Sida 1/6
MADE IN USA
SIX YEAR WARRANTY
Acclaim Portable Lectern Sound System Owners Manual
For System Setup & Operation Videos Visit Our Website: www.anchoraudio.com
MADE IN USA
SIX YEAR WARRANTY
A Message from the President
Congratulations on purchasing an Anchor Audio sound system, the choice
of thousands of satisfied customers including the White House, prestigious
universities, school districts nationwide, police and fire departments, and all
branches of the U.S. military. Our products are made of the finest materials
and built with pride in the U.S.
We’ve incorporated the latest technology into your sound system yet kept
it simple to use. Just take a few minutes to review this manual to ensure
the maximum enjoyment of your Anchor system. Or, you can view a
demonstration video complete with a trouble shooting section at
www.anchoraudio.com.
Feel free to call our friendly customer support staff at 1-800-ANCHOR1
Monday thru Friday between 7:00am and 5:00pm Pacific Standard Time
with any questions. We love to hear from our customers.
Janet Jacobs, President
on behalf of all Anchor employees
GETTING STARTED
Please check your new unit carefully for any
damage which may have occurred during shipment.
Each Anchor product is carefully inspected at the
factory and packed in specially designed boxes for
safe transport.
Notify the freight carrier immediately of any damage
to the shipping box or product. Repack the unit
in the original box and wait for inspection by the
carrier’s claim agent. Notify your dealer of the
pending freight claim.
NOTE: All damage claims must be made with freight carrier!
RETURNING SYSTEMS FOR SERVICE
OR REPAIR
For service or repair, please contact the dealer
you purchased your system from or Anchor Audio
Customer Service at 800.262.4671 to obtain a
RA
(Return Authorization)
number. You may
also complete an online RA request form at
www.anchoraudio.com. All shipments to Anchor
Audio must include a RA number and must be
shipped prepaid. C.O.D. shipments will be refused
and returned at your expense.
IMPORTANT: Save the shipping box & packing materials,
they were specially designed to ship your unit!
WARRANTY REGISTRATION
Visit our website at www.anchoraudio.com and
select “Warranty Registration.” Complete the online
form to activate the six-year limited warranty on
your Acclaim Portable Lectern and two-year limited
warranty for the microphones.
1
GETTING STARTED 1
.....................................................................................................................................
ACCLAIM LECTERN BASIC SYSTEM OPERATION 2
..........................................................................................
OPERATING THE BUILT-IN UHF WIRELESS RECEIVER 3 ....................................................................................
OPERATING THE WIRELESS MICROPHONE / TRANSMITTER ..........................................................................
4
CARING FOR YOUR BUILT-IN BATTERIES 5
......................................................................................................
HAVING TROUBLE WITH YOUR SOUND SYSTEM? .........................................................................................
6
ACCLAIM SOUND SYSTEM TECHNICAL SPECIFICATIONS 6
..............................................................................
CONTENTS
100-0163-000/C - 1/11
MADE IN USA
SIX YEAR WARRANTY
Acclaim Portable Lectern Sound System Owners Manual
For System Setup & Operation Videos Visit Our Website: www.anchoraudio.com
2
TOP PANEL OF ACL-7500U2
BACK PANEL OF ACL-7500U2
BASIC SYSTEM OPERATION
NOTE: Fully Charge Batteries Before First Use!
IMPORTANT: Make all connections with shielded cables to avoid
hum, buzzing or interference.
1. Set all Input Level Controls to minimum & Tones Controls
to flat
(the middle setting)
before turning your system on
2. Plug lectern gooseneck microphone into the Lectern Mic
Jack located on the tabletop
3. Switch POWER to ON, the BATTERY LED will light
4. Slowly increase the Level Control for the input jacks used
to the desired volume
5. Adjust BASS & TREBLE controls to desired sound quality
AUXILIARY MICROPHONE
INPUT JACK – XLR
Balanced - low impedance microphones,
powers condenser mics
SPEAKER OUT
OUTPUT JACK – 1/4” PHONE
Balanced - drives an unpowered 2 ohm speaker
in addition to the built-in speakers
LINE IN
INPUT JACK – 1/4” PHONE
Jack may be combined with mic inputs
for a composite output
For playback of tape/CD player or
other audio source
LINE OUT
OUTPUT JACK – 1/4” PHONE
Balanced - provides combined
output of all active system inputs
Record presentation / connect to another
powered sound system
ACCLAIM LECTERN TABLETOP
All Models
LECTERN
MICROPHONE
JACK
FRONT/SPEAKER
LECTERN TOP
CHARGE INDICATOR LIGHT
UHF WIRELESS RECEIVER
Available on selected models only
LINE IN
LEVEL CONTROL
WIRED MIC LEVEL
CONTROL
LOW BATTERY
INDICATOR LIGHT
POWER SWITCH
LECTERN LEVEL
CONTROL
WIRELESS MICROPHONE 1
LEVEL CONTROL
WIRELESS MICROPHONE 2
LEVEL CONTROL
MADE IN USA
SIX YEAR WARRANTY
Acclaim Portable Lectern Sound System Owners Manual
For System Setup & Operation Videos Visit Our Website: www.anchoraudio.com
CHANNEL SELECTION - BUILT-IN RECEIVER
Select a channel, set the built-in receiver & microphone transmitter
to that channel before using your wireless system.
1. Choose any available wireless channel/
frequency from 1 thru 16
(see page 4 for transmitter instructions)
2. Set the Wireless Channel Selector Knob to the channel/
frequency you choose in step 1
WIRELESS 2
VOLUME CONTROL
WIRELESS 1 CHANNEL
SELECTION
WIRELESS 1 RX
INDICATOR LIGHTS
WIRELESS 2 RX
INDICATOR LIGHTS
WIRELESS 1
VOLUME CONTROL
WIRELESS 2 CHANNEL
SELECTION
DIVERSITY WIRELESS BY ANCHOR AUDIO
Anchor Audio UHF wireless is a 16 channel, diversity wireless system that receives signals with two independent antennae. With diversity
wireless the receiver processes the stronger signal, effectively minimizing dropouts and interference from other transmitting sources. The
antennae are mounted internally so there are no obstructions or risk of damage.
NOTE: Ongoing wireless interference? The frequency you selected may be in use by other systems in the area!
Change channels until you find a clear frequency!
If you have two wireless receivers repeat above for the second receiver.
Remember, each receiver/transmitter pair must be set to different
channels to avoid interference.
3
WIRELESS 1
CHANNEL
RX
WIRELESS 2
CHANNEL
RX
RXRX
1
3 57
9
11
13
15
1
3 57
9
11
13
15
