MegaVox Pro Public Address System Owners Manual
For System Setup & Operation Videos Visit Our Website: www.anchoraudio.com
MADE IN USA
SIX YEAR WARRANTY
A Message from the President
Congratulations on purchasing an Anchor Audio sound system, the choice of thousands
of satisfied customers including the White House, prestigious universities, school
districts nationwide, police and fire departments, and all branches of the U.S. military.
Our products are made of the finest materials and built with pride in the U.S.
We’ve incorporated the latest technology into your sound system yet kept it simple to
use. Just take a few minutes to review this manual to ensure the maximum enjoyment
of your Anchor system. Or, you can view a demonstration video complete with a trouble
shooting section at www.anchoraudio.com.
Feel free to call our friendly customer support staff at 1-800-ANCHOR1 Monday thru
Friday between 7:00am and 5:00pm Pacific Standard Time with any questions. We love
to hear from our customers.
Janet Jacobs, President
on behalf of all Anchor employees
GETTING STARTED / WARRANTY INFORMATION 1 .......................................................................
BASIC SYSTEM OPERATION 2 ....................................................................................................
CONNECTING PA SYSTEM / CONTROLLING FEEDBACK 3 ............................................................
OPERATING THE BUILT-IN UHF WIRELESS RECEIVER 4 .................................................................
OPERATING THE WIRELESS MICROPHONE / TRANSMITTER ....................................................... 5
CARING FOR YOUR BATTERY 6 ...................................................................................................
HAVING TROUBLE WITH YOUR SOUND SYSTEM? / TECHNICAL SPECIFICATIONS ......................... 7
CONTENTS
GETTING STARTED
Please check your new unit carefully for any
damage which may have occurred during shipment.
Each Anchor product is carefully inspected at the
factory and packed in specially designed boxes for
safe transport.
Notify the freight carrier immediately of any damage
to the shipping box or product. Repack the unit
in the original box and wait for inspection by the
carrier’s claim agent. Notify your dealer of the
pending freight claim.
NOTE: All damage claims must be made with freight carrier!
RETURNING SYSTEMS FOR SERVICE
OR REPAIR
For service or repair, please contact the dealer
you purchased your system from or Anchor Audio
Customer Service at 800.262.4671 to obtain a
RA
(Return Authorization)
number. You may
also complete an online RA request form at
www.anchoraudio.com. All shipments to Anchor
Audio must include a RA number and must be
shipped prepaid. C.O.D. shipments will be refused
and returned at your expense.
IMPORTANT: Save the shipping box & packing materials,
they were specially designed to ship your unit!
WARRANTY REGISTRATION
Visit our website at www.anchoraudio.com and
select “Warranty Registration.” Complete the online
form to activate the six-year limited warranty on
your MegaVox Public Address System and two-year
limited warranty for the microphones.
1
100-0058-000 rev. A 12/10
MADE IN USA
SIX YEAR WARRANTY
MegaVox Pro Public Address System Owners Manual
For System Setup & Operation Videos Visit Our Website: www.anchoraudio.com
2
BACK PANEL OF MEGA-6000U2
BASIC SYSTEM OPERATION
NOTE: Fully Charge Batteries Before First Use!
IMPORTANT: Make all connections with shielded cables to avoid
hum, buzzing or interference.
1. Before turning the systems power on: Set all Input
Level Controls
2. Plug a microphone into a MIC jack and/or a line-level
audio source into the LINE IN jack
3. Switch POWER to ON - The red BATTERY LED will turn
on
(If the light flashes or stays off charge the battery)
4. Slowly increase the Level Controls for the input jacks
used to desired volume level
WIRELESS RECEIVERS
(see page 4)
WIRELESS LEVEL CONTROLS
MIC - INPUT JACK
1/4” Phone - Unbalanced,
low impedance, no
phantom power
LINE IN - INPUT JACK
1/4” Phone - For any line-level
signal source: tape/VCR/CD/DVD
players, musical instruments, etc.
CHARGER INPUT JACK
SPEAKER OUT -
OUTPUT JACK
1/4” Phone - Drives the MEGA-6001
unpowered companion speaker
Using companion speaker will decrease
battery service time requiring more
frequent charging
MIC/SIGNAL ALERT
LEVEL CONTROL
LINE IN
LEVEL CONTROL
LINE OUT - OUTPUT JACK
1/4” Phone - Unbalanced, combined
output of all active system inputs
(Output is post source level; any volume
fluctuations for a specific input will
affect this output signal level)
BATTERY CHARGE
INDICATOR
POWER SWITCH
SIGNAL ALERT BUTTON
System emits a loud, air-horn type tone
Push & hold button to activate siren
and control volume with MIC/SIGNAL
control
CAUTION: The signal alert sound can produce VERY high or harmful sound pressure levels that can cause hearing damage.
SPEAKER STAND SETUP
1. Loosen the Lower Collar Knob
2. Separate the stand legs until the leg support Cross
Braces are parallel to the floor
3. Tighten the Lower Collar Knob
4. Loosen the Upper Collar Knob and extend the
center pole
5. Adjust height and retighten the Upper Collar Knob
6. Place your Anchor sound system on the stand
LOWER
COLLAR KNOB
UPPER
COLLAR
KNOB
CROSS BRACES
MADE IN USA
SIX YEAR WARRANTY
MegaVox Pro Public Address System Owners Manual
For System Setup & Operation Videos Visit Our Website: www.anchoraudio.com
3
CONTROLLING FEEDBACK
Feedback, a howling noise or shrill sound, is self-generated by the sound system. It’s caused by
a microphone picking up the sound coming from the speaker and then re-amplifying it. Once a
feedback loop starts, it continues until the system is adjusted.
FEEDBACK CAUSES
• Microphonetooclose,pointingtowards
or in front of speaker
• Volumesettingistooloudforroom
• Soundreectingoffhardsurfaces
AVOIDING & ELIMINATING FEEDBACK
• Pointmicrophoneinadifferentdirection
• Keepmicrophoneawayfromthespeaker
• PlacespeakerinFRONTofthemicrophone
• Reducethesoundsystemvolumelevels
CAUTION: Feedback can damage your equipment & may be hazardous to hearing.
CORRECT SYSTEM PLACEMENT WRONG SYSTEM PLACEMENT
CONNECTING TWO OR MORE MEGAVOX PRO PA SYSTEMS
UNPOWERED MEGAVOX PRO COMPANION SPEAKER
(MEGA-6001)
Connect one end of a speaker cable
(SC-50)
to the SPKR OUT jack on the back of a
powered MegaVox PRO PA system.
The other end connects to the jack labeled IN on the back of a MegaVox PRO
unpowered companion speaker.
NOTE: AC power is not required for an unpowered companion speaker.
POWERED MEGAVOX PRO PA SYSTEMS WITH LINE OUT
Connect speaker cable
(EX-50PP)
from LINE OUT on first powered MegaVox PRO to
LINE IN on second powered MegaVox PRO. Set volume level of the second system to
maximum, this gives full volume control to the first or primary PA system.
DAISY-CHAINING
Use the Line Out method above to connect up to six powered MegaVox PRO PA
Systems. Make all connections with power off.
Set volume level to maximum on all secondary systems so the primary unit Level
Control sets the volume for the entire chain.
To avoid speaker popping, which can cause damage, power speakers on in order,
primary unit first, and power speakers off in reverse order, primary unit last.
FIRST POWERED MEGAVOX PRO
SECOND POWERED
MEGAVOX PRO
EX-50PP CABLE
