Sida 1/156
STAGEDRIVE+
QUICKSTART GUIDE
ENGLISH ( 1 - 26 )
GUÍA DE INICIO RÁPIDO
ESPAÑOL ( 27 - 52 )
GUIDE D’UTILISATION SIMPLIFIÉ
FRANÇAIS ( 53 – 77 )
GUIDA RAPIDA
ITALIANO ( 78 - 103 )
KURZANLEITUNG
DEUTSCH ( 104 – 128 )
SNELSTARTGIDS
NEDERLANDS ( 129 – 153 )
QUICKSTART GUIDE (ENGLISH)
BOX CONTENTS
STAGEDRIVE+
Power cable
Software CD
Quickstart Guide
Safety & Warranty Information Booklet
QUICK SETUP
1. Make sure all items listed in the BOX CONTENTS section are included in the box.
2. READ SAFETY & WARRANTY INFORMATION BOOKLET BEFORE USING THE PRODUCT.
3. Study the connection diagram in this guide.
4. Place all devices in an appropriate position for operation.
5. Make sure all devices are turned off and all faders and gain knobs are set to "zero."
6. Connect all sound sources' outputs to amplifier inputs as indicated in the diagram.
7. Connect the amplifier outputs to speakers.
8. Plug all devices into an appropriate power source.
9. Switch everything on in the following order:
• Sound sources (i.e. microphones, turntables, CD players, etc.)
• Mixer
• Amplifier
• Speakers
10. When turning powering down, turn everything off in the following order:
• Speakers
• Amplifier
• Mixer
• Sound sources
FRONT PANEL DIAGRAM
1. MODE BUTTON- Selecting one of four modes: PRESET, DELAY, EDIT and UTILITY.
2. DISPLAY- Shows the pages of the various menus and their parameters.
3. DIAL KNOB- Edits the value of the selected parameter.
4. PREV/NEXT BUTTON- Accesses menu pages and/or parameters.
5. NAVIGATION CURSOR KEYS- Selects various parameters.
6. MEMORY CARD SLOT- MMC card slot to store PRESETS.
7. ENTER KEY- Confirms editing of parameters.
8. ESC KEY- Exits the selected editing page or cancels an editing operation.
9. INPUT LEVEL LEDs- Shows the level of input A/B.
10. MUTE SWITCHES- Mutes the signal from any of the six respective outputs.
11. OUTPUT LEVEL LEDS- Shows the output level.
Note: The LIMITER will change the way in which the output level is displayed on the corresponding LED. The
level shown on the meter is no longer the "absolute" output level, but the level of the signal at -24dB, -12dB,
-6dB compared to the limiter threshold (indicated by the orange LIMIT LED).
1
23
4
6
5
7
8
9
10
11
2
REAR PANEL DIAGRAM
1
3
2456
7
8
1. AC INPUT AND FUSE HOLDER- Connect the included power cable here.
CAUTION: If the fuse needs to be replaced, please refer to a qualified technician. If the fuse continues
to blow after replacing, discontinue use of this unit and seek repair.
2. POWER SWITCH- Turns the main POWER on and off.
3. DIGITAL IN- Connect a balanced XLR-F cable here.
4. RS485 OUT- Allows outgoing communication between a STAGEDRIVE+ and other STAGEDRIVE+
units.
5. RS485 IN- Allows incoming communication between a STAGEDRIVE+ and other STAGEDRIVE+
units.
6. USB PORT- Allows communication via PC.
7. OUTPUTS- Use Balanced XLR-M cables on these outputs.
8. INPUTS- Balanced XLR - ¼” combo jacks.
GETTING STARTED
Adjusting the input signal
1. Keep the STAGEDRIVE+ outputs in MUTE status (LEDs on) by pressing each respective Mute button
on the front panel.
2. Feed a signal into the STAGEDRIVE+ input and watch the INPUT LEVEL A-B LED meter.
3. Keep the signal high, but without triggering the CLIP LED continually, adjusting the input gain if
necessary.
4. Press the MODE key until the EDIT menu LED lights up. Use the PREV and NEXT keys to go to the
Input Gain page and then press ENTER.
5. Use the DIAL to change the gain value and watch the level of the signal on the LED meter until ideal
values are reached.
6. Use the PREV and NEXT keys to access to the INB Gain page.
MENUS
PRESET Menu
Types of PRESETS
There are 3 categories of PRESETS:
• F = Factory PRESETS which cannot be permanently changed. These are the starting points for
creating User PRESETS and card PRESETS from scratch.
• U = User PRESETS can be programmed by users.
• C = Card PRESETS can be programmed by users and stored on a Multimedia Memory Card.
