MADE IN USA
SIX YEAR WARRANTY
AN-135+ Speaker Monitor Owners Manual MADE IN USA
SIX YEAR WARRANTY
A Message from the President
Congratulations on purchasing an Anchor
Audio sound system, the choice of thousands
of satisfied customers including the White
House, prestigious universities, school districts
nationwide, police and fire departments, and all
branches of the U.S. military. Our products are
made of the finest materials and built with pride
in the U.S.
We’ve incorporated the latest technology into
your sound system yet kept it simple to use. Just take a few minutes to review this
manual to ensure the maximum enjoyment of your Anchor system. Or, you can view a
demonstration video complete with a trouble shooting section at www.anchoraudio.com.
Feel free to call our friendly customer support staff at 1-800-ANCHOR1 Monday thru
Friday between 7:00am and 5:00pm Pacific Standard Time with any questions. We love
to hear from our customers.
Janet Jacobs, President
on behalf of all Anchor employees
CONTENTS
GETTING STARTED
Please check your new unit carefully for any
damage which may have occurred during shipment.
Each Anchor product is carefully inspected at the
factory and packed in specially designed boxes for
safe transport.
Notify the freight carrier immediately of any damage
to the shipping box or product. Repack the unit
in the original box and wait for inspection by the
carrier’s claim agent. Notify your dealer of the
pending freight claim.
NOTE: All damage claims must be made with freight carrier!
RETURNING SYSTEMS FOR SERVICE
OR REPAIR
For service or repair, please contact the dealer
you purchased your system from or Anchor Audio
Customer Service at 800.262.4671 to obtain a
RA
(Return Authorization)
number. You may
also complete an online RA request form at
www.anchoraudio.com. All shipments to Anchor
Audio must include a RA number and must be
shipped prepaid. C.O.D. shipments will be refused
and returned at your expense.
IMPORTANT: Save the shipping box & packing materials,
they were specially designed to ship your unit!
WARRANTY REGISTRATION
Visit our website at www.anchoraudio.com and
select “Warranty Registration.” Complete the
online form to activate the six-year limited warranty
on your AN-135+ speaker monitor and two-year
limited warranty for the microphones.
1
100-0196-000 rev. A
GETTING STARTED 1 ..................................................................................................................
ARCHITECTS’ SPECIFICATION / BACK PANEL 2 ............................................................................
AN-135+ TECHNICAL SPECIFICATIONS .................................................................................... 3
MADE IN USA
SIX YEAR WARRANTY
AN-135+ Speaker Monitor Owners Manual
2
BACK PANEL OF AN-135ARChITECTS’ SPECIFICATION
NOTE: When connecting multiple AN-135 units
(daisy chaining)
stereo cable
MUST be used to avoid interference.
POWER ON
LINE IN/LINE OUT
(3.5 MM)
LINE IN
(1/4” PHONE)
Record your presentation or “daisy-
chain” another AN-135 for greater
crowd coverage
The speaker shall be an Anchor AN-135 or equivalent.
The general construction shall include an injection-
molded case, one 4.5” Neodymium woofer and input
terminations consisting of both 3.5 mm and 1/4” phone.
The maximum speaker dimensions shall not exceed
5.25” high, 8.4” wide and 9” deep. The maximum
weight shall be 3.5 pounds.
The case shall be formed by injection-molded ABS, and
shall have a finish of black or white.
The speaker has the ability to be mounted on walls,
ceilings, equipment racks and speaker stands with
appropriate hardware and accessories.
Waste electrical and electronic products must not be disposed of with
household waste. Please recycle where facilities exist. Check with
your Local Authority or Retailer for recycling advice.
SB-3BK+
40° tilt bracket
A multi-purpose bracket used
for mounting the AN-135 to a
wall or ceiling.
SB-360BK+
360° swivel bracket
A multi-purpose bracket used for
mounting the AN-135 to a wall or
ceiling.
MOUNTING BRACKETS
MADE IN USA
SIX YEAR WARRANTY
AN-135+ Speaker Monitor Owners Manual
AN-135 TEChNICAL SPECIFICATIONS
(Specifications Subject to Change Without Notice)
ANCHOR AUDIO CUSTOMER SERVICE
800.262.4671
FOR ADDITIONAL INFORMATION
visit www.anchoraudio.com
3
Rated Power Output 30 Watts
Max SPL @ Rated Power 109 dB @ 1 meter
Frequency Response 65Hz - 18KHz ±3dB
Speaker Type 4.5” Neodymium woofer
Line Out Jack line level, 3.5 mm – stereo
Line In Jack line level, 3.5 mm – stereo & 1/4” phone – mono
AC Power Req. 100 - 240 VAC, 47/63 Hz (70W Max.)
Dimensions
(HWD)
5.25” x 8.4” x 9” (13 x 21 x 23 cm)
Weight 3.5 lbs / 1.58 Kg
