewed at the

following address:

Please visit us at www.alteclansing.com

Produt features,specifications and appearances

are subject to change without notice. 2015 Alte c Lansing/AL Infinity,LLC.

ALTEC,ALTECLANSING,the Altec

Lansing logo are marks of Altec

Lansing/AL Infinity LLC

Market Maker Brand Licensing

81ROUTE NATIONALE 7

69570 DARDILLY.

The European directive 2002/96/CE on Waste Electrical and Electronic

Epuipment(WEEE),requires that old household electrical appliances must

not be disposed of in the normal unsorted municipal waste stream.Old

appliances must be collected separately in order to optimize the recovery

and recycling of the materials they contain,and reduce the impact on

human health and the environment.The crossed out“wheeled bin”symbol

on the product reminds you of your obligation,that when you dispose of

the appliance,it must be separately collected.Please visit us at

www.alteclansing.com

Pressing this button mutes the system

Pressing this button enables unit into bluetooth mode

Press this button once puts the unit

bluetooth pairing mode

Press this button when you are paired with bluetooth.

This will paly previous track

Press this button when you are paired with bluetooth.

This will paly or pause the current track

Press this button when you are paired with bluetooth.

This will paly next track

Pressing this button enables AUX mode-wired connection

thecomputer or any other portable audio device connected

using wires,is activated.

Mute

AUX

Previous track

Play/Pause

Next track

Increase volume This will increase the volume

Increase treble This will increase the treble

Decrease treble This will decrease the treble

Increase bass This will crease the bass

Decrease bass This will decrease the bass

Bluetooth multi media speakers

Compatible with all bluetooth enabled devices such as smart phones,tablets,Computers Etc.

Wired connection also available for computers,netbooks,laptops etc

Syncs in seconds

Digital volume indicator

Wireless remote controller included

Wireless range≥6 meters(33 feet)

Bluetooth pairing name:AL-SND325F-001

Decrease volume This will decrease the volume

Bluetooth

Pairing modein

Bluetooth
