Sida 1/7
MADE IN USA
SIX YEAR WARRANTY
Beacon® Sound System Owners Manual
For System Setup & Operation Videos Visit Our Website: www.anchoraudio.com
MADE IN USA
SIX YEAR WARRANTY
A Message from the President
Congratulations on purchasing an Anchor Audio sound system, the choice of thousands
of satisfied customers including the White House, prestigious universities, school
districts nationwide, police and fire departments, and all branches of the U.S. military.
Our products are made of the finest materials and built with pride in the U.S.
We’ve incorporated the latest technology into your sound system yet kept it simple to
use. Just take a few minutes to review this manual to ensure the maximum enjoyment
of your Anchor system. Or, you can view a demonstration video complete with a trouble
shooting section at www.anchoraudio.com.
Feel free to call our friendly customer support staff at 1-800-ANCHOR1 Monday thru
Friday between 7:00am and 5:00pm Pacific Standard Time with any questions. We love
to hear
from our customers.
Janet Jacobs, President
on behalf of all Anchor employees
GETTING STARTED / WARRANTY INFORMATION 1 .......................................................................
BASIC SYSTEM OPERATION / LINE ARRAY TOWER 2 ...................................................................
TRAVEL DOLLY / CONTROLLING FEEDBACK 3 .............................................................................
USING THE BUILT-IN MP3 / OPERATING THE BUILT-IN UHF WIRELESS RECEIVER 4 .........................
OPERATING THE WIRELESS MICROPHONE / TRANSMITTER ....................................................... 5
CARING FOR YOUR BATTERY 6 ...................................................................................................
HAVING TROUBLE WITH YOUR SOUND SYSTEM? / TECHNICAL SPECIFICATIONS ......................... 7
CONTENTS
GETTING STARTED
Please check your new unit carefully for any
damage which may have occurred during shipment.
Each Anchor product is carefully inspected at the
factory and packed in specially designed boxes for
safe transport.
Notify the freight carrier immediately of any damage
to the shipping box or product. Repack the unit
in the original box and wait for inspection by the
carrier’s claim agent. Notify your dealer of the
pending freight claim.
NOTE: All damage claims must be made with freight carrier!
RETURNING SYSTEMS FOR SERVICE
OR REPAIR
For service or repair, please contact the dealer
you purchased your system from or Anchor Audio
Customer Service at 800.262.4671 to obtain a
RA
(Return Authorization)
number. You may
also complete an online RA request form at
www.anchoraudio.com. All shipments to Anchor
Audio must include a RA number and must be
shipped prepaid. C.O.D. shipments will be refused
and returned at your expense.
IMPORTANT: Save the shipping box & packing materials,
they were specially designed to ship your unit!
WARRANTY REGISTRATION
Visit our website at www.anchoraudio.com and
select “Warranty Registration.” Complete the online
form to activate the six-year limited warranty on
your Beacon sound system and two-year limited
warranty for the microphones.
1
100-0190-000 rev. A 11/10
MADE IN USA
SIX YEAR WARRANTY
Beacon® Sound System Owners Manual
For System Setup & Operation Videos Visit Our Website: www.anchoraudio.com
2
BACK PANEL OF BEA-7500MU2
WIRELESS RECEIVERS
(see page 4)
POWER SWITCH
UNIVERSAL MIC – INPUT JACKS
Balanced XLR – low impedance, for balanced mic,
powers condenser-type mics.
Unbalanced 1/4” – high impedance, for unbalanced
mics, no phantom power.
AC POWER CORD INLET
LINE OUT – OUTPUT JACK
Balanced 1/4” & Dual RCA provide a
combined output of all active system inputs.
Record your presentation or connnect to
another powered sound system. VOICE OVER BUTTON
Reduce Line and CD Input levels by 12dB
when using microphones allowing speakers
to be heard over background music.
ON = Button In OFF = Button Out
CHARGE STATUS LEDS
Green - Charge complete
Amber - Charge nearly complete
Red - Charging has begun
Battery Empty LED
Red - charge battery immediately
Power On LED
Green - power on
LINE IN LEVEL CONTROL
LINE IN – INPUT JACKS
The 1/8 (3.5mm) jack is used to hook
up a portable CD player, iPod, laptop
or other external audio source.
Dual RCA unbalanced inputs can
be used for daisy-chaining together
multiple Beacon speakers.
USB DC OUT -12V 500 mA
To charge/power external device
TONE CONTROLS – BASS/TREBLE
MP3 PLAYER
(see page 4)
MICROPHONE LEVEL CONTROLS
DC OUT - 5V 500 mA
To charge/power external device
BASIC SYSTEM OPERATION
NOTE: Fully Charge Batteries Before First Use!
IMPORTANT: Make all connections with shielded cables to avoid
hum, buzzing or interference.
1. Remove Travel Dolly
(page 3)
and open Line Array
(below)
2. Set all Input Levels to minimum & Tone Controls to flat
(middle)
setting
3. Plug wired microphone into the MIC 1 or MIC 2 jacks
and/or any audio source into the LINE-IN jacks
4. Switch POWER to ON, Power ON LED will light
5. Slowly increase Level Controls for active Input Jacks
to desired volume
6. Adjust Tone Controls for desired sound quality
OPENING BEACON LINE ARRAY
1. Open Array latches
2. Grasp handle and remove Array from base
3. Turn Array over and place on top of base
4. Close Array latches
5. Slowly flip Array Tower up until locked
securely into place
CLOSING BEACON LINE ARRAY
1. Turn POWER to OFF
2. Fold Array in half (apply slight pressure)
3. Open latches and remove folded Array
4. Turn Array over grasp handle and slide into base
5. Close Array latches
IMPORTANT: Latches MUST be locked and grill MUST
face forward for system to work!
MADE IN USA
SIX YEAR WARRANTY
Beacon® Sound System Owners Manual
For System Setup & Operation Videos Visit Our Website: www.anchoraudio.com
3
CONTROLLING FEEDBACK
Feedback, a howling noise or shrill sound, is self-generated by the sound system. It’s caused by
a microphone picking up the sound coming from the speaker and then re-amplifying it. Once a
feedback loop starts, it continues until the system is adjusted.
FEEDBACK CAUSES
• Microphonetooclose,pointingtowards
or in front of speaker
• Volumesettingistooloudforroom
• Soundreectingoffhardsurfaces
AVOIDING & ELIMINATING FEEDBACK
• Pointmicrophoneinadifferentdirection
• Keepmicrophoneawayfromthespeaker
• PlacespeakerinFRONTofthemicrophone
• Reducethesoundsystemvolumelevels
CAUTION: Feedback can damage your equipment & may be hazardous to hearing.
CORRECT SYSTEM PLACEMENT WRONG SYSTEM PLACEMENT
BEACON TRAVEL DOLLY
Beacon Portable sound systems are equipped with a
removable Travel Dolly which features wheels and a
retractable handle. To eliminate possible vibration from
effecting the performance of your unit, we recommended that
you remove the Travel Dolly before operating the system.
TOP BRACKET
RETRACTABLE HANDLE
(CLOSED)
RELEASE
PEDAL
BOTTOM BRACKET
REMOVING TRAVEL DOLLY
1. Press & hold the spring-loaded Release
Pedal located on the Bottom Bracket
2. Swing the dolly bottom away from
the system
3. Lift Handle up to remove dolly from the
Top Bracket
Reverse steps to reattach the dolly
